Page 1: Table Of Contents
ORANGE JUICER Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWINGS Page ELECTRIC CIRCUIT SCHEMA Page...
Page 2: Ageneral Information
ORANGE JUICER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.
Page 3: A1 Product Description
Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *Professional Orange Juicers ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) OPE24O 420x578x910 470x620x960 UGOPE24O 470x578x800 520x620x850 OPE24E 420x578x910 470x620x960...
Page 4: A3 Transportation
ORANGE JUICER TRANSPORTATION *This appliance can not be moved by hand from area to area.It must be moved on pallet with Kasap Tip Dik Buzdolapları forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.
Page 5: Csafety Instructions
ORANGE JUICER Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...
Page 6: Doperation P Age
ORANGE JUICER OPERATION *Control Panel; Kasap Tip Dik Buzdolapları A : ON / OFF *Operating;  Before operating the appliance,clean the outer surface,reamer balls and residue filter with moist cloth.  In order to operate the appliance plug in.  If you dont place the appliance’s front safety guard,it is not operated due to having magnetic sensor.
Page 7: Ecleaning & Maintenance
ORANGE JUICER Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE  CLEANING AND MAINTENANCE AFTER EVERY USE  Clean the residue filter under reamer balls after every use.  Always turn off the appliance and disconnect from the power supply before cleaning. ...
Page 8: Ftroubleshooting
ORANGE JUICER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check the launcher. THE APPLIANCE IS NOISY If the motor is noisy,stop it and call authorized service. The appliance can stop due to low voltage.In this situation check the THE APPLIANCE STOPPED...
Page 9: Gspare Part List- Exploding Drawings
ORANGE JUICER Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS OPE24E OPE24O...
Page 10 ORANGE JUICER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : OPE24E Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE Y.OPE24E.001 WIRE CAGE TOP PLASTIC (GRAY) Y.OPE24E.002 UPPER DRUM PLASTIC Y.OPE24E.003 TOP PLASTIC SHEET Y.OPE24E.004 BEARING SCREW PLASTIC Y.OPE24E.005 DRUM BEARING PLASTIC Y.OPE24E.006 DRUM BUSHING Y.OPE24E.007...
Page 11 ORANGE JUICER Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : OPE24O PRODUCT NAME P.CODE Y.OPE24O.001 WIRE CAGE TOP PLASTIC (ORANGE) Y.OPE24O.002 UPPER DRUM PLASTIC Y.OPE24O.003 TOP PLASTIC SHEET Y.OPE24O.004 BEARING SCREW PLASTIC Y.OPE24O.005 DRUM BEARING PLASTIC Y.OPE24O.006...
Page 12 ORANGE JUICER SPARE PART LIST- EXPLODING DRAWINGS Kasap Tip Dik Buzdolapları UGOPE24E UGOPE24O...
Page 13 ORANGE JUICER Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE : UGOPE24O PRODUCT NAME P.CODE BOTTOM STAND TOP PLASTIC Y.UGOPE24O.001 TOP SUPPORT SHEET Y.UGOPE24O.002 TOP SUPPORT CENTER SHEET Y.UGOPE24O.003 CHASSIS Y.UGOPE24O.004 COVER INSIDE SHEET Y.UGOPE24O.005 BOTTOM STAND COVER PLASTIC (ORANGE) Y.UGOPE24O.006 PLAYING WHEEL WITHOUT BRAKE Y.UGOPE24O.007...
Page 14: Helectric Circuit Schema
ORANGE JUICER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları C1 Contactor Lower Motor Magnetic Safety Lower Motor 0,37 Switch Large Contactor Sensor KW-1500 rpm Lighted...

This manual is also suitable for:

Ugope24o Ope24e Ugope24e
