READY SET STAND
Please read the following safety instructions before commencing set up
∆
Once you have found a new home for your new desk, make sure there are no obstacles in its path
∆
Make sure the desktop isn't set up right up against any walls
∆
To avoid risk of injury keep children away from electric standing desks, control boxes and controllers
∆
Keep all electrical components away from liquids
∆
Do not sit or stand on Ready Set Stand frames
∆
Do not open electrical components (lifting legs, control box, controller) as there may be a risk of injury
∆
Ready Set Stand electric standing desks has electric motors which are designed for dry work areas only
∆
The desk is height adjustable in order to suit your desk ergonomics needs while you work.
Any other use is at the risk of the user
STANDING DESK FRAME - PARTS & TOOLS LIST (KIT INCLUSIONS)
1.
Support Beam (x1)
2.
Side Bracket (x2)
3.
Feet (x2)
4.
Foot Pad (x4)
5.
Lifting System (1 leg with Motor, 1 leg with Gearbox)
and Control Box
6.
ST3.5*19 Screws (x2)
7.
ST4.8*19 Screws (x10)
8.
M6*16 Bolts (x16)
9.
M8*16 Bolts (x8)
10.
Rubber Cushion (x8)
11.
5mm Hex Allen (x1)
BEFORE YOU BEGIN
1.
We recommend you lay all the peices flat on the floor and your bamboo top laying flat with the pre-drilled holes facing up
2.
You will need your own Phillips head screw driver for fixing the frame to the bamboo top (not included in the toolkit)
3.
It's recommended to use an electric drill for faster assembly, or in case you need to pre-drill any holes into your bamboo top
NEED A HAND DURING YOUR SET UP? DROP US AN EMAIL AT
SHARE YOUR PHOTOS WITH US VIA INSTAGRAM #READYSETSTAND OR FIND US ON FACEBOOK @READYSETSTANDAU
THANK YOU FOR CHOOSING READY SET STAND DESKS FOR YOUR ACTIVE WORK SPACE
1
2
3
4
6
7
8
contact@readysetstand.com.au
DUAL MOTOR DESK WITH
DELUXE CONTROL
ASSEMBLY INSTRUCTIONS
5
9
10
11
Advertisement
Table of Contents
Summary of Contents for Ready Set Stand DUAL MOTOR DESK WITH DELUXE CONTROL
- Page 1 Do not open electrical components (lifting legs, control box, controller) as there may be a risk of injury ∆ Ready Set Stand electric standing desks has electric motors which are designed for dry work areas only ∆ The desk is height adjustable in order to suit your desk ergonomics needs while you work.
- Page 2 READY SET STAND DUAL MOTOR DESK WITH DELUXE CONTROL ASSEMBLY INSTRUCTIONS 5MM HEX ALLEN a. Before you begin, lay down bamboo desktop on the ground with pre-drilled holes facing up b. Using the 5mm Hex Allen Key - loosen the 8 centre support beam bolts and extend support bar out c.
- Page 3 READY SET STAND DUAL MOTOR DESK WITH DELUXE CONTROL ASSEMBLY INSTRUCTIONS a. Carefully overturn the frame as shown b. Using the 5mm hex allen and M6*16 bolts, attach side brackets as shown c. Fit rubber cushions to the side brackets and centre support...
- Page 4 READY SET STAND DUAL MOTOR DESK WITH DELUXE CONTROL ASSEMBLY INSTRUCTIONS ABOUT YOUR DELUXE DESK CONTROLS How To Program Your Memory Settings 1. Use the up/down buttons to find your desired height 2. Press and hold the “M” key until the digital height display starts flashing 3.
