Tüchler KABUKLIP Operating Manual

Release system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Manual
English v1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KABUKLIP and is the answer not in the manual?

Questions and answers

Summary of Contents for Tüchler KABUKLIP

  • Page 1 Operating Manual English v1.2...

  • Page 2: Table Of Contents

    Table 1: Technical Data KabuKlip Release Unit ................6 Table 2: Technical Data KabuKlip Control System ................. 6 Table 3: Technical Data KabuKlip – DMX Slave ................7 Table 4: Technical Data KabuKlip – Akkupack ................7 Table 5: Technical Data KabuKlip Power Failure Detector ............8 Table 6: Guide values for grip slip force and load capacity ............

  • Page 3: General

    KabuKlip Operating Manual v1.2 - Page 3/17 1. General This Operating Manual (OM) is part of the product scope of supply and must be read before first use. Follow the instructions in this OM. Keep the OM near the system.

  • Page 4: Important Safety And Operating Information

    Take appropriate technical and organisational measures to secure the system so that the connecting and power cables cannot be unplugged. The KabuKlip units will open and drop their load in the event of a power loss. 5. TÜCHLER hereby reject all liability for damage caused by falling objects regardless of whether this was intentional, unintentional or the result of a malfunction.

  • Page 5: Warnings

    KabuKlip Operating Manual v1.2 - Page 5/17 3. Warnings 3.1. Set Screw The set screw must not be tightened in the open state. Doing so may damage the magnetic disk. Set Screw 3.2. Connecting in a Ring The individual release chains may not be joined together to form a ring as this may lead to a defect in the control unit.

  • Page 6: Technical Data

    100 % (permanent operation) Protection class Type KabuKlip IP 23 Type KabuKlip OA IP 54 Table 1: Technical Data KabuKlip Release Unit 4.2. KabuKlip Control System Properties Data Power consumption 160 W / 230 V DMX – IN/OUT connection Connection...

  • Page 7: Table 3: Technical Data Kabuklip - Dmx Slave

    Maximum permissible number of Kabuklip release units per release line Maximum permissible number of Kabuklip release units per KabuKlip - DMX Slave Table 3: Technical Data KabuKlip – DMX Slave 4.2. KabuKlip – Akkupack Properties Data Power consumption 750W / 230V 4x CEE 7/4 „Master“...

  • Page 8: Table 5: Technical Data Kabuklip Power Failure Detector

    The load capacities in Table 3 refer to the system configuration in Table 4. Example: a) Use of 19 KabuKlip release units each with 2 m connecting cable and 50 m control cable (from the control unit to the first KabuKlip release unit)  permissible.

  • Page 9: Areas Of Use Of The Kabuklip System

    After fastening, the KabuKlip release units must be properly secured using the integrated steel safety clip. The control line from the control unit to the first KabuKlip release unit in particular must be free of any tension. Faulty or damaged plug connections can lead to a power loss and therefore premature release of the load.

  • Page 10: Configuration Of The Kabuklip Controller

    KabuKlip Operating Manual v1.2 - Page 10/17 7. Configuration of the KabuKlip controller The following settings must be set on the KabuKlip controller before use: 7.1. Operating mode selection: Use the DIP switch to select between modes:  Master (identical with "Stand-alone") ...
  • Page 11 Set the following settings: Master/Slave = ON The highest possible DMX address is 32. Up to 25 KabuKlip release units can be controlled with one stand-alone system. The KabuKlip release units are all opened simultaneously. 7.3. "Multi" system "Multi" system means that several controllers (connected via DMX where one serves as Master) are used.

  • Page 12: Control Of The Kabuklip Controller

    KabuKlip Operating Manual v1.2 - Page 12/17 8. Control of the KabuKlip controller The following control and display elements are provided on the KabuKlip controller: Status LED LIGHT button Master LED Key-operated switch Release button "Fire" 8.1. Control sequence:  After the DMX addresses and the master/slave relationship have been set, the controller is ready for use.

  • Page 13: Maintenance

     Once the item to be dropped is correctly clamped, turn the key-operated switch to the "Armed" position (the LED clamp lights - pilot lamps on the KabuKlip release units - will go out).

  • Page 14: Troubleshooting

    (see 7.1, Control sequence) 11. KabuKlip DMX Slave The KabuKlip DMX Slave can be used with multiple release chains. It is possible to release different objects at different times. This makes special effects such as diagonal releases and the like possible.

  • Page 15: Cessation Of Use, Disassembly And Disposal

    KabuKlip Operating Manual v1.2 - Page 15/17 11.2. Operation of the Kabuklip DMX Slave Assignment of DMX Addresses to the Release Chains: Chain 1 Chain 2 Chain 3 Chain 4 Chain 5 Chain 6 LED light data Base Base Base...

  • Page 16: Declaration Of Conformity

    KabuKlip Operating Manual v1.2 - Page 16/17 13. Declaration of Conformity The manufacturer hereby confirms that the KabuKlip system complies with the following directives and standards: Machinery Directive 2006/42/EC, ÖVE/ÖNORM E8001, 89/336/EEC, 2004/108/EC, 2006/95/EC, EN 60204-1, EN 60439-1, EN 60950-1.
