GEX Corporation P4405 Product Specifications And Usage Information

DESCRIPTION

A baseplate designed for easy installation inside of the Thermo Scientific GENESYS 30 Spectrophotometer. The baseplate allows
for use of swappable dosimeter holders: B3 DoseStix, B3 WINdose, FWT, and/or other 1cm square film dosimeters. The holders
are 'hot-swappable' for insertion in and out of the baseplate without the use of any tools, and requires no additional action
once installed.

APPLICATION

For use in conjunction with the GENESYS 30 Spectrophotometer to measure the optical absorbance of dosimeters.

SPECIFICATIONS

Physical Specifications:
GEX Part
Product Description
No.
Hot-swappable Baseplate
P4405
with beam tubes
P4410 DoseStix Holder
WINdose Holder
• Receiver component
P4420
• Hinged Holder
component
Holders: Nylatron
Material
Baseplate: Anodized aluminum
Grey
Color
Cardboard box and wrapped in bulk packaging to provide protection and prevent movement inside the
Packaging
product box during transport.

Calibration:

Not applicable.

Maintenance:

The GENESYS 30 Spectrophotometer and holders should be installed in a location where they will not be exposed to excessive
dust or other particulate matter. The holders should be cleaned as part of a preventive maintenance program at a frequency
dependent on the level of cleanliness of the area. Any accumulated particulate can be removed using compressed air. The
holders should be cleaned annually at minimum, and physically taken apart and cleaned with a lint-free wipe and isopropyl
alcohol.
Avoid dropping or physically damaging the holders. Although they are made of very hard plastic, they can still become
damaged. If damage occurs, verify performance and consult GEX Customer Service.

Storage:

There are no environmental storage requirements.
100-168 Rev. B
Product Specifications and Usage Information
GENESYS 30 Dosimeter Holder System
Product Dimensions
14.5cm (L) x 11.2cm (W) x 1.3cm (H)
(5.7"L x 4.4"W x 0.5"H)
30.0mm (L) x 50.0mm (W) x 60.0mm (H)
(1.2" L x 2.0" W x 2.4" H)
Receiver Component:
• 41.0mm (L) x 55.0mm (W) x 44.0mm
(H) (1.6" L x 2.2" W x 1.7" H)
Hinged Holder component:
• Outer Dimensions: 2.900" (L) x
0.500" (W) x 0.525" (H) (±0.005")
• Inner Window Pocket: 0.414" (W) x
0.413" (L) (±0.005")
• Slot Dimensions: 1.330" (L) x
0.200" (W) (±0.005")
Aperture Dimensions: 0.315"
•
±0.002"
Release Date: 10/29/18
P4405, P4410, & P4420
Packaging Dimensions
12.7 cm x 12.7 cm x 12.7cm
(13" x 10" x 2")
12.7 cm x 12.7 cm x 12.7cm
(5" x 5" x 5")
12.7 cm x 12.7 cm x 12.7cm
(5" x 5" x 5")
Page 1 of 5
Product
Weight
0.6 kg
(1.3 lbs.)
0.06 kg
(0.14 lb.)
0.08 kg
(0.18 lb.)
