Solvent Based Spray Gun Cleaner
Operating
Instructions
UGC2005
UGC2005M
UGC3005
UGC4005
UGC5005
What it should come with
105 - Grid Filter x 1
128 - Work Screen x 1
2050 - Quick Release Coupling x1
736 - Hook x 1
2030 - Extended Nozzle Kit includes x 2
Also available:
786 - Air, Dirt & Water trap
783 - Nipple
Installation fittings:
FRA3 3" Angle Flange
We also recommend:
Solvent Recycler
sales@air-allied.com.au
FD3 3" Flexi Ducting
FR3 3" Angle Flange Flat
F6R5 6" to 5" Reducer
Paint Can Crusher
Air & Allied Sales (Pacific) Pty Ltd
UGC5005 ONLY
105 - Grid Filter x 2
128 - Work Screen x 2
2050 - Quick Release Coupling x 2
2030 - Extended Nozzle Kit x 4
736 - Hook x 2
Gate Valve 803
FF3 3" Flange Flat
Paper Compactor
F5R3 5" to 3" Reducer
www.air-allied.com.au
Advertisement
Table of Contents
Summary of Contents for Air & Allied Sales UGC2005
- Page 1 Solvent Based Spray Gun Cleaner Operating Instructions UGC2005 UGC2005M UGC3005 UGC4005 UGC5005 What it should come with 105 - Grid Filter x 1 UGC5005 ONLY 128 - Work Screen x 1 105 - Grid Filter x 2 2050 - Quick Release Coupling x1...
- Page 2 Setting the machine up PLEASE NOTE: It is advised that an air, dirt and water trap filter is fitted (786 as shown on the front page). This will protect the valves and cylinder from dirt and water contamination. It is possible to obtain 100/150 gun washes from a 25 litre drum of solvent but this is dependent upon how much paint material is left in your spray gun pot.
- Page 3 Installation of containers WARNING: DO NOT SMOKE OR USE OPEN FLAME NEAR CABINET. UGC4005 ONLY Take 1 x 25litre drum of clean solvent, remove 5 litres and fill an empty 5 litre container. UGC5005 ONLY Take 2 x 25litre drum of clean solvent, remove 5 Litres from each drum and fill 2 x empty 5 litre container.
-
Page 4: Using The Machine
Using the machine Please Note: For best results spray guns should be cleaned as soon as possible after use. Any paint left in cup/pot should be emptied into a waste container or stored for future use. Place paint cup/pot into machine over the top pair of square nozzle jets. The air cap of the spray gun can either be loosened or removed completely and put into machine. - Page 5 Unic International (UK) Health & Safety Data Sheet Information supplied in accordance with section 6 of the health and safety at work etc. Act 1974 PRODUCT NAME UNIC POWERCLEAN SPRAY GUN CLEANING UNIT. USES Removal of paint from Spray guns, cups and hoses. GENERAL Before operating Powerclean Spray Gun Cleaning System, operators must be PRECAUTIONS...
-
Page 6: Test Report
Test Report on emissions from Powerclean Spray Gun Cleaners Table 3 - Solvent concentrations measured during the operation of a Unic Powerclean Automatic Spray Gun Cleaning Machines. Short Term Monitoring Monitoring Monitoring Solvent Exposure Limit Position 1 Position 2 Position 3 Ref: EH 40 1992 10cm above the 10cm above the... -
Page 7: Declaration Of Conformity
Declaration of Conformity UGC2005/2005M/3005/4005/5005 Model: This product complies with the following European Community Directives: 2006/42/EC Machinery Directive The following standard was used to verify compliance with the directives: EN13463-1:2009 Note: Checked requirements of harmonized standards Certified to Atex standards. Certificate number: SIRA 03ATEX5252... - Page 8 Model: UGC2005 Air Input: 40/90 PSI - 2.75/6 Bar Air Consumption: 1/2 CFM: 28/56 L/min Air Input Connection: 1/4” B.S.P Year of manufacturing: 2013/14 Height: 1020mm Width: 440mm Depth: 475mm Weight: 28kg Directive 94/9/EC.Marking: Ex II 2G T6 Certi cate Number:...
-
Page 9: Information Request
Information Request Form Please send information on: (please tick appropriate box) Mini Spray Gun Cleaners Can Crushers Paint Can Washers Paint Can Shakers Brake Washer Parts Washer Solvent Recycler Spares Service Information Other Comments: Please send this information to: Name: Address: Email: Telephone:... -
Page 10: Warranty Conditions
Warranty Conditions UGC2005/UGC2005M/UGC3005/UGC4005/UGC5005 Solvent Based Spray Gun Cleaner Subject to the other Warranty Conditions the Company 1.1 Warrants that upon delivery, and for a period of 12 months from the date of delivery of the spray gun cleaning machine (‘the Machine’), the Machine shall: (a) Be of satisfactory quality within the meaning of the Sale of Goods Act 1979;...
