1 |
P a g e
Aberlink Work Instruction
Deva 031 Touch Screen Joystick installation
Issue: 1
Doc No: WI2021-029
Published: 25/02/2021
Included Components
• 031 Joystick
• 031 USB Interface Card
• 031 Card PC Backplate
• USB A to USB B Cable
Deva 031 touch screen joystick installation WI-2021-029 Iss. 1
Contact Support: helpdesk@aberlink.co.uk | +44 (0)1453 884461
www.aberlink.com
Advertisement
Summary of Contents for DEVA 031
- Page 1 P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Aberlink Work Instruction Deva 031 Touch Screen Joystick installation Issue: 1 Doc No: WI2021-029 Published: 25/02/2021 Included Components • 031 Joystick • 031 USB Interface Card • 031 Card PC Backplate •...
-
Page 2: Using The Joystick
Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Using the Joystick This document shows a step-by-step installation of deva 031 joystick and the required deva configuration settings. Please follow the document step by step before calling for assistance. Remember the joystick is a USB device and will require deva drivers. -
Page 3: Installing The Interface Card
P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Installing the interface Card Screw the interface card onto the PC Backplate using the two jack post screws that are already pre-inserted into the card. With the top lid removed from your controller locate the motor loom on the backplate (This cable is covered in a black cable sleeve). - Page 4 Remove the link and store it somewhere safe, as it will have to be refitted if a Logitech joystick is refitted in the future. With the 2-way pin removed insert the 10-way header into the rear of the Deva 031 interface card as shown below.
- Page 5 P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Remove one of the blanking plates on the PC backplate and place the joystick card into the now empty slot. Use the same screw you remove from the blanking plate to hold it in place, then plug the short USB cable into the card and the other end into the one of the USB ports on the back of your controller.
- Page 6 Deva 031 Joystick drivers and settings file. When you have downloaded the zip file extract the contents, you will see a folder for the Joystick driver and a registry file for the settings. Double click the 031.reg file www.aberlink.com...
- Page 7 P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 You might see the following box when you have double clicked the settings registry file, if so click the ‘Run’ button When you see this message box pop up, please click the yes button to automatically apply the settings.
- Page 8 P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 To update the drivers right click the Windows 10 start icon then click on device manager Right click on the Touchscreen Joystick (this might be displayed as unknown device)
- Page 9 P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Then click update drivers. Click on browse my computer for driver software www.aberlink.com...
- Page 10 Point the installer at your driver folder you just downloaded it should be in the path ‘C:\USER\CMM Controller\Downloads\deva031usb39’ if you downloaded it from our website. Click next when you have selected the folder. The joystick should display the following message and your Deva 031 Joystick is now ready to use with your CMM. www.aberlink.com...
-
Page 11: Need More Help
11 | P a g e Deva 031 touch screen joystick installation WI-2021-029 Iss. 1 Change History Date of Change Description of Change Issue Changed Approved 26/02/2021 First edition Need more help? Further support documents, work instructions and tutorial videos are available on request Contact Aberlink: helpdesk@aberlink.co.uk...
