Summary of Contents for JOEY Wagon
- Page 1 Wagon Instruction Manual...
- Page 2 4. The Joey Wagon 5. Wagon Overview Assembly Attach fenders Attach wheels Attach wagon fabric Attach canopy Attach tray and cupholder 12. Harness operation Brake operation 14. How to fold your wagon Push & Pull modes 16. Cleaning & Maintenance...
- Page 3 Failure to follow these instructions could result in serious injury or death. This wagon seats up to two children. Each seat is suitable from birth (with infant car seat attached) up to 55 lbs (25kg) and 45 in (114 cm).
- Page 4 NEVER leave your child ALWAYS ensure that your unattended. child is properly positioned by NEVER park your wagon on a using the safety harness at all times. hill with your child inside. ALWAYS lock the brake while...
- Page 5 THE JOEY WAGON The Joey wagon was designed to make every trip together a chance to expand your family’s horizons, and show your kids more of the world. It’s made for suburbs, cities, and country roads, for vacations and the day to day. And for all those days where you’re making it up as you go along.
- Page 6 WAGON OVERVIEW HANDLEBAR HARNESS FENDER PORT PLUGS REAR WHEEL FOOTWELL BRAKE FRONT WHEEL CANOPY CUPHOLDER MESH POCKETS TRAY STORAGE CUPHOLDERS...
- Page 7 ASSEMBLY WARNING: Care must be taken when folding and To get you on your way, lay out all parts of the wagon unfolding the stroller to prevent finger entrapment included in your shipping box. To get you on your way, lay out all parts included in your To open your wagon frame: shipping box.
- Page 8 ATTACH FENDERS For ease of installation, fenders are interchangeable for left and right sides To attach fenders: Slot each fender into a wheel arch. Ensure that the bottom of the fender locks securely into the open slot in the rear axle mount. You will hear a CLICK! when fender is secured in place.
-
Page 9: Attach Wheels
ATTACH WHEELS For ease of installation, both rear and front wheels are interchangeable for left and right sides, respectively. To attach rear wheels: To remove the rear wheels: Push the rear wheel post Press the button located into rear wheel below wheel housing and housing until CLICK! is pull the wheel outward... - Page 10 After securing the velcro loops: Locate the 8 d-rings on the wagon seat. Loop the webbing straps around the front and rear seat backs. Loop the webbing straps around the side interiors of the seat backs.
-
Page 11: Attach Canopy
ATTACH CANOPY To attach the canopy: Locate posts on each side of the canopy. Slide the canopy posts into side housings on the seat backs. Locate the loops at the base of the canopy and fasten the holes around the knobs. Canopy is extendable and offers UPF 50+ protection. - Page 12 ATTACH TRAY AND CUPHOLDER To attach the tray: To attach the cupholder: Assemble tray Slide the cup holder into attaching the 2 vertical attachment points located on posts to each side of the the handle bar. tray. Push the cup holder in a Locate tray attachment...
- Page 13 HARNESS OPERATION Before you place your child in the wagon, press the brake pedal down until it clicks into the locked position. 3-Point Harness Place your child in the wagon and position the crotch belt between your child’s legs. Fasten both waist belts to the buckle on each side of the crotch belt until you hear a CLICK! on both sides.
-
Page 14: Brake Operation
Check to make sure the brakes are in a fully locked position. The wagon should not move when pushed. To release brakes: Apply a light downward pressure on the top section of the linked... - Page 15 HOW TO FOLD YOUR WAGON To fold your wagon frame: Remove any accessories attached to the wagon, including the canopy and snack tray. Locate the release buttons below each seat back. Push the buttons to release the seat backs and push downward.
- Page 16 PUSH & PULL MODES Push mode: To set the wagon in push mode, pull the knob and lock the handle upright. Pull mode: To set the wagon in pull mode, pull the knob to unlock and drop the handle.
-
Page 17: Cleaning And Maintenance
CLEANING & MAINTENANCE Cleaning: Frame and wagon fabric: Wipe with a damp cloth and let dry. To clean your Wagon Frame, Handlebar, Fenders, and Wheels: Wipe with a damp cloth and a mild cleaning solution and dry thoroughly. DO NOT use abrasives. - Page 18 www.myjoey.com LAIR, LLC 1305 W 11th St, #4003 Houston, TX 77008...
