Ultra Low Volume Fogger
Model SP-4.5
SUITABLE FOR RAPID DEEP DISINFECTION OF:
OFFICES, SCHOOLS, COLLEGES, WAREHOUSES,
SHOPS, BANKS, HOTELS, B&Bs, BARS, RESTAURANTS,
SURGERIES, DENTAL PRACTICES, BUSES, TAXIS,
PRIVATE CARS, COMMON ACCESS AREAS,
WAITING ROOMS, PUBLIC CONCOURSES,
CARE HOMES, RESIDENTIAL PROPERTIES
AND MANY OTHER LOCATIONS
User Guide
Please read before use
Advertisement
Summary of Contents for Sterimax SP-4.5
- Page 1 Ultra Low Volume Fogger Model SP-4.5 SUITABLE FOR RAPID DEEP DISINFECTION OF: OFFICES, SCHOOLS, COLLEGES, WAREHOUSES, SHOPS, BANKS, HOTELS, B&Bs, BARS, RESTAURANTS, SURGERIES, DENTAL PRACTICES, BUSES, TAXIS, PRIVATE CARS, COMMON ACCESS AREAS, WAITING ROOMS, PUBLIC CONCOURSES, CARE HOMES, RESIDENTIAL PROPERTIES...
-
Page 2: Technical Specifications
➢ Spray Fluid Tank Capacity: 4.5 litres ➢ Net Weight (dry without fluid):2.9kg ➢ Dimensions (cm) approx: 33 x 20.5 x 43 ➢ Brand: Sterimax ➢ Model: SP-4.5 ➢ European Conformity Certification: CE ➢ Made in China On/off switch Spray output nozzle... - Page 3 Introduction Thank you for purchasing this electric fogging machine. This machine atomises liquid chemical products in order to create and distribute a pervasive fine fog to a wide-area target environment. The most common uses for this equipment are: ✓ deep-clean disinfection of industrial, commercial, educational and residential locations to protect humans against viral and bacterial infection.
- Page 4 Instructions for Use Refer to Figure 1 as required 1) Unscrew Fluid Reservoir 7) Spray in a smooth motion, Cap and fill reservoir with not aggressively rocking the appropriate chemical fluid up machine or tilting the reservoir to a maximum 4.5 litres. backwards (as that will cause intermittent supply of fluid to if the fluid that you will be...
- Page 5 Emptying and Cleaning Once operation has finished it is strongly recommended to empty the fluid reservoir of any remaining chemical fluid back into its original container. Then add about 1 litre of water into the fluid reservoir and spray in an outdoor area for 1-2 minutes to rinse any residual chemical fluid out of the internal parts of the appliance.
- Page 6 WARNING ➢ Never operate this equipment directly from an electrical plug socket without first connecting it to a plug-in Residual Current Device (RCD) which will prevent serious injury or death in the event of an electrical malfunction. ➢ Do not operate this machine for more than 20 minutes continuously.
- Page 7 Guide to Suitable Disinfection Fluids for Coronavirus Most industrial cleaning fluids are anti- bacterials. Some are also rated for killing viruses and fungal spores. COVID-19 is caused by a type of virus called a coronavirus. The name of this virus is SARS-CoV-2. To reliably neutralise a virus you need to ensure that you are using a cleaning fluid that is specifically certified for virucidal properties.
- Page 8 Guide to relevant European Test Standards for Disinfecting Agents Poliovirus, Norovirus, Influenza A, VIRUSES adenovirus (EN 14476) MRSA (EN 1276), BACTERIA E.coli (EN 13697), Pseudomonas aeruginosa, Stapylococcus aureus (EN 1276, EN 13697, EN 13727, EN 14561) BACTERIAL SPORES Bacilus subtilis, Clostridium difficile (EN 13704) Aspergillus niger FUNGI...
