Alno AEE 100 E Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Dunstesse
AEE 100 E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEE 100 E and is the answer not in the manual?

Questions and answers

Related Manuals for Alno AEE 100 E

Summary of Contents for Alno AEE 100 E

  • Page 1 Dunstesse AEE 100 E...
  • Page 2 Dear Customer, If you follow the recommendations contained in this Instruction Manual, your appliance will give you constant high performance and will remain efficient for many years to come. CONTENTS RECOMMENDATIONS AND SUGGESTIONS CHARACTERISTICS INSTALLATION MAINTENANCE...

  • Page 3: Recommendations And Suggestions

    RECOMMENDATIONS AND SUGGESTIONS INSTALLATION • The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. • The minimum safety distance between the cooker top and the extractor hood is 650 mm. • Check that the mains voltage corresponds to that indicated on the rating plate fixed to the inside of the hood.
  • Page 4 CHARACTERISTICS Dimensions 1000 1000...
  • Page 5 Components Ref. Q.ty Product Components Hood Body, complete with: Controls, Light, Blower, Filters 7.2.1 Telescopic Chimney comprising: Upper Section Lower Section Reducer Flange ø 150-120 mm 14.1 Air Outlet Connection Extension 14.1 Air Outlet Connection Ref. Q.ty Installation Components Hood Connector Support 7.2.1 Upper Chimney Section Fixing Brackets Wall Plugs...

  • Page 6: Installation

    INSTALLATION Wall drilling and bracket fixing 7.2.1 7.2.1 • Rest Bracket 7.1 as shown, 935 mm above the cooker top, taking care that the bracket is level. • Mark the wall at the centres of the holes in the bracket. •...

  • Page 7: Mounting The Hood Body

    Mounting the hood body • Before hooking up the hood body, adjust the 2 screws Vr located on the hood body connection points so that they are at the half way point. • Hook the hood body to the mounted bracket. •...

  • Page 8: Electrical Connection

    ELECTRICAL CONNECTION • Connect the hood to the mains through a two-pole switch having a contact gap of at least 3 mm. • Remove the grease filters (see paragraph Maintenance) being sure that the connector of the feeding cable is correctly inserted in the socket placed on the side of the fan.

  • Page 9: Control Panel

    Control panel Light Switches the lighting system on and off. Motor running led. Motor Switches the extractor motor on and off at low speed. Used to provide a contin- uos and silent air change in the presence of light cooking vapours. Speed Medium speed, suitable for most operating conditions given the optimum treated air flox/noise level ratio.

  • Page 10: Maintenance

    MAINTENANCE Grease filters CLEANING METAL SELF- SUPPORTING GREASE FILTERS • The filters must be cleaned every 2 months of operation, or more frequently for particularly heavy usage, and can be washed in a dishwasher. • Remove the filters one at a time by pushing them towards the back of the group and pulling down at the same time.
  • Page 11 Dir. 89/336/CEE 73/23/CEE 436002475_02 - 041105...
