Summary of Contents for SwitchBee Central Unit
- Page 2 Works with: CU Ver 1.3.3(4) +, Android App Ver 1.3.3(3) +, and IOS Ver 1.3.5 + Connect the Power adapter to the central unit. Connect the LAN cable to the central unit and to your home router. Status of the Central Unit...
- Page 3 Make sure your phone is connected to the same WiFi network as your router and Central Unit. Open the App. The App iden�fies the central unit and displays the registra�on form. Enter name and e-mail and press register. A�er the welcome screen enter a name for your smart home.
- Page 4 circle blinks to indicate that pairing has started. Follow on screen instruc�ons to select the switch type (configura�on), switch name, switch room and switch icon. The switch can be tested, before moving onto the next switch. to the main screen. To pair more switches at a later stage, press “EDIT”, “+”, “ADD SWITCH”.
- Page 5 1-SW-SSR 2-SW-SSR 1 way module light control: 2 way module light control: Connect the live wire into LIN, Connect the live wire into LIN, and the return or lamp to L1. and the returns/lamps into L1 and L2. If there is a neutral wire present, we recommend to connect it to N.
- Page 6 3-SW-SSR 1-SW-R16-D 3 way module light control: Power switch control module: Connect the live wire into LIN, Connect the live wire into LIN, and the return or load into L1. and the returns/lamps into L1,L2 & L3. Connect the neutral wire into N. (In some boiler switches there are 2 neural wires).
- Page 7 1-M-SSR 2-M-SSR Motor control module: 2 Motor - control module: Connect Live to LIN, Connect Live to LIN, Motor-Down to L1, Motor1-Down to D1, Motor-Up to L2. Motor1-Up to U1, Motor2-Down to D2, and Motor2-Up to the red wire. If there is no neutral bridge U2 to N, just like 3-M-SSR (Op�on 2) If there is a neutral wire present, we recommend to connect it to N.
- Page 8 3-M-SSR (Op�on 1) with NEUTRAL 3-M-SSR (Op�on 2) with NO NEUTRAL Motor module with 2 light controls: Motor module with 2 light controls: If there is a Neutral wire present: If there is NO Neutral wire present: Connect Live to LIN, Motor-Down Connect Live to LIN, Motor-Down to DN.
- Page 9 Two Way Switches Change both switches to Switchbee modules. The primary module (the one connected to the lamp), needs to be paired as a Standard (On/Off) module. The secondary module needs to be paired as a Two Way module. With NEUTRAL 1.
- Page 10 Socket IR – Setup The IR socket only works with the following hardware versions: CU Ver 1.3.3(4) +, Android App Ver 1.3.3(3) +, and IOS Ver 1.3.5 + 1. Insert the smart socket into the wall outlet. 1.1. First setup the socket as a regular Socket and only then as an IR Device 2.
- Page 11 Socket IR – Setup On the screen above select To teach the socket Bring the remote of the the socket that you want new IR commands AC to a distance of at least select: 20cm from the smart socket to transmit the IR from. For example (AC) Socket LEARN NEW ACTION.
- Page 12 Socket IR – Setup Enter descrip�on and select Regular Icon or Text Icon. If you select Text Icon you can create your own Icon as in Picture 3 below, (23) - cool, or even add an EMOJI. We recommend not to create an icon for + or -, but rather to create an icon for a complete scenario.
- Page 13 Switchbee Accessories Dry Contact | Contactor connec�on to module Connect the blue wire from the relay to N, and the red wire from the relay to L1 on the module. Connect a Neutral (Must) to the module - at N.
- Page 14 Backing up the se�ngs in the Switchbee Central Unit (Including backing up users, scenarios, �mers and more), is done through the following steps: Connect a USB s�ck / Flash drive to the USB port on the central unit. In the applica�on press on Menu , se�ngs and slide down to Backup...
- Page 15 Make a short press using a pin or paper clip in the factory reset hole between the power adapter and the antenna at the back of the central unit (short = 1 seconds) 2. Factory Reset.
- Page 16 Technical guidelines by Simchi...
