Hoshizaki KM-250BAF Parts List
Crescent cuber with storage bin
Hide thumbs
Also See for KM-250BAF:
- Service manual (51 pages) ,
- Instruction manual (21 pages) ,
- Service manual (358 pages)
Related Manuals for Hoshizaki KM-250BAF
Summary of Contents for Hoshizaki KM-250BAF
- Page 1 71169 ISSUED: MAY 5, 2000 REVISED: NOV. 4, 2002 HOSHIZAKI CRESCENT CUBER WITH STORAGE BIN MODEL KM-250BAF KM-250BWF PARTS LIST...
- Page 2 Auxiliary Codes KM-250BAF KM-250BWF APRIL 2000 DEC. 2000 DEC. 2001 MAY 2000 JAN. 2001 DEC. 2001 APRIL 2002...
-
Page 4: Ice Cuber Assembly
KM-250BAF A. ICE CUBER ASSEMBLY K-0, L-0, M-0 17 18... - Page 5 KM-250BAF MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONT. BOX ASSEMBLY TRUSS HEAD SCREW LABEL LOCATION TOP PANEL FRONT PANEL TRUSS HEAD SCREW BODY CONT. BOX GUIDE TRUSS HEAD SCREW CONT. BOX COVER TRUSS HEAD SCREW HEX HEAD BOLT BUSHING...
- Page 6 KM-250BAF MODEL INDEX DESCRIPTION TOP INSULATION BRACE TRUSS HEAD SCREW BRACKET FRAME TRUSS HEAD SCREW FRAME (L1) TRUSS HEAD SCREW FRAME (R) TRUSS HEAD SCREW COVER FRONT FRAME SHEET HINGE (L) HINGE (R) HEX HEAD BOLT W/WASHER (LF) COLLAR BOLT...
- Page 7 KM-250BWF A. ICE CUBER ASSEMBLY K-0, L-0, M-0, M-1...
- Page 8 KM-250BWF MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONT. BOX ASSEMBLY TRUSS HEAD SCREW LABEL LOCATION TOP PANEL FRONT PANEL TRUSS HEAD SCREW BODY CONT. BOX GUIDE TRUSS HEAD SCREW CONT. BOX COVER TRUSS HEAD SCREW BUSHING BUSHING GASKET THUMBSCREW DOOR SIDE PANEL (L) SIDE PANEL (R)
- Page 9 KM-250BWF MODEL INDEX DESCRIPTION TOP INSULATION BRACE TRUSS HEAD SCREW BRACKET FRAME TRUSS HEAD SCREW FRAME (L1) TRUSS HEAD SCREW FRAME (R) TRUSS HEAD SCREW COVER FRONT FRAME SHEET HINGE (L) HINGE (R) HEX HEAD BOLT W/ WASHER (LF) COLLAR WIRE SADDLE BUSHING HOOK...
-
Page 10: Refrigeration Circuit
KM-250BAF B. REFRIGERATION CIRCUIT 48 50 K-0, L-0, M-0... - Page 11 KM-250BAF MODEL INDEX DESCRIPTION EVAPORATOR TRUSS HEAD SCREW BASE TRUSS HEAD SCREW COMPRESSOR BOLT GROMMET SPACER PROTECTOR PROTECTOR HOLDER CONDENSER TRUSS HEAD SCREW SHROUD (A) TRUSS HEAD SCREW FRAME (C) T2 SCREW FAN MOTOR SELF LOCKING NUT FAN BLADE BUSHING...
- Page 12 KM-250BAF MODEL INDEX DESCRIPTION MATERIAL OR MODEL NUMBER STRAINER PRESSURE SWITCH ACB-1UB09 PRESSURE SWITCH BRACKET T2 SCREW THERMISTOR HOLDER-THERMISTOR COPPER INSULATION-THERMISTOR PE FOAM EXP. VALVE COVER (A) PE FOAM EXP. VALVE COVER (B) PE FOAM RUBBER TUBE EPDM CLAMP D11-S COPPER COPPER TUBE (A) –...
- Page 13 KM-250BAF MODEL INDEX DESCRIPTION CABLE TIE CABLE TIE INSULATION TUBE INSULATION TUBE COPPER TUBE - CONDENSER B. REFRIGERATION CIRCUIT TITLE MATERIAL PART OR MODEL NUMBER NUMBER CV-100 7920-0002 CV-200 7920-0010 L=40 7762-0717 L=40 7762-1020 COPPER 4A0195-01 REQUIRED NUMBER...
- Page 14 KM-250BWF B. REFRIGERATION CIRCUIT K-0, L-0, M-0, M-1 21 22 24 23...
- Page 15 KM-250BWF MODEL INDEX DESCRIPTION EVAPORATOR TRUSS HEAD SCREW BASE TRUSS HEAD SCREW COMPRESSOR BOLT GROMMET SPACER PROTECTOR PROTECTOR HOLDER CONDENSER-WATER COOLED HEX HEAD BOLT W/WASHER (LF) DRIER EXP. VALVE VALVE BODY COIL VALVE BOLT ACCESS VALVE STRAINER WATER REGULATOR TRUSS HEAD SCREW T2 SCREW MALE CONNECTOR PRESSURE SWITCH BRACKET...
- Page 16 KM-250BWF MODEL INDEX DESCRIPTION MATERIAL OR MODEL NUMBER THERMISTOR HOLDER-THERMISTOR COPPER INSULATION-THERMISTOR PE FOAM CABLE TIE CV-200 INSULATION TUBE L=40 EXP. VALVE COVER (A) PE FOAM EXP. VALVE COVER (B) PE FOAM INSULATION TUBE L=40 CLAMP D11-S COPPER COPPER TUBE (A) – HIGH SIDE COPPER COPPER TUBE (B) –...
-
Page 17: Water Circuit
KM-250BAF, BWF C. WATER CIRCUIT (1/2) K-0, L-0, M-0, M-1... - Page 18 KM-250BAF, BWF C. WATER CIRCUIT (2/2) K-0, L-0, M-0, M-1...
- Page 19 KM-250BAF, BWF MODEL INDEX DESCRIPTION PUMP MOTOR ASSEMBLY TRUSS HEAD SCREW WATER VALVE TRUSS HEAD SCREW DISTRIBUTOR HOSE (B) JOINT DISTRIBUTOR HOSE (C) WATER SPRAY TUBE SPRAY GUIDE WATER SUPPLY TUBE PLUG ELBOW TANK INSERT COUPLING THUMB SCREW VINYL HOSE...
- Page 20 KM-250BAF, -BWF MODEL INDEX DESCRIPTION TRUSS HEAD SCREW VINYL HOSE BUSHING (A) DRAIN (A) FITTING (A) HOSE CLAMP HOSE CLAMP HOSE CLAMP HOSE CLAMP INSULATION TUBE DRAIN RUBBER GASKET VINYL HOSE ELBOW VINYL HOSE “O” RING “O” RING C. WATER CIRCUIT...
-
Page 21: Control Box Assembly
KM-250BAF, BWF D. CONTROL BOX ASSEMBLY K-0, L-0, M-0, M-1... - Page 22 KM-250BAF, BWF MODEL INDEX DESCRIPTION THERMOSTAT ASSY TRUSS HEAD SCREW CONT. BOX CAPACITOR – STARTING RUN CAPACITOR STRAP T2 SCREW STARTER T2 SCREW MAGNETIC CONTACTOR BRACKET T2 SCREW CAPACITOR T2 SCREW TRANSFORMER T2 SCREW CONTROLLER BOARD BOARD SUPPORT TOGGLE SWITCH BUSHING D.
-
Page 23: Label Location
KM-250BAF E. LABEL LOCATION K-0, L-0, M-0 VIEW A... - Page 24 KM-250BAF MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL – PENGUIN – HA (L) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET LABEL – R404A LABEL – SWITCH CAUTION LABEL CAUTION LABEL (G) MANUAL LABEL LABEL – AIR FILTER CAUTION LABEL (F) INSTRUCTION LABEL LABEL –...
- Page 25 KM-250BWF E. LABEL LOCATION K-0, L-0, M-0, M-1 VIEW A...
- Page 26 KM-250BWF MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL – PENGUIN – HA (L) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET LABEL – R404A LABEL – SWITCH CAUTION LABEL CAUTION LABEL (G) MANUAL LABEL INSTRUCTION LABEL LABEL – CONTROL BOARD RATING LABEL E.
-
Page 27: Top Panel
KM-250BAF, BWF F. TOP PANEL K-0, L-0, M-0, M-1... - Page 28 KM-250BAF, BWF MODEL INDEX DESCRIPTION MATERIAL OR MODEL NUMBER TOP PANEL TAPE - FOAM F. TOP PANEL TITLE PART REQUIRED NUMBER NUMBER M-0 M-1 216841-01 8208-0006...
-
Page 29: Pump Motor Assembly
KM-250BAF, BWF G. PUMP MOTOR ASSEMBLY K-0, L-0, M-0, M-1... - Page 30 KM-250BAF, BWF MODEL INDEX DESCRIPTION PUMP MOTOR PUMP MOTOR BRACKET PUMP SHAFT COVER TRUSS HEAD SCREW IMPELLER PUMP HOUSING ASSEMBLY ABS T2 SCREW G. PUMP MOTOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 3U0146-01 APTA4J2P10W JSR CB40 105926-01 JSR 86K1...
-
Page 31: Thermostat Assembly
KM-250BAF, BWF H. THERMOSTAT ASSEMBLY K-0, L-0, M-0, M-1... - Page 32 KM-250BAF, BWF MODEL INDEX DESCRIPTION THERMOSTAT HEATER VINYL HOSE SILICONE TUBE ALUMINUM TAPE H. THERMOSTAT ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER A30-3761-00 437626-01 EP-21 437409-01 L=800 7711-0406 L=210 7730-0810 ALUMINUM 324558-06 REQUIRED NUMBER M-0 M-1...
-
Page 33: Accessories & Packaging
KM-250BAF, BWF MODEL INDEX DESCRIPTION INSTRUCTION MANUAL SCOOP PACKAGING PALLET WOOD BLOCK – B SIDE PROTECTOR CORNER POST CORNER POST CARTON MODEL AND SERIAL NO. LABEL FOAM BLOCK – FRONT FOAM BLOCK – TOP J. ACCESSORIES & PACKAGING TITLE MATERIAL...
