Sonardyne 8315 iWAND User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

UM-8315
User Manual for the
Type 8315 iWAND
Issue B Rev 1
Date of Issue: 27 May 2014
Sonardyne International Limited
Blackbushe Business Park
Yateley, Hampshire
GU46 6GD United Kingdom
920-0105
T. +44 (0) 1252 872288
F. +44 (0) 1252 876100
E. support@sonardyne.com
W. www.sonardyne.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8315 iWAND and is the answer not in the manual?

Questions and answers

Summary of Contents for Sonardyne 8315 iWAND

  • Page 1 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Date of Issue: 27 May 2014 Sonardyne International Limited T. +44 (0) 1252 872288 Blackbushe Business Park F. +44 (0) 1252 876100 Yateley, Hampshire E. support@sonardyne.com GU46 6GD United Kingdom W.
  • Page 2 Protected by UK patent no. 2415113, US patent no. 8,139,442, and other patents internationally. 6G and Sonardyne Wideband are UK registered trademarks of Sonardyne International Limited. All rights reserved. No part of this document shall be reproduced, stored in a retrieval system or transmitted by any means, electronic, mechanical, photocopying, recording, or otherwise, or translated into any language without the written permission of Sonardyne International Limited.
  • Page 3 Contacting the Sonardyne Support Team 24-hour Emergency Telephone Helpline: +44 (0) 1252 877600 The Sonardyne 24-hour helpline is answered at the UK Headquarters during normal office hours (08:00 to 17:00). Outside these hours, your call is automatically transferred to an agency, which logs the details of your emergency and alerts the appropriate Sonardyne personnel.

  • Page 4: Table Of Contents

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Contents Section 1 Introduction ........................1 Scope of this Manual ......................1 Purpose of this Manual ......................1 Related Publications ......................1 Conventions ........................... 1 Section 2 – Safety ......................... 2 Introduction ..........................
  • Page 5 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Prerequisites for Operation ....................31 Ping Check .......................... 32 Quick Check ........................34 5.5.1 Acoustic Settings ....................35 5.5.2 Battery Status ......................35 5.5.3 Firmware Information ..................... 36 5.5.4...
  • Page 6 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 11.1.3 Battery Life ......................70 11.1.4 Environmental ......................70 11.1.5 Firmware Requirements ..................71 Appendix A – Firmware History record ..................72 Firmware History Record ..................... 72 Appendix B – Software Copyright / License / Warranty ............73 Appendix C –...
  • Page 7 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 4-24 – Break Key on Keyboard ..................21 Figure 4-25 – iWAND Serial Output After a <BREAK> ..............21 Figure 4-26 – iWAND Information ....................21 Figure 4-27 – Time Information View .................... 22 Figure 4-28 –...
  • Page 8 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-17 – Test Sonsors Menu with Lodestar Present .............. 38 Figure 5-18 – Lodestar ON interrogation ..................38 Figure 5-19 – Lodestar ON Completion ..................38 Figure 5-20 – Latitude Configuration option for Lodestar .............. 39 Figure 5-21 –...
  • Page 9 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-53 – Get Configuration Sequence Confirm ..............52 Figure 5-54 – Sensor Test Request ....................52 Figure 5-55 – All Sensors View ..................... 53 Figure 5-56 – Set Configuration Sequence Success ..............53 Figure 5-57 –...
  • Page 10 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Amendment History The amendment history records all amendments and additions made to this manual. Issue Revision Date Comments Section Page 07/03/13 Initial Issue ECN12223 Inclusion of Firmware 21/06/13 Upgrade instructions.

  • Page 11: Section 1 Introduction

    Issue B Rev 1 Section 1 Introduction Scope of this Manual This User Manual describes the safe installation, operation and maintenance of the 8315 iWAND. The information and procedures within this manual are based on Sonardyne’s experience and knowledge. To make sure the safety of the installer and operator is maintained it is important that all Warnings, Cautions and Safety Section in this manual, and the Warnings, Cautions and Safety Section of any additional manuals are read and understood.

  • Page 12: Section 2 - Safety

    Section 2 – Safety Introduction The 8315 iWAND contains no user serviceable parts. Under no circumstances should the plastic housing be opened – any repairs are return to base. It is recommended the operator complies with the Health and Safety Regulations applicable to the vessel and the region before operating this equipment.

  • Page 13: Section 3 - Technical Description

    Section 3 – Technical Description Introduction The Type 8315 iWAND (iWAND) is a handheld multiband test unit for acoustic testing and configuration of Sonardyne 6G equipment. The iWAND utilizes Sonardyne 6G Discovery to identify the unit under test (UUT) with a simple one-touch operation without knowledge of the acoustic address or frequency band.

  • Page 14: Communications

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 3.2.2 Communications The iWAND can communicate serially via either RS232, half-duplex RS485, Bluetooth or USB. The iWAND 6G Configurator software will automatically identify the iWAND and establish a link to it. In addition to PC communication, the 9-way ‘D’...

  • Page 15: Figure 3-3 - Scrolling Displays

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 For any menus or table displays that are too long to fit on the screen a direction indicator icon is displayed. The UP and DOWN arrow keys can be used to scroll the display.

  • Page 16: Transducer Connector

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 The screen rotation control allows the screen to rotate when the iWAND orientation is changed. The internal accelerometers are used to detect the orientation of the unit and rotate the screen accordingly to make the display easier to read.

  • Page 17: End-Cap Connector Cover

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 3.2.7 End-cap Connector Cover The rubber bung tethered to the end-cap must be fitted whenever the connectors are not in use. Any internal connector covers should also be fitted. It is critical the connectors are protected as much as possible for both direct splash and moist air.
  • Page 18 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Each time a button is pressed while the screen is on or the orientation of the unit is changed, the screen-on timer is reset so the screen will stay on for the configured time after this event. The iWAND can be manually put into Idle Mode by holding the ENT button down for more than 1 second (but less than 5 seconds or the unit will enter Sleep Mode).

  • Page 19: Section 4 - Connection To The Iwand

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Section 4 – Connection to the iWAND Introduction The iWAND is supplied in a transit case containing all accessories including charging equipment (with international plug adapters) and Bluetooth dongle. Before operating the iWAND it must first be fully charged and the UTC time must be set.

  • Page 20: Connecting To The Iwand

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 If the GPS symbol is not present it can be enabled by scrolling to the iWAND Setup > Power Saving > GPS Enable. Figure 4-3 – GPS Enabled / Disabled Make sure the iWAND has a clear view of the sky.

  • Page 21: Figure 4-4 - Enabling Bluetooth

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 NOTE When possible the Bluetooth dongle shipped with the iWAND should be used. To use the Bluetooth interface on the iWAND it must be turned on from the menu system iWAND Setup >...

  • Page 22: Figure 4-6 - Windows 7 Control Panel

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.4.1.2 Adding the iWAND to the Computer via Bluetooth Windows 7 With Bluetooth on the iWAND enabled as outlined in Section 4.4.1 and the Bluetooth dongle installed as in Section 4.4.1.1 the iWAND is ready to install.

  • Page 23: Figure 4-8 - Bluetooth Device Added

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 If multiple iWANDs are detected the UID is printed on the label on the back of the unit or can be seen from the menu item iWAND Setup > iWAND Information.

  • Page 24: Figure 4-10 - Devices And Printers

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 4-10. Click on the Devices and Printers link. Figure 4-10 – Devices and Printers Refer to Figure 4-11. Select the iWAND on the Devices and Printers window.

  • Page 25: Figure 4-12 - Iwand Bluetooth Port Properties

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 4-12. The COM port assigned to the iWAND will be shown on the Hardware tab. Figure 4-12 – iWAND Bluetooth Port Properties Refer to Figure 4-13. If no COM port is assigned make sure the Serial Port (SPP) option is selected on the Services tab.

  • Page 26: Usb

    Windows XP is not currently supported for Bluetooth connection. 4.4.2 When installed, the USB interface on the iWAND will appear as a virtual COM port. The driver is supplied on the Sonardyne CDROM (920-2004) in the \Drivers directory. 4.4.2.1 Adding the iWAND to the Computer via USB The following steps show the installation sequence for Windows 7.

  • Page 27: Figure 4-16 - Iwand Driver Installation

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 4-16. In Device Manager, from the Other devices drop-down list select the iWAND. Figure 4-16 – iWAND Driver Installation Right-click on the iWAND device and select Update Driver Software….

  • Page 28: Figure 4-18 - Usb Driver Location

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 4-18. Click the Browse button and locate the Drivers directory on the supplied Sonardyne CDROM 920-2004. Figure 4-18 – USB Driver Location Refer to Figure 4-19. Windows will locate the correct drivers and prompt for confirmation.

  • Page 29: Figure 4-20 - Usb Driver Installation Complete

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 4-20. On successful completion of the driver installation an Update Driver Software window will appear. Figure 4-20 – USB Driver Installation Complete Refer to Figure 4-21. Once installed the iWAND will appear as a new COM port on the computer.

  • Page 30: Rs232/Rs485 Connection

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 The iWAND should be able to communicate with most terminal programs (e.g. HyperTeminal). NOTE When connected, the serial settings (baud rate, stop bits etc.) are not important so the default settings can be used.

  • Page 31: Iwand Setup

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 In HyperTerminal a <BREAK> can be sent by holding CTRL and pressing the Break key. Figure 4-24 – Break Key on Keyboard The baud rate configured for P0 (port 0) is set at the default 9600 baud BR9600. P1 (port 1) is assigned to the USB interface –...

  • Page 32: Time Information

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.2 Time Information The time information screen shows the time source used by the iWAND. In the best case the unit will be in view of satellites and updating – this will be indicated by a time source of GPS 1PPS and the Last Synchronized time will match the current time.

  • Page 33: Figure 4-28 - Colour Scheme - Standard

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.4.3 Colour Scheme The iWAND display colour scheme can be changed. To improve visibility in certain lighting conditions it may be beneficial to switch to a high-contrast colour mode. The Standard scheme is recommended for most situations.

  • Page 34: Power Saving

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.5 Power Saving 4.5.5.1 Screen-On Time The Screen-on Time control determines how long the iWAND will spend in Normal Mode before switching the display off and entering Idle Mode. The shorter the duration the longer the battery will last for.

  • Page 35: Discovery Options

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.5.3 Turn-On Time The length of time the iWAND spends on before entering the Sleep Mode is configured from this menu. To configure the Turn-on Time: iWAND Setup > Power Saving > Power On Time – the shorter this period the longer the battery life.

  • Page 36: Figure 4-34 - Lmf, Mf And Hmf Bands

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.6.2 LMF Band, MF Band, HMF Band These options allow the individual frequency bands used in the 6G Discovery process at the beginning of the ‘Quick Check’, ‘Get Configuration’ and ‘Set Configuration’ sequences to be enabled or disabled.

  • Page 37: Abop Mode

    4.5.7 ABOP Mode When communicating with Sonardyne 6G BOP devices, ABOP mode needs to be activated so the correct wakeup and 6G Discovery signals are used. To access the menu, click iWAND Setup > ABOP Mode. To enable ABOP mode, select the Enable option and press the ENT key. The word ABOP will appear in the title bar as shown in Figure 4-37 until ABOP mode is disabled.

  • Page 38: Transponder Mode

    Transponder Mode allows the iWAND to behave as a transponder. It can therefore be used to test an external Sonardyne 6G transceiver. The current acoustic settings of the iWAND are shown on the display. These values can be used in conjunction with the acoustic test mode in the 6G Configurator software or directly with direct 6G commands to the transceiver.

  • Page 39: Accessories

    Issue B Rev 1 NOTE The transmit power for the iWAND is significantly lower than a standard Sonardyne Transponder. It will only operate at short range in a quiet environment for tank testing applications, or with direct transducer contact when used in air.

  • Page 40: Figure 4-42 - Gps Status View

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 4.5.9.2 GPS Accessories The GPS Status view provides a simple diagnostic view of how well the iWAND GPS receiver is receiving satellite signals. The display shows elevation and azimuth with the received signal strength of each satellite being tracked.

  • Page 41: Section 5 - Iwand Operation

    The BACK arrow key will return to the previous menu until the home screen is reached Prerequisites for Operation The first four menu options Ping Check, Quick Check, Get Configuration and Set Configuration all begin with a Sonardyne 6G Discovery operation to identify the instrument being communicated with. NOTE As the WSM6 is a tone interrogation transponder it DOES NOT support 6G Discovery –...

  • Page 42: Ping Check

    If the battery is too depleted the iWAND will display a Battery Too Low message and will not continue. The battery on the 6G instrument must be a genuine Sonardyne 6G battery pack. If this is not the case the 6G instrument will only respond to a very limited command set. The iWAND will display a Battery Authentication Error message and will not continue.

  • Page 43: Figure 5-4 - Ping Check Discovering

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-4 – Ping Check Discovering Refer to Figure 5-5. Once the instrument has been discovered it will be interrogated. Figure 5-5 – Ping Check Interrogating Refer to Figure 5-6. Following a successful interrogation the basic status of the instrument will be displayed.

  • Page 44: Quick Check

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Quick Check This menu leads to all of the standalone test options. It includes functions to view acoustic settings, battery status, sensor measurements and a number of other operations to view configuration and status of the instrument.

  • Page 45: Acoustic Settings

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-9 – Quick Check Menu Figure 5-10 – Instrument Interrogation 5.5.1 Acoustic Settings The Acoustic Settings screen shows the acoustic configuration of the instrument. The UID, Functionality level, Band and Transducer are fixed for the instrument – the remaining parameters can be configured with the iWAND 6G Configurator software.

  • Page 46: Firmware Information

    Figure 5-12 – Battery Status View 5.5.3 Firmware Information The Firmware Information screen shows the firmware version of the software inside the instrument. This may be required when contacting Sonardyne customer support. Figure 5-13 – Firmware Information View 5.5.4 View Sensors The View Sensors screen lists all sensors available and fitted on the instrument.

  • Page 47: Figure 5-15 - All Sensors View

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Selecting the All Sensors option shows the current measurement of each of the sensors available on the instrument. Figure 5-15 – All Sensors View The colour of the sensor value indicates the error status of the measurement: •...

  • Page 48: Lodestar Support

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 5.5.5 Lodestar Support 5.5.5.1 Power Control If an internal Lodestar is detected, extra menu options will appear to allow it to be turned on or off. Figure 5-17 shows an example with a Lodestar present.

  • Page 49: Figure 5-20 - Latitude Configuration Option For Lodestar

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 5.5.5.2 Latitude Configuation If a Lodestar is detected, Latitude Config appears on the Quick Check menu to configure the latitude – this is required for correct operation. The internal GPS of the iWAND is used to download the current latitude into the instrument.

  • Page 50: Figure 5-22 - Ready To Acoustically Configure

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-22. When the GPS fix has been achieved, Ready to Configure will display and the iWAND is ready to acoustically configure the latitude into the instrument.

  • Page 51: Acoustic Check

    In the Acoustic Check a transfer in both directions (from iWAND to the instrument and a return from the instrument to the iWAND) will occur, with the acoustic quality parameters being displayed. This may be requested when dealing with Sonardyne customer support. Figure 5-25 – Acoustic Check View...

  • Page 52: Figure 5-26 - Hpr Channel Configured With The Iwand 6G Configurator Software

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 5.5.6.1 HPR Check If HPR is enabled on the instrument and the iWAND has been purchased with the required functionality level, an option will be available to test the HPR.

  • Page 53: Test Release

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 5.5.7 Test Release If a release mechanism is fitted to the instrument, the menu will allow a functional test to be carried out. The test will start with the menu selecting the current state the release mechanism is in (open or closed).

  • Page 54: Acoustic Terminal

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 5.5.8 Acoustic Terminal For advanced users the Acoustic Terminal allows a raw view the internal 6G command that communicates between the iWAND and the instrument. Figure 5-32 – Acoustic Terminal Test Menu The predefined commands are selected from the menu and will be issued to the instrument and the replies shown.

  • Page 55: Get Configuration

    The Get Configuration sequence starts with a Sonardyne 6G Discovery operation to identify the instrument. If the prerequisites for operation have (refer to Section 5.3) been met the sequence will proceed to automatically collect all information required.

  • Page 56: Figure 5-36 - Start Of The Get Configuration Process

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-36. To begin the sequence press ENT. Figure 5-36 – Start of the Get Configuration Process Refer to Figure 5-37. The Discovering sequence will begin.

  • Page 57: Figure 5-39 - Get Configuration Sequence Confirm

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-39. The Get Configuration sequence will confirm if a release mechanism is fitted and it a test is required. Figure 5-39 – Get Configuration Sequence Confirm If a release mechanism test is to be carried out refer to section 5.7.1 –...

  • Page 58: Release Test

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-42. On completion of the Get Configuration sequence the iWAND will display the address of the unit and the configuration was successful. Figure 5-42 – Get Configuration Sequence Success At the end of the sequence the user will be prompted to run a release mechanism test (to test the release mechanism if one is present) and a sensor test (if the unit has any sensors).

  • Page 59: Figure 5-45 - Testing The Release - State Following Activation

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-45 – Testing the Release – State Following Activation Figure 5-46 – Testing the Release – Confirm Release Operation It is the user’s decision as to what state the release is left in and how it is exercised. After opening/closing the release and selecting the Finish Test option the dialogue box will request confirmation the release has operated.

  • Page 60: Sensors Check

    6G instrument to be configured. Configurations for multiple 6G instruments can be held by the iWAND at the same time. As outlined in Section 5.3 a Sonardyne 6G Discovery operation is performed at the start of the Set Configuration sequence. As this operation automatically identifies the 6G instrument, the Set Configuration process will automatically download the correct settings for the instrument without user intervention.

  • Page 61: Figure 5-49 - Hold The Iwand Against The Instrument

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-49. Make sure the iWAND aerial is held firmly against the transducer of the unit. Figure 5-49 – Hold the iWAND Against the Instrument Refer to Figure 5-50. To begin the configuration sequence press ENT.

  • Page 62: Figure 5-52 - Get Configuration Sequence Found

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-52 – Get Configuration Sequence Found Refer to Figure 5-53. The Set Configuration sequence will confirm if a release mechanism is fitted and it a test is required.

  • Page 63: Figure 5-55 - All Sensors View

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-55. If a Sensor Test is required all fitted senses will be tested and the current measurements of each sensor will be displayed. Figure 5-55 – All Sensors View Refer to Figure 5-56.

  • Page 64: Tone Testing

    The channel the WSM6 has been configured to must be known. As standard the iWAND allows acoustic testing of WSM6 in Sonardyne Wideband V1, Wideband V2 or Sonardyne tone modes. If the iWAND has been purchased with HPR functionality it can be used to test the WSM6 in HPR300 and HPR400 modes.

  • Page 65: Figure 5-60 - Wideband Reply Address Selection

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 5-60. On entry the interrogation channel selector will be selected. The UP and DOWN keypad keys allow the channel to be changed. Refer to Figure 5-60. Select the appropriate interrogate channel and press ENT to move onto the reply address selector.

  • Page 66: Figure 5-62 - Test Transmitting State

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 5-62 – Test Transmitting State Figure 5-63 – Nothing Received from Transponder Figure 5-64 – Response Received Section 5 27 May 2014...

  • Page 67: Figure 5-65 - Sonardyne Tone Mode

    5.9.1.2 Sonardyne Tone Mode The operation of Sonardyne Tone mode is identical to Sonardyne Wideband mode except the selection of the reply channel is a Sonardyne Tone rather than a Sonardyne Wideband address. Figure 5-65 – Sonardyne Tone Mode 5.9.1.3 HPR300 / HPR400 mode In HPR300 or HPR400 mode only the interrogate channel is configured –...

  • Page 68: Section 6 - Maintenance

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Section 6 – Maintenance Introduction CAUTION Equipment Damage. There are NO user serviceable parts inside the iWAND. The plastic housing should not be opened under any circumstances as this will damage the integrity of the housing seal.

  • Page 69: Section 7 - Functional Test

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Section 7 – Functional Test Running Self-Test Running a self-test on the iWAND hardware can be performed from the menu system from iWAND Setup > Test iWAND at the bottom of the menu. This will perform a series of functional tests on the internal electronics including: •...

  • Page 70: Section 8 - Firmware Upgrade

    Introduction This chapter describes the process for upgrading the firmware in the iWAND. The firmware update requires the Sonardyne 6G Terminal Lite software to be installed (this can be found on the Sonardyne 6G Utilities CD 8300-102). Firmware Upgrade Procedure Upgrading the firmware in the iWAND can only be carried out by means of the USB or the RS232 connection.

  • Page 71: Figure 8-2 - 6G Terminal Lite Dialog Box/6G Setup Tab

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 8-2 – 6G Terminal Lite Dialog Box/6G Setup Tab Refer to Figure 8-3. Make sure the 6G Terminal Lite version is 2.01.00.149 or later. To locate the version of the software click Help > About 6G Terminal.

  • Page 72: Figure 8-5 - Select Com Port

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 8-5. In the Select port type drop-down list, select the COM Port the iWAND is connected to. NOTE For standard RS232 ports select the port the iWAND is connected to. If the iWAND is connected via the USB the COM port will have (iWand) next to the port name.

  • Page 73: Figure 8-7 - Current Iwand Configuration

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 8-7. The 6G Terminal Lite window will populate with the current configuration of the iWAND, including the current firmware version. Figure 8-7 – Current iWAND Configuration Refer to Figure 8-8.

  • Page 74: Figure 8-9 - Bootloader Firmware List

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 8-9. In the list, the currently running firmware is displayed in green text. The black text is old or unused firmware. Figure 8-9 – Bootloader Firmware List Refer to Figure 8-10.

  • Page 75: Figure 8-11 - Confirm Replace Firmware

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 8-11. A dialog box will appear to confirm that the firmware will be replaced. Figure 8-11 – Confirm Replace Firmware Click OK to confirm the firmware is to be replaced.

  • Page 76: Figure 8-13 - Downloading New Firmware

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Refer to Figure 8-13. The file will automatically start to download and install the new firmware version. Figure 8-13 – Downloading New Firmware Refer to Figure 8-14. The new firmware will display in green text.

  • Page 77: Figure 8-15 - Close Bootloader

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Figure 8-15 – Close Bootloader Refer to Figure 8-16. After the reboot of the iWAND the 6G Terminal Lite settings should refresh and the new firmware will be displayed. If the software does not update automatically click Refresh.

  • Page 78: Section 9 - Fault Diagnosis

    For successful communications the iWAND transducer should be firmly held against the transducer of the Sonardyne 6G instrument being interrogated. Make sure the criteria outlined in Section 5.3 – Prerequisites for Operation have been met for the instrument being interrogated.

  • Page 79: Section 10 - Storage

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Section 10 – Storage 10.1 Storing the iWAND The iWAND when not in use should be stored in the protective transit case shipped with the product. Make sure the housing is clean and dry before returning to the case.

  • Page 80: Section 11 - Technical Specifications

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Section 11 – Technical Specifications 11.1 Technical Specification for the iWAND 11.1.1 External Power Parameter Specification External Supply Voltage Nominal 5 V DC (USB) Operating Range 5 V USB...

  • Page 81: Firmware Requirements

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 11.1.5 Firmware Requirements For correct operation the iWAND requires the following firmware versions (or later) in the unit being interrogated: Sonardyne 6G Product Minimum Firmware Version Compatt 6 / AMT V3.00.06.10*...

  • Page 82: Appendix A - Firmware History Record

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Appendix A – Firmware History record A.1 Firmware History Record This table is a history and record of all firmware installed into the equipment. Table A-1– Firmware History Record...

  • Page 83: Appendix B - Software Copyright / License / Warranty

    Sonardyne International. Where onward rental, lease or loan is sanctioned by Sonardyne International, the end user must be made aware of the details of this agreement and it is the responsibility of the rentee to ensure that the end user complies with the agreement and deletes and returns any copies at the end of the rental period..
  • Page 84 Good data processing procedure dictates that any program be thoroughly tested with non-critical data before relying on it. The user must assume the entire risk of using the program. ANY LIABILITY OF SONARDYNE INTERNATIONAL LIMITED WILL BE LIMITED EXCLUSIVELY TO PRODUCT REPLACEMENT OR REFUND OF PURCHASE PRICE.

  • Page 85: Appendix C - Windows 8 Driver Installation

    UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Appendix C – Windows 8 Driver Installation C.1 USB Driver Installation on Windows 8 In some configurations Windows 8 will not allow installation of digitally unsigned drivers. The driver provided with the iWAND for the USB interface is not digitally signed so the following procedure should be followed when installing it.
  • Page 86 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Click Restart now. Click Troubleshoot. Click Advanced options. Appendix C 27 May 2014...
  • Page 87 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Click Start-up Settings. Click Restart. Select Disable driver signature enforcement, option 7. The driver should install as described in Section 4.4.2. Appendix C 27 May 2014...
  • Page 88 An instrument that emits an acoustic signal in response to an electrical Acoustic Responder signal carried to it by cable. Information carried by sound pressure waves through water. The Sonardyne Acoustic Signal acoustic signal has a finite length. An instrument that emits signals regularly without an interrogating signal. A Acoustic Synchronous / SYNCHRONOUS Pinger can be synchronised to an external master signal.
  • Page 89 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Term Definition The firmware installed on the transponder. Firmware upgrades can be Firmware installed via WSM Terminal. The Tx firmware refers to the transmission signal synthesiser. Glossary of Terms...
  • Page 90 UM-8315 User Manual for the Type 8315 iWAND Issue B Rev 1 Global Headquarters, UK Rio das Ostras, Brasil Singapore, Asia Blackbushe Business Park Av. Zen lotes 05 e 06 34 Loyang Crescent Yateley Quadra D Block B Hampshire Zen, Rio das Ostras – RJ...
