Page 4
1.2.4 All air hose couplings are provided with holes which must be safety pinned or wired to prevent accidental disconnections. 1.2.5 The interior condition of the vessel should be inspected regularly for corrosion. CONTRACOR Version 1.0 ®...
Page 6
The farther the CK-50 Portable Moisture Separator is from the compressor, the more mois- ture will condense in the line, making it more likely to be removed. The water and oil that collect at the bottom of the CK-50 Portable Moisture Separator must be periodically be drained using the manual drain cook.
Page 7
3.3. Air Requirements. The CK-50 Portable Moisture Separators requires min. 5 m3/min by 4 bar and max. 22 m3/min by 10 bar for the efficient operation. At lower/higher volume and pressure CK-50 Portable Moisture Separator does not remove as much moisture and oil.
Page 8
14. Liability for any special, consequential or incidental damages (including but not limited to loss of revenue or profit, downtime costs, loss of the use of the equipment, regardless of cause or for breach of any written or implied warranty is expressly disclaimed. CONTRACOR Version 1.0 ®...
Page 9
Contents 1. Safety 2. Package and specification 4 3. Introduction. Setup. Air Requirements. Cleaning 6 4. Warranty and warranty service regulations 10 CONTRACOR CK-50 Art. 50100 ®...
Page 11
1.2.4 All air hose couplings are provided with holes which must be safety pinned or wired to prevent accidental disconnections. 1.2.5 The interior condition of the vessel should be inspected regularly for corrosion. CONTRACOR CK-50 Art. 50100 ®...
Page 13
The farther the CK-50 Portable Moisture Separator is from the compressor, the more mois- ture will condense in the line, making it more likely to be removed. The water and oil that collect at the bottom of the CK-50 Portable Moisture Separator must be periodically be drained using the manual drain cook.
Page 14
3.3. Air Requirements. The CK-50 Portable Moisture Separators requires min. 5 m3/min by 4 bar and max. 22 m3/min by 10 bar for the efficient operation. At lower/higher volume and pressure CK-50 Portable Moisture Separator does not remove as much moisture and oil.
Page 15
14. Weitergehende Ansprüche, wie z.B. Schadensersatz wegen Einnahme- oder Gewin- nausfall, Arbeitsunterbrechungen oder Nutzungsausfall des Equipments, sind ausge- schlossen. Die Garantie beschränkt sich nur auf das Equipment, dem Käufer stehen keine weiteren Schadensersatzansprüche, insbesondere auch nicht für Folgeschäden, CONTRACOR CK-50 Art. 50100 ®...
Page 16
Содержание 1. Безопасность 2. Упаковка и характеристики 3. Внедрение. Наладка. Требуемый расход воздуха. Очистка 4. Гарантия и правила гарантийного обслуживания CONTRACOR Версия 1.0 ®...
Page 17
Гарантия и правила гарантийного обслуживания CONTRACOR CK-50 Art. 50100 ®...
Page 18
При наличии любых признаков износа или утечки муфт или шлангов их следует заменить. 1.2.4 Все муфты воздушных шлангов снабжены отверстиями, которые должны быть безопасно зашплинтованы или закреплены проволокой для предотвращения случайных рассоединений. 1.2.5 Необходимо регулярно проверять резервуар внутри на отсутствие коррозии. CONTRACOR Версия 1.0 ®...
Page 19
CK-50 Сепаратор мобильный конденсата СК-50 10901 CFT-2 Сцепление байонетное 1 1/2” 50101 Клапан предохранительный 1/2”, установленное избыточное давление 10,5 бар 50102 Кран шаровой 1 1/2” 50103 Клапан сливной 1/2” 50104 Коалесцирующий элемент из нержавеющей стали CONTRACOR CK-50 Art. 50100 ®...
Page 20
для работы с переносными компрессорами, используемыми для струйной очистки вне помещений. 3.2. Наладка. Подключить мобильный сепаратор конденсата CK-50 к источнику воздуха между компрессором и воздушным фильтром CAF-3, установленным на входе аппарата для струйной обработки. Для подключения следует использовать воздушный шланг компании Contracor с...
Page 21
выполнить продувку для удаления любых инородных материалов, которые могли накапливаться. Если сетка из нержавеющей стали покрывается маслом и грязью, следует отсоединить мобильный сепаратор конденсата CK-50 от воздушной линии и промыть его теплой водой. 4. Гарантийные обязательства и правила гарантийного обслуживания.
Page 22
9. Нормальный износ оборудования, вызванный его эксплуатацией с интенсивностью, не соответствующей указанному в инструкции по эксплуатации назначению оборудования, не является гарантийным случаем. РУССКИЙ CONTRACOR® BAF-1 Art. 30400 31 10. Повреждения, возникшие в результате применения приспособлений, принадлежностей или расходных материалов иных, чем предлагаются поставщиком, а также в случае...
