MicMol AQUA Air Series Manual

Preset (Quick Set)

SPS 20K - Heavy Blue
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 1% 50% 50% 1% 0%
Channel A
60
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
0% 50% 100% 100% 50% 0% 40
Channel B
@ 6:00AM @ 7:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
20
0% 50% 100% 100% 50% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
LPS 15K -White + Blue
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 50% 100% 100% 50% 0%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM 60
0% 50% 100% 100% 50% 0%
40
Channel B
@ 6:00AM @ 7:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
20
0% 1% 50% 50% 1% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
Mixed Reef - 10K White + Blue
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 50% 100% 75% 50% 0%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM 60
0% 50% 100% 75% 50% 0% 40
Channel B
@ 6:00AM @ 7:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
20
0% 50% 100% 75% 50% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
Green Planted - WRGB
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 100% 100% 100% 100% 0%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM 60
0% 10% 10% 10% 10% 0% 40
Channel B
@ 6:00AM @ 7:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
20
0% 100% 100% 100% 100% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
Red Planted
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 90% 90% 90% 90% 0%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM 60
0% 80% 80% 80% 80% 0% 40
Channel B
@ 6:00AM @ 7:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
20
0% 20% 20% 20% 20% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
Mixed Planted
100
Dawn Sunrise Midday Sunset Dusk Night
80
0% 80% 80% 80% 80% 0%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM 60
0% 80% 80% 80% 80% 0% 40
Channel B
@ 6:00AM @ 10:00 PM
@ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM
20
0% 80% 80% 80% 80% 0%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 5:00 PM @ 8:00 PM @ 10:00 PM
Refugium Planted
100
Dawn Sunrise Midday Sunset Dusk Night
80
25% 0% 0% 0% 25% 100%
Channel A
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 8:00 PM @ 10:00 PM @ 00:00 AM 60
40
50% 0% 0% 0% 50% 100%
Channel B
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 8:00 PM @ 10:00 PM @ 00:00 AM
20
25% 0% 0% 0% 50% 100%
Channel C
@ 6:00AM @ 8:00 AM @ 12:00 PM @ 8:00 PM @ 10:00 PM @ 00:00 AM
Information
Make sure all the cables are connected before plug to electricity or will damage your light.
WARNING:

Important Handling Information

NOTICE: Failure to follow these handling instructions could result in damage to your Aqua Air or other property.
Never put the light and the smart controller in the water. Doing so may be dangerous and damage your light.
0
Carrying your Aqua Air before you move your Aqua Air, shut it down and disconnect all cables and cords connected to it.
Using power cord Never force a connector into a port. Don't put the power cord into your tank when it connected. When
00am 06am 12pm 03pm 07pm
you Setup your Aqua Air please make sure that it locate power supply where it will not be exposed to any water or
moisture.
Mount your power supply where it won't get wet. Include a "drip loop" - a tied loop of cord hanging down below the level
of the electrical outlet. That way, if water happens to run down the cord from the tank, it will drip off onto the floor rather
than into the outlet. Drip Loops should always be used to help prevent water from traveling along the cord and coming
into contact with an electrical outlet. Drip loops must always be below the level of the outlet. If the plug or outlet does get
wet, DO NOT TOUCH the cord.
Storing your Aqua Air If you are going to store your Aqua Air for an extended period of time, keep it in a cool location
(ideally, 71° F or 22° C).
When cleaning the outside of your Aqua Air, first shut down your Aqua Air and unplug the power cord. Then use a damp,
0
soft, lint-free cloth to clean the lamp exterior. Avoid getting moisture in any openings. Do not spray liquid directly on the
lamp. Do not use aerosol sprays, solvents, or abrasives that might damage the finish.
00am 06am 12pm 03pm 07pm

MicMol and the Environment

MicMol. recognizes its responsibility to minimize the environmental impact of its operations and products.
0
00am 06am 12pm 03pm 07pm
0
00am 06am 12pm 03pm 07pm
0
00am 06am 12pm 03pm 07pm

Warranty

MicMol warrants all MicMol products to be free from manufacturing defects for one year from the original purchase
date when purchased through an authorized MicMol retailer. This warranty does not cover any damages caused by
misuse, neglect, alterations or improper handling / transport / maintenance / installation. Physical damages are not
covered by warranty. MicMol does not cover personal injury, personal loss, or other damages associated with the use
of our products. In order to request warranty service, please email us at support@micmol.com. A purchase receipt is
0
required for any warranty service. Products requiring warranty service must be returned to MicMol or authorized
MicMol retailer. You are responsible for the cost of shipping a warranty claim to MicMol and any damages that may
00am 06am 12pm 03pm 07pm
occur during transit. Once a returned product has been inspected, it will be repaired or exchanged at our discretion
and returned to you. Thank you very much.
© 2012~2021 MicMol Limited. All rights reserved.
MicMol, the MicMol logo, Aqua Air, Aqua mini, Aqua Pro, THOR, Aqua CC, SOLO, Prism are trademarks of MicMol registered.
0
AA009-2112-A Printed in China
00am 06am 12pm 03pm 07pm
Congratulations on purchasing your Aqua Air.
Read this guide to get started to installing your lighting.

Aqua Air Overview

Aqua Air Smart Controller Power Supply Super Bracket

Getting Started

AC cord
