Page 1 All manuals and user guides at all-guides.com Intelligent Auto Dialed Alarm System (dial automatically the number saved by householder) CONTENTS MODEL:RL-0503CD Usage ..1 Feature ..1 Accessories ..1 System installation ..2 Operation instruction ..5 6.Additional accessories ..6 Technical data ..7 Diagram ..8...
Page 2 All manuals and user guides at all-guides.com Intelligent Auto Dialed Alarm System (dial automatically the number saved by householder) 4.System installation RL-0503CD USER MANUAL A.Main unit: 1.Usage 1.Connect one terminal of telephone line to the main unit and the other terminal to the telephone.
Page 3 All manuals and user guides at all-guides.com 2)outdoor Loose the screws, load 4x LR6 alkaline batteries and put it in an Obvious Place outside the house. C.Magnet sensor: E. Magnetic code controller It consists of magnetic bar and sensor. Stick the magnetic bar and sensor on the door/window and It consists o f magnetic bar and controller sensor.
Page 4 All manuals and user guides at all-guides.com c.Answer the telephone: hang up the telephone or mobile and then other alarm numbers will .Operation be dialed continuously after one finishes answering the telephone and mobile and hearing Switch o n th e main unit, load batteries for all accessories. Operatio n begins when NO- SAVE the record.
Page 5 All manuals and user guides at all-guides.com 7.Technical data 8. Diagram Main unit: Magnetic code controller Input voltage: DC6V-9V Input volts: DC4.5V (AAAx3) Working current: <12 m A Standby current: <10uA Receive frequency: 433.5MHZ-434MHZ Transmission current: <5mA Transmission frequency: 433.5MHZ-434MHZ Transmission distance: >50m (open area) Infrared sensor Input volts: DC4.5V (AAAx3)
