Summary of Contents for r2p Tracking ProBox 3100
- Page 1 ProBox 3100 Installation Revision: 030918 http://www.r2ptracking.dk...
- Page 2 PROBOX 3100 The ProBox sends the tracking data by means of GMS/GPRS. A SIM card is required. Make sure PIN code has been turned off. You may have to insert the SIM card into a mobile phone to turn off PIN code.
-
Page 3: Front View
PROBOX 3100 LED’s MICROPHONE (NOT USED) GPS LED GSM/GPRS LED PERIPHERAL LED FRONT VIEW GPS LED Two (2) blinks pr second = GPS NOT OK One (1) blink pr second = GPS OK GSM/GPRS LED Four (4) blinks pr second... -
Page 4: Rear View
PROBOX 3100 GPS antenna Remove self-adhesive tape Voice, microphone Mount of flat surface USB, computer GPS LED GSM LED PERIPHERAL LED FRONT VIEW REAR VIEW 1 Red Plus, 10-30 volt 1 Yellow RS232, B, Rx 2 Black Ground 3 Orange... - Page 5 PROBOX 3100 Start by finding a good location for the hardware. Installation-wires can be extended if required. A typical installation spot is under the dashboard but behind or over the glove compartment. From here you can often run the wires to the back of the radio where you find the power and ignition (switched 12 volt).
- Page 6 PROBOX 3100 Minimum wiring for tracking: Ground, 12 volt and ignition. GPS antenna FRONT VIEW REAR VIEW Fuse 3 amp Battery 1 Red Plus, 10-30 volt 2 Black Ground 9 Yellow Ignition 12/24 volt when ignition is on...
- Page 7 PROBOX 3100 1-wire connection Driver RFID login White 6 Green/Yellow 1W DATA 2 Black Ground Black 8 Purple Digital Out 1 Green 12/24 volt when ignition is on...
- Page 8 PROBOX 3100 White Yellow Grey Brown Brown 8 Purple Digital Out 1 250ohm Resistor Green Not used...
- Page 9 PROBOX 3100 Computer USB connection Software updates / configurator...
- Page 10 PROBOX 3100 CANCLIQ connection Blue 8 White CAN high Yellow 10 Blue CAN low Black 12 Black Ground CAN BUS 12/24 volt when ignition is on See our manual CAN BUS DETECTION if you do not know how to detect...
- Page 11 PROBOX 3100 J1708 connection Orange J1708 A 13 White/Red Brown 14 Yellow/Brown J1708 B Black 2 Black Ground J1708 12/24 volt when ignition is on...
- Page 12 PROBOX 3100 Driver panel connections 4 Red, 5 volt Black Purple Orange Green (not used) White (not used)
- Page 13 PROBOX 3100 Tacho Driver Login Tacho, D, 8 K-line, Brown Pin 11 TACHO, REAR VIEW...
- Page 14 PROBOX 3100 TACHO REMOTE DOWNLOAD CAN H, White/Red Tacho, C, 5 Pin 12 Tacho, C, 7 CAN L, Blue/Red Pin 11 Tacho, C, 8 Tacho, D, 8 K-line, Brown Pin 11 TACHO, REAR VIEW...
- Page 15 PROBOX 3100 TACHO REMOTE DOWNLOAD CAN BUS CAN H, Pin 8 CAN H, Pin 12 Tacho, C, 5 CAN BUS CAN L, Pin 10 Tacho, C, 7 CAN L, Pin 11 Tacho, C, 8 Tacho, D, 8 K-line, Pin 11 Interconnections between pins C7 and C8 is Usually reguired.
- Page 16 PROBOX 3100 Draeger Interlock 7000 10 Orange Digital 2 Out Pin 14 Pin 16 D8 KLINE TACHO, REAR VIEW RJ48 If pin 16 from the Interlock 7000 is connected to pin D8 on the Tachograph, the user switch will be overruled by the Interlock 7000.
- Page 17 PROBOX 3100 Temperature Sensor +5v Power 4 Red Yellow 6 Green/Yellow 1W Data 2 Black Ground Black...
-
Page 18: Jamming Detection
PROBOX 3100 Jamming Detection Power 10 - 30 volt Orange Digital 2 Out Digital output 2 is enabled when Jamming is detected. The digital output 2 is an open collector output and have a maximum rating of 300 mA. When the digital output is enabled there will be Ground on the output wire. -
Page 19: Digital Inputs
PROBOX 3100 Digital inputs 3 Pink Digital 1 In 5 Blue Digital 2 In 7 White Digital 3 In 2 Black Ground... -
Page 20: Analog Inputs
PROBOX 3100 Analog inputs 4 Grey Analog 1 In 6 Green Analog 2 In 2 Black Ground... -
Page 21: Digital Outputs
PROBOX 3100 Digital outputs 8 Purple Digital 1 Out 10 Orange Digital 2 Out 2 Black Ground...
