- Page 1 USER MANUAL Suspension/Pass-Through Strip Heat Lamps RETAIN THIS MANUAL FOR FUTURE REFERENCE. UNIT MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES. Models: 423BLS2, 423BLS3, 423BLS4, 423BLS5, 423BLS6, 423BLS7, 423BLS8, 423BLPT2, 423BLPT3, 423BLPT4, 423BLPT5, 423BLPT6, 423BLPT7, 423BLPT8 07/2021...
- Page 2 USER MANUAL Table of Contents Owner's Information ..........................3 Safety Warnings ............................. 4 Specifications ............................6 Parts of a Hanging Heat Lamp ........................ 6 Installation Instructions .......................... 7 Operating Instructions ..........................8 Troubleshooting ............................8 Warranty ..............................9...
- Page 3 USER MANUAL Owner's Information Please complete this information and retain this manual for the life of the equipment. For warranty purposes, please fill out and retain this information. An example of the serial plate(s) for these units are included below for reference.
- Page 4 ServIt lamps come in a standard attractive silver finish, perfect for front-of-house installation or use in a variety of portable applications. Each pair of bulbs includes a dedicated yet simple on/off switch for easy operation of select bulbs.
- Page 5 USER MANUAL ELECTRIC SHOCK HAZARD: • Wire unit into properly grounded electrical panel of the correct voltage, size, and configuration. • Suspension & pass-through strip heat lamps must be installed by a qualified electrician. Installation must conform to all local electrical codes. Installation by unqualified personnel will void unit warranty and may lead to electric shock or burn, as well as damage to unit and/or its surroundings.
- Page 6 # of Cords # of # of Cords Item # Voltage Wattage Item # Voltage Wattage Bulbs and Plugs Bulbs and Plugs Suspension Cord Countertop T-Leg 423BLS2 120V 500W 423BLPT2 120V 500W NEMA 423BLS3 120V 750W 423BLPT3 120V 750W 5-15P 423BLS4...
- Page 7 ASSEMBLY & INSTALLATION INSTRUCTIONS ServIt Suspension and Pass-Through Heat Lamps come partially assembled out of the box. All units in pass-through configuration with T-Legs require installation of legs. All suspension and pass-through 5, 6, 7, 8 bulb units come disassembled for easier transportation. The two sections of bulbs must be secured together using the included connector (423BLSCON) and applying red thread locker to the bolts.
- Page 8 USER MANUAL OPERATING INSTRUCTIONS General Information: • Always clean equipment thoroughly before first use. • Check rating label for your model designation and electrical rating. • Ensure unit is installed properly by a qualified electrician. WARNING: ELECTRICAL SHOCK HAZARD. FAILURE TO FOLLOW THE INSTRUCTIONS IN THIS MANUAL COULD RESULT IN SERIOUS INJURY OR DEATH. Do not modify the power supply cord plug.
