SmartRoom

光照监测器02型

产品使用说明书

出版号：2015-0610.V01

Table of Contents

Need help?

Do you have a question about the SR-ZSSWBPW-AL-02 and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartRoom SR-ZSSWBPW-AL-02

Page 2 欢迎您使用SmartRoom光照监测器02型产品说明书 ● 是南京物联传感技术有限公司的注册商标。本手册中提到的所有其他产品名称或商标是其各自品牌所有者的商标或注册商标。 ●使用前请您认真阅读产品使用说明书，确保正确地、安全地使用。 ●SmartRoom光照监测器02型产品（以下简称“本产品”）为南京物联传感技术有限公司（以下简称“我司”）出品的智能家居产品。本产品需要与智能家居相应 APP 客户端同步使用，并须使用本产品自带的配件，如您未正确地安装及使用本产品，而造成的损失，我司将不承担任何责任。 ●我司随时可能对本说明书中的产品信息进行更新，恕不另行通知。请您及时关注我司资讯，并下载最新版的APP客户端。 ●未经我司的明确书面许可，任何个人及企业不得复制本说明书的全部或部分内容，不得使用我司注册商标。对非法使用我司商标的行为，我司将依法追究行为人及企业法律责任。 ●欢迎您登录我司官网www.wulian.cc，了解更多智能家居产品信息。...
Page 3 产品特点 ● 支持IEEE 802.15.4 ZigBee/SmartRoom协议。 ●监测周围环境光强度，并将相关数据同步传输至移动智能终端，用户可根据数值对相关联动设备进行设置开启或关闭，如自动窗帘、遮阳篷、墙面开关等。 ●本产品采用无线设计，便于安装，占用面积小。 ●消耗功率低，节能环保。...
Page 4 产品参数通信协议 IEEE 802.15.4 ZigBee/SmartRoom 天线类型 PCB天线电源参数 DC 3V 电池类型 CR2*1 待机电流（µA）抗白光干扰 ≥8000LUX 有效接收角度 ±60° 光照流明值范围 1-65535 lx 材质颜色 PC，白色外形尺寸（直径×厚度，mm） 64× 32 净重（g）阻燃等级 UL94 V-2 工作环境温湿度 -10℃～+45℃/≤95%RH（不凝结）...
Page 5 装箱清单光照监测器主体*1 底座*1 膨胀管 + 自攻螺丝*2 说明书保修卡 CR2电池*1 说明书*1 保修卡*1...
Page 6 功能图示多功能按键系统指示灯磁铁电池盒光照接收区主体正面主体背面底座...
Page 7 安装步骤 1. 本产品可支持吸顶、墙面安装，还可直接放置在固定平台上使用；说明：建议优先选择墙面安装或放置在固定平台使用，并调整角度，将光照接收区对着有效光源。吸顶安装墙面安装放置使用...
Page 8 2. 采用吸顶、墙面安装方式时，请先用两颗膨胀螺丝将底座固定，如图所示；底座膨胀管螺丝墙面&天花板...
Page 9 3.打开电池盖，装入一粒CR2电池后盖上电池盖，将探测器主体直接吸扣在底座上，并调整至合适角度，安装完成。注：安装前，请先进行联网设置。 CR2电池电池盖墙面&天花板主体背面 ① ②...
Page 10 联网设置设置前，请确认无线网关（需另外购买）ZigBee网络正常工作。同时，请确认本产品处于通电状态，且处于网关的有效通信距离内。 1、加网设置快击【多功能按键】4次，申请加入ZigBee网络，搜索网络中，【系统指示灯】闪烁；成功加入ZigBee网络后，【系统指示灯】长亮2秒后熄灭。快击4次（单次快击时间不超过1秒）搜索网络时，闪烁；成功入网后，长亮2秒熄灭主体正面主体背面...
Page 11 2、退网设置长按【多功能按键】10秒，【系统指示灯】闪烁4次后熄灭，恢复为出厂设置，同时退出ZigBee网络。长按10秒闪烁4 次后熄灭主体正面主体背面...
Page 12 注意事项 ●安装时为了保证监测准确性，请将光照接收区对着有效光源。 ●本产品切勿跌落、撞击，以免损坏内部器件。 ●本产品应安装在干燥清洁的地方，防止内部元器件受潮而影响产品使用效果。 ●请勿擅自拆卸或改装本产品及其配件。 ●若本产品发生故障，非专业人员不得打开本产品，应送到当地维修点进行维修，或直接与我司客服联系。...
Page 13 故障诊断 1、Q：本产品申请加网时，无法加入网络，应该如何处理？ A：请确认网关是否处于允许加网状态，本产品是否位于网关有效的通信范围内，电池是否正常供电。 2、Q：当光照强度发生变化时，智能终端上未接收到反馈信息？ A：请确认本产品是否加入网关，APP客户端是否在后台运行。注：如果是Android版客户端，请确认您的客户端已经在后台运行；如果是ios版客户端，请在“设置>通知”中开启消息通知功能。 3、Q：客户使用APP客户端管理联网设备时出现频繁掉线现象，应该如何处理？ A：初次安装时，请确认本产品周围是否受到信号干扰，请不要将本产品安装在网关的通信范围外。...
Page 14 订购信息 SmartRoom光照监测器02型产品名称产品型号 SR-ZSSWBPW-AL-02 材质/颜色 PC，白色货号 SRPN140915001...
Page 15 软件下载下载方式一：请扫描产品包装盒上的二维码，下载软件客户端。下载方式二：官网下载：http://www.wulian.cc/service.shtml 温馨提示：初次使用时，请先安装APP客户端，并仔细阅读产品说明书；请时常关注我司资讯，以便及时更新。...
Page 16 南京市雨花台区凤集大道15号创业创新城-北柚11栋邮编：210039 服务热线：400-928-9288 官网：www.wulian.cc...
Page 17 The company passed the ISO9001: 2008 quality SmartRoom management system standard Smart Light Sensor User Manual ©Nanjing IOT Sensor Technology Co., Ltd. Publication Number: 2015-0610.V01...
Page 18 Welcome to Use Smart Light Sensor User Manual ● is the registered trademark of Nanjing IOT Sensor Technology Co., Ltd. All the other trademarks and registered trademarks mentioned in this manual are trademarks or registered trademarks of their respective owners. ●Please read this manual carefully for the proper use of this product.
Page 19 Features ● Support new IEEE 802.15.4 ZigBee/SmartRoom protocol. ● Monitor light intensity of the surrounding environment, and transfer related data to smart mobile terminals. Users can set up related linkage devices such as automatic curtain, awning, and wall switch to switch on/off them as per needs.
Page 20: Product Parameter
Product Parameter IEEE 802.15.4 ZigBee/SmartRoom Communication Protocol PCB Antenna Antenna Type DC 3V Power Parameter CR2*1 Battery Type Standby Current Resistance to White Light Interference ≥8000LUX Effective Receiving Angle ± 60° Light Luminous Flux Range 1-65535 lx Material & Color PC，White...
Page 21: Package List
Package List Main Body of Smart Light Sensor *1 Base*1 (Expansion Pipe +Self-tapping Screw)*2 Guarantee Manual Card CR2 Battery *1 Manual *1 Guarantee Card*1...
Page 22: Function Illustration
Function Illustration Multi-Functional Key System Indicator Magnet Battery Box Light Receiving Zone Base Front Side of Main Body Back Side of Main Body...
Page 23: Installation Steps
Installation Steps 1. This product supports ceiling mounting, wall mounting, and placing it on the fixed flat surface. Notes: Wall mounting or placing it on the fixed flat surface is a priority. Adjust angle, and aim light receiving zone at effective light source. Ceiling Mounting Wall Mounting Place on the fixed flat...
Page 24 2. When adopting ceiling mounting and wall mounting, please fix base via 2* setscrew as per below illustration. Base Expansion Pipe Screw Wall & Ceiling...
Page 25 3. Open battery cover to load 1* CR2 battery, and then close battery cover. Attach main body of sensor to base, and adjust angle to finish installation. Notes: Please join the network before installation. CR2 Battery Battery Cover Wall & Ceiling Back Side of Main Body ①...
Page 26: Networking Setting
Networking Setting Before setting, please make sure the gateway (additional purchase) works normally. Ensure that power is supplied to this product, and it is within the effective communication range of the gateway. 1. Add ZigBee Network Quickly click [Multi-Functional Key] 4 times to apply for joining ZigBee network. While searching networking, [System Indicator] is flashing.
Page 27 2. Exit ZigBee Network Long press [Multi-Functional Key] 10 seconds. [System Indicator] flashes 4 times, and then goes out. This product will restore to factory settings, and exit ZigBee network. Long press [Multi-Functional Key] [System Indicator] 10 seconds. flashes 4 times, and then goes out.
Page 28 Cautions ●In order to guarantee monitoring accuracy, please aim light receiving zone at effective light source. ●Avoid fall or sever collision for this product to prevent from damage of internal components. ●This product should be installed in dry and clean place to prevent inner component from dampness, otherwise its working performance may be affected.
Page 29: Troubleshooting
Trouble Shooting 1. Q: How to deal with it when failed to join ZigBee network? A: Please confirm gateway is allowed to add network. Make sure this product is within effective communication range, and battery provides normal power supply. 2. Q: How to deal with it when light intensity is changed, feedback information is not received on the smart home APP? A: Please check if this product is added to the gateway, and if smart home APP runs in background?
Page 30: Purchasing Information
Purchasing Information Product Name Smart Light Sensor Model SR-ZSSWBPW-AL-02 Material/Color PC，White Item No. SRPN140915001...
Page 31: Software Download
Option A: Download the latest smart APP by scanning QR code on the package box of this product. Option B: iOS user can download the APP by searching "Wulian SmartRoom" in "APP Store". Android user can download the APP by searching "Wulian SmartRoom" in "Google Play".
Page 32 Building 11, No.15, Fengji Road, Yuhuatai District, Nanjing (P. C.: 210039) Email: overseas@wuliangroup.com Service Hotline: 400-889-2891 www.wulian.cc/english...
