N
ighthawk mgx -7
Manual
Bidirectional data Transmission with wireless from Emitter to the receiver;
Tacitly approve as switched on when the batteries placed. Multi-color LEDS On the right of the bite alarm
is flickering alternating; Angd different sounds when the wheel running in different direction.
Button V and
has same function. Sound volume adjusted circulating from soundless to 7 step by
steps when clicking.
"Button T is the Tone adjustable button, you can choose circulating of the 8 steps of the tone "
"Button S is the Sensitivity adjustable button, class A of the Sensitivity is one beep, and there are total 8
steps of the Sensitivity, you can choose the sensitivity circulating. Each half circle of the wheel is 1 step of
the Sensitivity."
Choose the color of LED on the right of Emitter please press on the button S and T at the same time.
Totally 7 colors for choose
The LED on the left of the Emitter has 20s memories for bite indicating. And it flickering synchronization
with the swinger
"When the capacity of batteries less than 80%, the Geen LED flickering each 5s for lower power warning"
Emitter Data
working voltage: 6-10V
working current: 52MA
standby current: 10uA - reed switch break - - 95UA reed switch switched on
Shutdown Current: 6UA
radio frequency: 433.92MHZ
Radio power: 15dbm
Wireless distance: ≥ 150m
working temperature: -40 - 70
multi
color
.
-
.
www
saenger
tts
de
Seite 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Anaconda Nighthawk MGX-7
- Page 1 ighthawk mgx -7 Manual Bidirectional data Transmission with wireless from Emitter to the receiver; Tacitly approve as switched on when the batteries placed. Multi-color LEDS On the right of the bite alarm is flickering alternating; Angd different sounds when the wheel running in different direction. Button V and has same function.
- Page 2 ighthawk mgx -7 Receiver Function Bidirectional data Transmission with wireless from Emitter to the receiver; Tacitly approve as switched on when the batteries placed. Multi-color LEDS extinguished after instant flickering. "V- is to less the sound volume to soundless, then in shake status" V+ is to increase the sound volume to the maximum.
- Page 3 ighthawk mgx -7 Bank watcher "human infrared sensor (PIR), when some body pass, the bank watcher alarm and transmit the wireless signal to receiver." "Tacitly approve as switched on when the batteries placed. 2 LEDS light with white led flash, and you will hear ""di"", after the voice stop, it means starting up."...
- Page 4 Tent lamp "constant current drawing and high light LED.Bidirectional data Transmission with wireless from Emitter to the tent lamp; not only illumination, it also have the same function as receiver. " Tacitly approve as switched on when the batteries placed. Multi-color LEDS is flickering alternating means starting up.
