VAM-HD 12v
Installation Guide
NOTE: This Product is intended for installation by a professional installer only! Any
attempt to install this product by any person other than a trained professional may
result in severe damage to the electrical system and to vehicles components.
Page 1 of 5
COMPANY CONFIDENTIAL
©2016 REDTAIL TELEMATICS

Advertisement

loading
Need help?

Need help?

Do you have a question about the VAM-HD 12v and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for REDTAIL TELEMATICS VAM-HD 12v

Summary of Contents for REDTAIL TELEMATICS VAM-HD 12v

  • Page 1 VAM-HD 12v Installation Guide NOTE: This Product is intended for installation by a professional installer only! Any attempt to install this product by any person other than a trained professional may result in severe damage to the electrical system and to vehicles components.
  • Page 2 Table of Contents VAM-HD Plugin Installation ………………… … Testing the VAM-HD 12v plugin …………… Status LED Diagnostics ……………………… ….. Regulation ……………………………………………… 5 Page 2 of 5 COMPANY CONFIDENTIAL ©2016 REDTAIL TELEMATICS...
  • Page 3 VAM-HD 12V PLUGIN INSTALLATION 1. Plug the device into the 12V adapter 2. Using the supplied Velcro strips, securely fasten the device to the carpet or dashboard with the white barcode label facing downwards. Avoid installing the unit where it is subject to kicks or bumps such as in the glove box or under the central armrest.
  • Page 4 Orange 1 rapid flash Ignition OFF Green 2 rapid flashes Ignition ON Bluetooth 1 long flash Searching for a Bluetooth connection Orange Green 2 long flashes Bluetooth connected 1 long flash Bluetooth not connected/off Page 4 of 5 COMPANY CONFIDENTIAL ©2016 REDTAIL TELEMATICS...
  • Page 5 (e.i.r.p.) is not more than that permitted for successful communication. The product should not be installed in the engine bay of the vehicle. The product should be installed at least 20cm away from any persons within the vehicle. Page 5 of 5 COMPANY CONFIDENTIAL ©2016 REDTAIL TELEMATICS...
