- Page 1 2 -Wire Intercom System DT591/592 User Manual DT591 DT592 DT-ENG-591/592-V1 100S719...
-
Page 2: Table Of Contents
CONTENTS 1.Parts and Functions..................... 1 2.Terminal Descriptions ..................1 3.Specifications ...................... 2 4.Mounting ......................2 4.1 Mounting Without Rainy Cover ..............2 4.2 Mounting With Rainy Cover ................3 4.3 Placing Name Label ..................3 4.4 Adjusting Camera Angle ................4 5.System Wiring and Connections ................. -
Page 3: Parts And Functions
1.Parts and Functions Camera Lens Night View LED Speaker Nameplate Call Button Microphone Rainy Cover 90 mm 23 mm Note: DT592 has two call buttons. 2.Terminal Descriptions 1 2 3 Lock Control Jumper Doorstation Code DIP MIC adjustment SPK adjustment Main Connect Port S 2 + S - P L S 1 +... -
Page 4: Specifications
• To select the lock type: see 5.2.1 , 5.2.2 Lock Control Jumper: • Total 4 doorstations can be supported,see 6.1 Doorstation Code DIP: • To connect the bus line and the electronic locks. Main Connect Port: • BUS: Connect to the bus line, no polarity. •... -
Page 5: Mounting With Rainy Cover
4.2 Mounting With Rainy Cover 160-165cm 4.3 Placing Name Label Move the plastic cover away to open the transparent name label cover, insert a name paper, then put the plastic cover back to the panel. name label... -
Page 6: Adjusting Camera Angle
4.4 Adjusting Camera Angle use a screwdriver to loosen the screw and then adjust the angle of the camera ,then fix the screw. 5.System Wiring and Connections 5.1 Basic Connection monitor L1 L2 PL S1+ S2+ S-... -
Page 7: Electric Lock Connection
5.2 Electric Lock Connection 5.2.1 Door Lock Controlled with Internal Power Note: Electronic lock of Power-on-to-unlock type should be used. The door lock is limited to 12V, and holding current must be less than 250mA. The door lock control is not timed from Exit Button(EB). Parameter of Monitor must be set to 0 (by default). -
Page 8: How To Setup The Unlock Parameter In Monitor
Note: 1.must connect DT591/592 correctly before setting. 2.the parameter will be saved in DT591/592 automatically,so you need only set on one monitor. 3.the above diagram is fit for icon menu series monitors only, to text menu series monitors,please refer to the corresponding user manual. -
Page 9: Multi Doorstations Connection
5.3 Multi Doorstations Connection monitors DBC4 A B C D 85~260VAC 4# Camera 3# Camera 2# Camera 1# Camera ID=11 ID=01 ID=10 ID=00 L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S- L1 L2 PL S1+ S2+ S-... -
Page 10: Multi Monitors Connection
5.4 Multi Monitors Connection 5.4.1 Basic IN-OUT Wiring Mode monitor 3 4 5 6 Code=15, DIP-6=on monitor 3 4 5 6 Code=14, DIP-6=off monitor 3 4 5 6 Code=0, DIP-6=off 85~260AC ID=00... -
Page 11: With Dbc-4 Wiring Mode
5.4.2 With DBC-4 Wiring Mode monitor monitor 3 4 5 6 3 4 5 6 Code=14, DIP-6=on Code=15, DIP-6=on monitor monitor 3 4 5 6 3 4 5 6 Code=12, DIP-6=on Code=13, DIP-6=on monitor monitor 3 4 5 6 3 4 5 6 Code=2, DIP-6=on Code=3, DIP-6=on monitor... -
Page 12: Setup
6.Setup ON(1) OFF(0) 6.1 DIP Switches Settings of Doorstation Total 2 bits on the DIP switches can be configured.The switches can be modified either before or after installation. Bit state Descriptions Default setting, ID = 0(00), set to the first Door Station. ID = 1(10), set to the second Door Station. - Page 13 Bit-1 to Bit-5 are used to User Code setting. The value is from 0 to 31, which have 32 different codes . Bit state User Code Bit state User Code Bit state User Code Code=0 Code=11 Code=22 3 4 5 3 4 5 3 4 5 Code=1...
-
Page 14: Notices
6.3 Notices Name Discription Usage Power supply,85~260Vac input,24Vdc/3A Connect with multi doorstations or PS5-24V output,10 DIN modules multi monitors(up to 2 or above) Power supply,85~260Vac input,24Vdc/1A Connect with one doorstation and one PS4-24V output,for basic kit only,4 DIN modules monitor(DT16 can be connected two) -12-... -
Page 15: Cables Requirements
7.Cables Requirements The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach. The farest monitor monitor with two or four monitors monitor monitor DBC/DBC-4 When Monitor quantity <... - Page 16 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
