ICOP Technology PPC-090T-D2N3N User Manual

Dmp vortex86 dx2 processor compact panel pc with 9” touchscreen
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-090T-D2N3N and is the answer not in the manual?

Questions and answers

Summary of Contents for ICOP Technology PPC-090T-D2N3N

  • Page 2 User’s Manual PPC-090T DMP Vortex86 DX2 Processor Compact Panel PC with 9” Touchscreen PPC-090T-D2N3N PPC-090T-D2N4N PPC-090T-D2N3N-GE PPC-090T-D2N4N-GE PPC-090T-D2W4N PPC-090T-D2W4N-GE (Revision 1.1A) PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...
  • Page 3 REVISION DATE VERSION DESCRIPTION 2014/1/22 Version 1.0A New Release 2014/3/11 Version 1.1A 4.3 Serial Ports Setting (RS232/422/485) PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...
  • Page 4 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the ICOP Technology Inc. Copyright 2014 ICOP Technology Inc. Manual # IUMPPC090T-01 Ver.1.1A Mar, 2014 TRADEMARKS ACKNOWLEDGMENT Vortex86DX2...
  • Page 5 SAFETY INFORMATION  Read these Safety instructions carefully.  Please carry the unit with both hands, handle carefully.  Make sure the voltage of the power source is correct before connecting the equipment to the power outlet.  Do not expose your Panel PC to rain or moisture in order to prevent shock and fire hazard.

  • Page 6: Table Of Contents

    Content Ch. 1 General Information................1 1.1 Product Description ................2 1.2 Product Specifications ................ 3 1.3 Inspection Standard for TFT-LCD Panel ..........5 1.4 Product Dimensions ................7 1.5 Panel Mounting Instruction ..............9 1.6 Ordering Information ................. 11 Ch.

  • Page 7: 1 General Information

    General Information 1.1 Product Description 1.2 Product Specifications 1.3 Inspection standard for TFT-LCD Panel 1.4 Product Dimensions 1.5 Mounting Instruction 1.6 Ordering Information PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 8: Product Description

    1.1 Product Description ICOP Technology Inc. is proudly going to release a brand new Panel PC, which offers fanless design, low power consumption, and IP65 front panel. The PPC-090T is powered by DMP’s latest Vortex86DX2 SoC, the 3 generation SoC of Vortex86 family, and dual-channel 1GB DDRII chipset that handles processing more efficiently and provides faster performance.

  • Page 9: Product Specifications

    1.2 Product Specifications CPU BOARD SPECIFICATIONS DM&P Vortex86DX2 933MHz L1:16KB I-Cache, 16KB D-Cache / Cache L2: 4-way 256KB Cache BIOS AMI BIOS Memory 512MB / 1GB /2GB DDR2 onboard Software Programmable from Watchdog Timer 30.5u to 512 seconds x 2 sets Integrated 10/100M Ethernet X1 Giga Ethernet (Optional) X1 Audio...
  • Page 10 Storage -30~+70°C (-22~ +158°F) Temperature 0% ~ 90% Relative Humidity, Operating Humidity Non-Condensing Dimensions 242x156.5x44mm (9.68"x6.26"x1.76") Weight 3.0 Kg Protection IP65 Front Panel Certification CE / FCC / VCCI / Vibration LCD SPECIFICATIONS Display Type 9” WSVGA TFT LCD Backlight Unit Display Resolution 1024(W) x 600(H) Brightness (cd/m...

  • Page 11: Inspection Standard For Tft-Lcd Panel

    1.3 Inspection Standard for TFT-LCD Panel DEFECT TYPE LIMIT φ＜0.15mm Ignore Note 0.15mm≦φ≦0.5mm N≦4 SPOT 0.5mm＜φ 0.03mm<W≦0.1mm, L≦5mm N≦3 Note FIBER VISUAL 1.0mm＜W, 1.5mm＜L INTERNAL DEFECT φ＜0.15mm Ignore Note POLARIZER 0.15mm≦φ≦0.5mm N≦2 BUBBLE 0.5mm＜φ Mura It’ OK if mura is slight visible through 6%ND filter A Grade B Grade Note...
  • Page 12 [ Note 2 ] Bright dot is defined through 6% transmission ND Filter as following. [ Note 3 ] Display area C Area: Center of display area O Area: Outer of display area [ Note 4 ] Judge the defect dot and the adjacent dot as following. Allow below (as A, B, C and D status) adjacent defect dots, including bright and dark adjacent dot.

  • Page 13: Product Dimensions

    1.4 Product Dimensions PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...
  • Page 14 PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 15: Panel Mounting Instruction

    1.5 Panel Mounting Instruction Cut a mounting hole in the panel. (Refer to PPC‐090T Dimensions on page 7~8.) (Note 1) Check and remove the twelve M3 screws in a diagonal pattern as image below if necessary. Place PPC‐090T face‐down on a clean, flat surface. Slide the panel cutout around the back of PPC‐090T, until the panel rests directly on the gasket.
  • Page 16 Note 1: It is strongly recommended that a professional machine shop cut the mounting hole in the panel. Note 2: The length for all twelve M3 screws will be according to the thickness of mounting panel. For example: The length of standard M3 screws for PPC-090T is 6mm.

  • Page 17: Ordering Information

    1.6 Ordering Information PART NUMBER DESCRIPTION PPC-090T-D2N3N 9” Panel PC w/512MB Memory / 3USB / AUDIO / LAN / 2COM / DC12~24V PPC-090T-D2N4N 9” Panel PC w/1GB Memory / 3USB / AUDIO / LAN / 2COM / DC12~24V PPC-090T-D2N3N-GE 9” Panel PC w/512MB Memory / 3USB /...

  • Page 18: 2 System Installation

    System Installation 2.1 CPU Board Outline 2.2 Connector Summary 2.3 Connector Pin Assignments 2.4 External I/O Overview 2.5 External I/O Pin Assignment 2.6 Watchdog Timer PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 19: Cpu Board Outline

    2.1 CPU Board Outline PPC CPU Board PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 20: Connector Summary

    2.2 Connector Summary Description Type of Connections Pin # Power Terminal Connector External Power Plug 3-pin COM (RS232/422/485) External D-Sub Male Connector 9-pin External USB Connector 6-pin External USB Connector 6-pin PS/2Keyboard External Mini DIN Socket 6-pin External USB Connector 6-pin USB (Wi-Fi Optional) Internal USB Connector...

  • Page 21: Connector Pin Assignments

    2.3 Connector Pin J7: USB Assignments Pin # Signal Name Pin # Signal Name USBD4- J1: Power Terminal Connector USBD4+ Pin # Signal Name +12~24V J8: USB (Wi-Fi Optional) Pin # Signal Name Pin # Signal Name USBD1- J3: COM (RS232/422/485) USBD1+ Pin # Signal Name...

  • Page 22: External I/O Overview

    2.4 External I/O Overview Power Switch PS/2 KB USB 2.0 PORT Audio-Out 10/100Mbps GIGA Ethernet +12 ~ 24VDC RS-232/422/485 Ethernet (Optional) NOTE The functions of GIGA LAN, Wireless are optional The serial ports RS232/422/485 are selected by BIOS setting, please refer to 4.3 Serial Ports Setting (RS232/422/485) PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 23: External I/O Pin Assignment

    2.5 External I/O Pin Assignment Power Switch J4/J5/J7: USB Pin # Status Pin # Signal Name USB0- USB0+ Power Connector DC-IN 24V Pin # Signal Name GGND +12~24V GGND RJ45 Signal Signal PS/2 Keyboard Name Name Pin # Signal Name FTXD+ FTXD- KBCLK...

  • Page 24: Watchdog Timer

    2.6 Watchdog Timer There are two watchdog timers in PPC-090T, we also provide DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://tech.icop.com.tw or download the PDF file at: dmp.com.tw/tech PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 25: 3 Hardware Installation

    Hardware Installation PPC-090T supports various kinds of storages for industrial application, divided into SATA Slim, CompactFlash or SD card (optional). 3.1 Installing the SATA Slim 3.2 Installing the Compact Flash PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

  • Page 26: Installing The Sata Slim

    3.1 Installing the SATA Slim [SPEC] JEDEC SFF-8156 standard form factor 53 x 32 x 4.0 mm SDM-SLIM-4G-V SDM-SLIM-8G-V SDM-SLIM-16G-V [STEP] Remove the nine screws in a diagonal pattern as the image below. Place the SATA slim horizontally aligned and gently put into the socket until you feel a click.

  • Page 27: Installing The Compact Flash

    3.2 Installing the Compact Flash [STEP] Remove the nine screws in a diagonal pattern as the image below. Gently insert the CF card along the track. Caution: Please watch out for the direction which the CF card has to be face up. Insert all nine screws into the screw holes.

  • Page 28: 4 Driver Installation

    Driver Installation 4.1 PPC-090T Development Note 4.2 BIOS Default Setting 4.3 Serial Ports Setting (RS232/422/485) PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...
  • Page 29 The Vortex86DX2 processor is integrated RDC Display chip which is an ultra-low powered graphics chipset with total power consumption at around 1-1.5 W. The Vortex86DX2 processor is integrated 10/100Mbps Ethernet controller that supports both 10/100BASE-T and allows direct connection to your 10/100Mbps Ethernet based Local Area Network for full interaction with local servers, wide area networks such as the Internet.

  • Page 30: Ppc-090T Development Note

    4.1 PPC-090T Development Note < WINDOWS DEVELOPMENT GUIDE > Windows Embedded CE 6.0 BSP, Windows Embedded Compact 7 BSP, and Windows Embedded Standard 2009 trial image with development notes, please visit technical website to get more information at http://tech.icop.com.tw/. < LINUX INSTALLATION NOTE> Please visit Linux technical website to get more information at ftp://ftp.dmp.com.tw/Linux_DEMO/Vortex86_Linux_Support_List_revised.

  • Page 31: Bios Default Setting

    4.2 BIOS Default Setting If the system cannot be booted after BIOS changes are made, please follow below procedures in order to restore the CMOS as the default setting. Press < End > Key, when the power on Press < Del > to enter the AMI BIOS setup Press <...

  • Page 32: Serial Ports Setting (Rs232/422/485)

    4.3 Serial Ports Setting (RS232/422/485) Please press <Del> to get into the BIOS settings after booting the machine, and follow the steps below: [Step 1] Use the arrow key to select the category “Chipset” on the top of the menu, then select SouthBridge Configuration in the sub menu and press <Enter>...
  • Page 33 [Step 3] Choose the port you would like to change. For example, choose TXDEN1 for COM1 and press <Enter>. You will then see three options; select the desired type and press <Enter> to finish the setting. The Serial Ports setting is finished. PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...
  • Page 34 [Step 4] Press <Esc> twice to get back to the Top Menu. Use the arrow key to the category “Exit”, and select the option “Save Changes and Exit”. Press <Enter> and choose [OK] to keep your changes, then the device will reboot automatically.

  • Page 35: Warranty

    (RMA) number. Returned goods should always be accompanied by a clear problem description. All Trademarks appearing in this manuscript are registered trademark of their respective owners. All Specifications are subject to change without notice. ©ICOP Technology Inc. 2014 PPC-090T User’s Manual IUMPPC090T-01 Ver.1.1A Mar, 2014...

This manual is also suitable for:

Ppc-090t-d2n4nPpc-090t-d2n3n-gePpc-090t-d2n4n-gePpc-090t-d2w4nPpc-090t-d2w4n-ge
