- Page 1 OU FLEX Shelf - 027 OU FLEX Operation Manual OU FLEX - 027 Installation and Operation Manual Issue E-1 OU FLEX -027 INSTALLATION AND OPERATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS OU FLEX satellite information ..............Coverage on ASTRA 3B ..............SES contact numbers for line up process ..............OU FLEX shelf 027 ..............Air MAC address:00:06:39:8b:08:ef ..............OU FLEX schematic diagram ..............Front panel and top of the unit .............. -
Page 3: Ou Flex Satellite Information
30Mbit/s upstream and 100Mbit/s downstream. SES Contact Numbers for line up process SES NOC Engineering +31 (0) 7768 685059 Milexia +44 (0) 1256 812222 OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 3... -
Page 4: Ou Flex Shelf 027
OU FLEX SHELF 027 Air MAC Address:00:06:39:8b:08:ef The 1RU OU-Flex shelf include: Power supplies, Newtec MDM3310 modem, 2 combiners for L-Band interface, 2 LAN ports and a WiFi hotspot router. The inclusion of this shelf into an existing Ku band DSNG vehicle or flyaway will enable ac- cess to the SES OU-FLEX platform providing two-way broadcast capability of up to 20Mbps uplink and 25Mbps downlink over the Astra 3B satellite. -
Page 5: Front Panel And Top Of The Unit
OU FLEX SHELF 027 Front Panel and Top of the unit Rear Panel NOTE: All connections are N-Type 50Ω OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 5... -
Page 6: Ou Flex Modem (Newtec Mdm3310)
CONNECTING TO THE OU FLEX SHELF OU FLEX Modem (Newtec MDM3310) Modem front panel LED indication Connecting to the OU FLEX Shelf LAN / WIFI Router SSID: 2G Network OU FLEX 027 2G 5G Network OU FLEX 027 5G Router LAN IP ADDRESS: 192.168.1.254 Password:... -
Page 7: Modem Configuration
CONNECTING TO THE OU FLEX SHELF Modem Configuration Connect to the Modem either via the: • WIFI SSID OU FLEX 027 • Or directly from the front panel LAN ports Your computer should be configured in DHCP mode If the modem is attached directly to the internal router which acts as a DHCP server for the computer. -
Page 8: Expert Mode
EXPERT MODE The Expert mode will allow you to edit the modem parameters and conduct the line-up tests. Logging into expert mode Type into the URL bar: http://192.168.1.1/cgi-bin/index?ilogin *NOTE ?ilogin - note the ‘i’ after the index Password: s3p OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 8... -
Page 9: Buc And Lnb Set Up
EXPERT MODE BUC and LNB Set Up You can configure your BUC parameters within the NEWTEC modem 1. Select >Outdoor Unit then select the ODU type ID < 27 OU-FLEX customer INPUT 2. Select your LNB set up <single band or switchable < 22 KHz tone ON/OFF < Voltage 13V or 18V 3. -
Page 10: Carrier Installation Set Up
EXPERT MODE Carrier Installation Set Up ONLY WHEN INSTRUCTED TO DO SO FROM THE SES NOC You may be asked to activate a dedicated installation carrier test mode to verify the correct terminal installation and pointing of the antenna, or to perform a manual line-up procedure toset the correct modem TX output level. -
Page 11: Making A Booking
MAKING A BOOKING Booking Tool SES have an advanced booking tool that allows the user to book occasional use service online and on the fly based on their requirement for throughput and time. Bookings can be entered and also modified online as required. - Page 12 MAKING A BOOKING You will then see the OU Services screen. On this screen you can see your up coming events with the event name, date, start time end time and duration. On the right hand side is the status of the booking which will either be pencil (which means it hasn’t been confirmed by SES) firm (SES approved) or billing (event has happened and is still to be billed).
-
Page 13: To Make A New Booking
MAKING A BOOKING To Make a New Booking Click on the Booking Inquiry ( blue tab) at the top left of the OU Services screen. You will then have a choice of IP over satellite or pure satellite capacity which is also bookable through this portal. - Page 14 MAKING A BOOKING You then enter a screen where you can select the project, the event name & description and the location. You also have to enter the modem ID that has been agreed with SES during registration and an SNG registration with SES if you have one. Then click Next.
- Page 15 MAKING A BOOKING Click Submit and then OK after you receive a thank you for booking message. This will take you back to the OU Service page where you will see your booking awaiting approval. Once approved you will receive an e-mail to confirm that it is now a live booking. OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 15...
-
Page 16: Appendix A - System Reset
APPENDIX A - SYSTEM RESET Hold down the reset button and power cycle OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 16... -
Page 17: Appendix B - Router Set Up
APPENDIX B - ROUTER SET UP OU FLEX -027 INSTALLATION AND OPERATION MANUAL PAGE 17...
