Slim's Detailing SLIMS149 Instructions

Thank you for purchasing a Slim's product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PlEASE READ THESE INSTRUCTIONS CAREFUlly. NOTE THE SAFE OPERATIONAl REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTly AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAIlURE TO DO SO MAy CAUSE DAMAGE AND/OR PERSONAl INJURy AND WIll
INVAlIDATE THE WARRANTy. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETy
Refer to Wear ear
instruction protection
manual
1.1.

ElECTRICAl SAFETy

 WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and any other
connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of appropriate safety devices. A
Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also recommend that a Residual Current
Device (RCD) is used. It is particularly important to use an RCD with portable products that are plugged into a supply which is not protected by an
RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual Current Device by contacting your Sealey dealer.
you must also read and understand the following instructions concerning electrical safety.
1.1.1. the Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a
qualified electrician, using a Portable Appliance tester (PAt), at least once a year.
1.1.2. the Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those
appliances and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1. and 1.1.2.
and use a Portable Appliance tester.
1.1.4. Ensure that cables are always protected against short circuit and overload.
1.1.5. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure
that none is loose.
1.1.6. Important: Ensure that the voltage marked on the appliance matches the power supply to be used and that
the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7. DO NOT pull or carry the appliance by the power cable.
1.1.8. DO NOT pull the plug from the socket by the cable.
1.1.9. DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty item repaired or
replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is damaged, cut the cable just above
the plug and dispose of the plug safely. Fit a new plug according to the following instructions (UK only).
a) Connect the GREEN/yEllOW earth wire to the earth terminal 'E'.
b) Connect the BROWN live wire to the live terminal 'l'.
c) Connect the BlUE neutral wire to the neutral terminal 'N'.
d) After wiring, check that there are no bare wires, that all wires have been correctly connected, that
the cable outer insulation extends beyond the cable restraint and that the restraint is tight.
Double insulated products, which are always marked with this symbol
to rewire, connect the wires as indicated above - DO NOT connect either wire to the earth terminal.
1.1.10. Products which require more than 13amps are supplied without a plug. In this case you must contact a qualified electrician to ensure that a
suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket with your
electrician.
1.1.11. If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. the cable core section is important and should be at least 1.5mm², but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use of
2.5mm² section cable. If an extension reel is to be used outdoors, ensure it is marked for outdoor use.
1.2.

General Safety

WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this equipment.

WARNING! Disconnect from mains power before changing accessories or servicing.

Maintain the sander/polisher in good condition (use an authorised service agent).

Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.

Use the sander/polisher in a suitable work area. Keep area clean, tidy and free from unrelated materials. Ensure that there is adequate

lighting.
Before use, check abrasive pad condition. If worn or damaged replace immediately.

WARNING! Always wear approved eye or face protection when operating the sander/polisher.

If dust is generated, use face, dust, or respiratory protection in accordance with COSHH regulations.

Depending on use, sander/polisher noise level may exceed 85dB - in which case wear safety ear defenders.

Remove ill fitting clothing, ties, watches, rings, other loose jewellery and contain and/or tie back long hair.

Wear appropriate protective clothing and keep hands and body clear of moving parts.

Maintain correct balance and footing. Ensure the floor is not slippery and wear nonslip shoes.

Keep children and unauthorised persons away from the work area.

Always use the sander/polisher with the side handle securely screwed in.

Ensure the workpiece is correctly secured before operating the sander/polisher. Never hold workpiece by hand and check the workpiece to

ensure there are no protruding nails, screws, rivets, etc.
INStRUCtIONS FOR:
600W 150MM RANDOM ORBITAl DUAl
ACTION SANDER
MODEl NO:
Wear eye Wear
protection protective
gloves
Original Language Version
/POlISHER
SlIMS149
Wear
a mask
, are fitted with live (brown) and neutral (blue) wires only.
FUSE RATING
THIS PRODUCT MUST BE
FITTED WITH A
5 AMP FUSE
SlIMS149 | Issue:2- 18/08/16
