- Page 1 HOME MONITOR User Manual OV2411 The features & specifications described in this user’s guide may be subjected to modifications without prior notice.
- Page 2 OV2411 HOME MONITOR Safety Instructions WARNING This home monitor is compliant with all relevant standards regarding Guide, safe to use. Therefore, always read the instructions in this User’s Guide carefully before using the device. - This product is not a toy. Do not allow children to play with it.
- Page 3 9. Cam 3 Key 1.2 Keys All ovizee handset operation are done with the following keys : Power, Menu, Enter, Cam1, Cam2, Cam3, Cam4, Up, Down, Left, Right. Press <Menu> to go to enter the main menu. The main menu consist of the pairing, LCD contrast, brightness, video display timer, night-vision, voice trigger and snap-shot video viewer selection.
- Page 4 There is no setup involved. Just plug-in power and it will start working. For additional camera, pairing procedures must be done before usage, please refer 2.1 for details. The camera unit comes with built-in light-sensor, IR-LED, Power LED, microphone and speakers that work with Ovizee handset unit.
- Page 5 OV2411 HOME MONITOR 2.1 Camera unit power supply 1. Connect the small plug of the AC adaptor to the baby unit and the other end to the mains socket (230V/50Hz). NOTE Only use the enclosed power adapter (5V DC / 1000mA).
- Page 6 OV2411 HOME MONITOR 2.2 Vision unit battery installation 1. Insert the wire tab of the rechargeable battery pack into the contact 2. Close the battery compartment and tighten the screw in a clockwise direction. - It will take a few seconds to start up the unit.
- Page 7 OV2411 HOME MONITOR 2.3 Vision unit power supply IMPORTANT Install the rechargeable battery pack before connecting the AC power supply. 1. Connect the small plug of the AC adaptor to the parent unit and the other end to the mains socket (230V/50Hz) NOTE Only use the enclosed power adapter (5V DC / 1000mA)..
-
Page 8: First Time Installation
OV2411 HOME MONITOR 2.4 First time installation done before normal operation (Note: Devices comes with Camera/Viewer pair needs no pairing as they are already pre-paired in the factory). Choose the zone for paring by pressing ZONE1 to ZONE4. Press <MENU>... -
Page 9: Speaker Volume Control
OV2411 HOME MONITOR 3.1 Select Camera (Zone) press <ZONE1> to go to video zone 1, press <ZONE2> to go to video zone 2, Zone1 Zone3 press <ZONE3> to go to video zone 3, press <ZONE4> to go to video zone 4. - Page 10 OV2411 HOME MONITOR 3.3 Talk function(Vision to Camera) Press <UP/TALK> to set two ways audio, a “Talking” icon will be showed on the top of the display. Hold this key to continue talking. Release the key after speaking. Up/Talk 3.4 Snap-shot Function (Handheld to Camera ) Press <Down/Snap shot>...
-
Page 11: Night Vision
OV2411 HOME MONITOR Press <MENU> then <UP> and <DOWN> to select Video Timer Press <LEFT> and <RIGHT> to set video on timer ( 15s, 1 min and always on ) Press <MENU> again to quit * Note that the power up default setting is 1 min * Video Timer setting is applied to all cameras 3.6 Night-Vision... -
Page 12: Contrast Control
OV2411 HOME MONITOR 3.7 Voice Trigger/Wakeup Press <MENU> then <UP> and <DOWN> to select voice trigger function. Press <LEFT> or <RIGHT> to choose VOX level Right mode= Maximum volume to turn on the camera If voice trigger is detected by the camera, the PandaVision Viewer will automatically switch to the camera even it is viewing other channel or standby. -
Page 13: Real-Time-Clock Setup
OV2411 HOME MONITOR 3.9 Memory-card Photo-viewer Ovizee handset supports snap-shot function if a micro-SD card ( < 2GB ) is present. ( The Micro-SD card should be FAT16 or FAT32 pre-formatted ) All photo will be stored in the order PV000000 to PV999999, under the directory “OVIZEEVIS”... -
Page 14: Fcc And Ic Regulations
OV2411 HOME MONITOR FCC and IC regulations FCC Part 15 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 15: Industry Canada
OV2411 HOME MONITOR WARNING Changes or modi cations to this equipment not expressively approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Operation is subject to the following two conditions: (1) this device may not... -
Page 16: Industrie Canada
OV2411 HOME MONITOR Toute modi cation ou changement e ectué à cet appareil sans l’accord des parties responsables de l’homologation peut retirer à l’utilisateur son droit d’utiliser l’appareil. Cet appareil est conforme à l’article 15 de la FCC. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d’interférences nuisibles et;... -
Page 17: Disposal Of The Device (Environment)
OV2411 HOME MONITOR Disposal of the device (Environment) At the end of the product lifecycle, you should not dispose of this product with normal household waste, but take the product to a collection point for the recycling of electrical and electronic equipment. The symbol on the product, user’s guide and/or box indicates this. - Page 18 OV2411 HOME MONITOR Baby unit Frequency : 2.4GHz to 2.4835GHz Maximum range : 150m Line of Sight Image sensor : Colour CMOS Lens: f 2.5mm, F 2.8 IR LED : 9 pcs Power : Adapter: DC5V, 1000mA (Model: GPE, GPE053-050100-Z)
- Page 19 OV2411 HOME MONITOR Manufactured, distributed or sold by Pandachip Limited, the owner of OVIZEE and the Stylized OVIZEE Logo, and other OVIZEE trademarks and trade dress. OVIZEE and the Stylized OVIZEE Logo are registered in the HK Patent & Trademark are the property of their respective owners.
