Summary of Contents for Sidney Attachments TTS12-3PT
- Page 1 3-POINT TREE SAW USER GUIDE 866-567-9618 | SidneyAttachments.com...
- Page 2 The following manual should answer any questions you may have about your Sidney Attachments product. However, if you need additional information, please feel free to contact your local dealer or us at Sidney Attachments directly at 1-866-567-9618. Proudly crafted in the USA.
-
Page 3: Table Of Contents
SIDNEY ATTACHMENTS 3 POINT TREE SAW Table of Contents Introduction Regulations and Standards Known Hazards and Hazard Mitigation Inspection Checklist Installation and Removal Operation Maintenance Troubleshooting Limited Warranty SA-3PTTS-20-07-15... -
Page 4: Introduction
Introduction Three Point Tree Saw Features and Specifications: Model 3 Point Tree Saw Part Number TTS12-3PT Dimensions 45” x 46” x 55” Weight (dry) 539 lb Max Horsepower 75 hp Fluid Capacities Bearing 32 fl oz SAE90... - Page 5 Special Note: Current at the time of publication. Sidney Attachments reserves the right to redesign all or any portion of this attachment and the owner’s manual at any time without notification. For questions or concerns, or to inquire about updates, please contact your...
-
Page 6: Regulations And Standards
Regulation and Standards General safety considerations: OSHA clear zone Radius = 2x height of tree Known Hazards and Hazard Mitigation • Flying objects — WARNING: Flying debris may be created when using this attachment. Use personal protective equipment and keep all bystanders at a safe distance. •... - Page 7 General Safety Precautions: Sidney Attachments wants users to have many years of safe, low-maintenance use from the Sidney Tree Saw attachment. Please read the following section regarding safety thoroughly and follow all precautions each time the Sidney Tree Saw attachment is used.
-
Page 8: Inspection Checklist
3. Maintain the machine in safe operating condition: • Follow the manufacturer’s instructions. • Keep the foot controls free of mud, ice, snow, and debris. • Regularly inspect and maintain: Interlocked controls » Seat belts » Restraint bars » Side screens »... -
Page 9: Installation And Removal
Installation and Removal • Lifting/Points It is recommended that the user sling the Sidney tractor tree saw near the CG location and balance by hand. DO NOT lift or sling the saw in any manner that might damage the blade or drive shaft. •... -
Page 10: Operation
OPERATION General Use: • Blade The saw blade will spin whenever the PTO is engaged if the saw is properly connected to the machine. • Downing Downing of standing trees requires care and planning. Be aware of wind, slopes, leaning stems, and other factors that may indicate the probable direction that the tree will fall once cut. -
Page 11: Maintenance
Maintenance Saw teeth are consumable items which are inexpensive and easy to replace. The special tool required for servicing the teeth is supplied with the saw and can be found inside the saw body bolted to the right side. Remove this tool and acquire a set of teeth. -
Page 12: Troubleshooting
Lubrication Points & Procedures Drive shaft universal joints: • Lubrication interval: » Once per season under casual use. » Lubricate weekly under heavy use or adverse conditions such as rain or snow. Bearing Assembly: • The bearing assembly inside the head contains gear oil. •... - Page 13 Driveshaft Clutch Gearbox Fill Plug Front Cover Top Link Pin Lower Link Pin Saw Frame LH Side Cover Top Cover Blade Adapter Blade Shoe...
-
Page 14: Limited Warranty
Limited Warranty The goal of Sidney Attachments (“Sidney”) warranty policy is to assure confidence, reduce downtime and minimize cost of ownership. Should you want to verify warranty, or should potential issues arise, please contact your authorized dealer or Sidney’s Customer Service Team at Info@SidneyAttachments.com, 866-567-9618, or 913-495-4803 and we will strive to resolve any issues in a timely manner. - Page 15 General All Sidney Limited Warranties are extended only to the original purchaser in the U.S. and may be void in the event that the product is sold or otherwise transferred. No warranty will apply to any product that been (i)modified, altered or adapted without Sidney’s written consent, (ii) abused or misused, (iii) repaired by any third party in a manner which fails to meet Sidney’s repair standards, (iv) improperly installed, (v) used without a proper functioning case drain, (vi) modified to defeat the motor protection valve, (vii) used with any device or implement not covered by this warranty, or used outside of the United States.
- Page 16 SidneyAttachments.com 16000 W. 108th Street Lenexa KS, 66219 SA-UG-TPP-1906171 2019 User Guide...
