- Page 1 User Manual Maximum level sensor LD-1 The manufacturer delivers the device complete with the use manual and warranty card. Upon reseipt, chceck the completeness of the product and the documents received WARNING! Please read the instruction manual before use.
- Page 2 Maximum level sensor LD-1 Dear user! Thank you for choosing our product! This manual is a comprehensive workflow for handling the maximum level sensor. Please read it carefully before using the device, strictly follow its recommendations and warnings and have access to it during use. This will prevent accidents and material losses.
-
Page 3: Table Of Contents
Maximum level sensor LD-1 Table of Contents 1. INTENDED USE ................................1 2. SAFETY RULES ................................2 3. TECHNICAL DATA ................................3 4. CONSTRUCTION ................................4 4.1. FRONTAL VIEW ............................... 4 4.2. INTERNAL VIEW ..............................4 5. OPERATING PRINCIPLE ..............................5 6. -
Page 4: Intended Use
Maximum level sensor LD-1 1. INTENDED USE The maximum level sensor LD-1 should be used only to control the maximum state of a given medium in a tank or other vessel. Due to the variety of physical and chemical parameters of the liquid which could be monitored , the material is selected individually by SWIMER specialists. -
Page 5: Safety Rules
Maximum level sensor LD-1 2. SAFETY RULES Depending on the type of liquid stored in the tank, the leakage of which will be monitored by the sensor, when handling the sensor, use appropriate protective clothing and personal protective equipment, in accordance with the manufacturer's safety data sheet. -
Page 6: Technical Data
Maximum level sensor LD-1 3. TECHNICAL DATA The full name of the device Maximum level sensor LD-1 Depth of the driver [mm] Width of the driver [mm] Height of the driver [mm] Diameter of the sensor [mm] Height of the sensor [mm] Weight of the entire device [g] Power [V] 3 x 1,5... -
Page 7: Construction
Maximum level sensor LD-1 4. CONSTRUCTION 4.1. FRONT VIEW Rys. 3. Front view of controller 1 – Controller’s cover 2 – Test button 3 – Diode sygnalizing an alarm in the tank 4 – Batteries chargé diode 5 – Bolts 6 – Maximum level alarm 4.2. -
Page 8: Operating Principle
Maximum level sensor LD-1 5. OPERATING PRINCIPLE The LD-1 maximum level sensor is designed to inform the user when the liquid in the storage tank reaches the maximum value. In order to fulfill its function, it must be placed in the storage tank for a given medium as shown in the figure below (Fig. 5). The maximum level is determined by the manufacturer of the particular vessel or storage vessel. - Page 9 Maximum level sensor LD-1 Then the user has to check by pressing the test button (by pressing for about 5 seconds) whether the device is in working order. The correct operation is confirmed by an acoustic signal and a diode that indicates contact with the liquid, as shown in the figure below.
-
Page 10: Maintenance
Maximum level sensor LD-1 MAINTENANCE Every week: 1. Check the condition of the batteries. In the event of the green LED blinking once, it is recommended to replace the batteries (3x1.5V). Every six months: 1. Test the device by holding down the test button. 2. -
Page 11: Utilization
Maximum level sensor LD-1 7. UTILIZATION Fig. 9. Symbol of the crossed out trash can Products marked with the above symbol (Fig. 9) cannot be disposed of together with household waste and must be delivered to an appropriate collection point of this type in accordance with the applicable regulations. This sign can be found on a sticker (Fig.
