Moisture meter
User manual
MF-S-HTD
Paper Moisture Sensor
Sensor for online moisture measurement of board, cardboard
and panel production
Part #: HM-14560
6% | 456kg/m
78,0°F | 6,1
| -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m
3
Read the user manual before starting any work!
Page 1
| 09m
/s | 4,90Ugl | 1
2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for scigiene MF-S-HTD
Summary of Contents for scigiene MF-S-HTD
- Page 1 Moisture meter User manual MF-S-HTD Paper Moisture Sensor Sensor for online moisture measurement of board, cardboard and panel production Part #: HM-14560 6% | 456kg/m 78,0°F | 6,1 | -27,3td | 0,64aw | 51,9%r.H. | 14,8%abs | 100,4g/m | 09m...
-
Page 2: Overview Of Your Mf-S-Htd Sensor
Overview of your MF-S-HTD Sensor Overview top side Name Installation plate Socket for external sensors (Option) Button with green LED (Reset, Link) USB interface for firmware Update Button with red LED (Status, Adjust) Paper guide rolls Page 2... -
Page 3: Overview Bottom Side
Overview bottom side Name Paper guide rolls Sensor plate ATTENTION Sensitive sensor plate The white sensor surface consists of a thin ceramic plate. It can be damaged by mechanical loads! ► When installing the sensor, remove the provided transport protection as late as possible! Page 3... -
Page 4: Overview Connections
Overview connections Name Modbus TCP connection (optional) Connection for IR temperature sensor Power supply and optional analog output Page 4... -
Page 5: Overview Transport Protection
Overview transport protection Name Transport protection Safety note Page 5... -
Page 6: Table Of Contents
Pin assignment Modbus TCP (option) ..............14 Laying the power supply or transmission line ............14 4) Measurement 15 MF-S-HTD with Modbus TCP option and HumiSenseWare software ..... 15 MF-S-HTD with analogue output option ............... 15 5) Care and maintenance 16 Adjustment of the device .................. - Page 7 Storing the device ......................19 Disposal of the device ....................19 8) Device information 20 EC declaration of conformity ..................20 Technical data ......................... 21 9) Notes 22 Page 7...
-
Page 8: Introduction
1.1 Information on this user manual These user manual enables safe and efficient use of the MF-S-HTD. The user manual is an essential part of the device and must be kept close to the device and be accessible to the user at any time. -
Page 9: For Your Safety
2. For your safety The device complies with the following European directives: • Restriction of Hazardous Substances in Electrical and Electronic Equipment (RoHS) • Electromagnetic compatibility (EMC) The device corresponds to state-of-the-art technology. However, it is still associate with a number of residual hazards. -
Page 10: First Steps
Avoid strong mechanical impacts or loads. • Do not install the device near strong electromagnetic radiations. • Ensure that the paper lies on the paper guide rollers of the MF-S-HTD sensor during operation. • The sensor must always be installed above the paper web. •... -
Page 11: Mechanical Installation
► When installing the sensor, remove the provided transport protection as late as possible! The MF-S-HTD sensor has to be fastened with the mounting plate to the machine. For this, different holes are placed on the mounting plate. Use four screws (M8 or M6) to attach the sensor to the machine. -
Page 12: Sketch Mf-S-Htd
• Then tighten all the nuts again. The contactless infrared temperature sensor has a 10:1 optics. » During the measurement, there must always be paper in the measuring field of the temperature sensor (image 5). 3.5 Sketch MF-S-HTD Page 12... -
Page 13: Pin Assignment Power Supply And Analogue Output (Option)
3.6 Pin assignment power supply and analogue output (option) Cable color Pin No Function Brown Power supply V- (0 VDC) White Power supply V+ (24 VDC) Blue Power output moisture 4 - 20 mA (optional) Black Ground power output & temperature (optional) Grey Power output temperature 4 - 20 mA (optional) -
Page 14: Pin Assignment Modbus Tcp (Option)
3.7 Pin assignment Modbus TCP (option) A 4-pole M12 connector with D-coding (M12-D) is required here. Pin No Function Housing Shielding • A CAT6 or higher type cable is recommended. • Every cable type must be equipped with a shielded M12 round plug D-coded on the sensor side. »... -
Page 15: Measurement
4.2 MF-S-HTD with analogue output option To calculate the water content with the analogue output option, a separate PLC program is required. The value of the MF-S-HTD analogue output is not the water content, it is the internal value of the MF- S-HTD sensor! -
Page 16: Care And Maintenance
5. Care and maintenance Regular cleaning and maintenance will ensure that your device remains in perfect condition as long as possible. ATTENTION Sensitive sensor plate The white sensor surface consists of a thin ceramic plate. This can be destroyed by mechanical pressure! ►... -
Page 17: Cleaning The Device
5.3 Cleaning the device ATTENTION Device damage caused by wet cleaning Water or cleaning products can damage the device if they get into the device. ► Only dry cleaning (compressed air) is recommended. ATTENTION Sensitive sensor plate The white sensor surface consists of a thin ceramic plate. This can be destroyed by mechanical pressure! ►... -
Page 18: Faults
6. Faults If the following actions do not eliminate the faults or if other faults not listed here appear, please contact Scigiene. Fault Cause Remedy Incorrect Paper or cardboard temperature Use material with a temperature measurement beyond the application range: above 0 °C or below... -
Page 19: Storage And Disposal
7. Storage and disposal 7.1 Storing the device Store the device as follows: • Store with the original transport cover. • Do not store outdoors. • Store dry and dust-free. • Avoid mechanical shocks and impacts. • Storage temperature: -20 °C to +70 °C 7.2 Disposal of the device Devices marked with this symbol are regulated by the European Directive 2012/19/EU of the European Parliament and the Council of 4 July 2012 relating... -
Page 20: Device Information
8. Device information 8.1 EC declaration of conformity DECLARATION OF CONFORMITY Name/ Address of manufacturer: Max-Schaller-Straße 99/A – 8181 St. Ruprecht Product designation: Paper Moisture Sensor Type designation: MF -S -HTD The designated product is in conformity with the European directives: 2014/30/EU EMV –... -
Page 21: Technical Data
8.2 Technical data Measuring range moisture 1 % to 20 % water content (depending on material) Measuring range temperature 0 °C to +100 °C Paper grammage 200 to 2000 g/m² Paper temperature 0 °C to +100 °C Operating temperature automatic Environmental temperature 0 °C to +70 °C Storage temperature... - Page 22 9. Notes Page 22...
- Page 23 Page 23...
