Quick Start Guide - Electro-Harmonix BIG MUFF Manual

Using BMπHP as a Hardware Plugin
1. Install the software for your operat-
ing system at www.ehx.com/BMPHP
2. Connect the BMπHP to your computer
using a standard USB cable.
All power can be supplied through
the USB cable.
3. Wait for the computer to install drivers
and make the device available.
4. Open up your DAW.
5. Insert the Electro-Harmonix Big
Muff Pi software plugin on a track
or channel within your DAW.

Quick Start Guide

6. Assign the BMπHP to the software
7. When the STATUS light in the soft-
8. Press Play on the DAW. The channel
9. Rock-n-Roll!
- 2 -
plugin by doing the following:
a. Click the Settings menu in upper
right corner of plugin toolbar.
b. Click Select Device (this will be
greyed if unit is not properly
connected).
c. Click BMP-[4 digit serial number].
d. Click on Audio.
ware plugin turns green the BMπHP
is ready for use.
with the plugin will now go through
the BMπHP's analog circuitry.
Signal Flow Diagram
INPUT
FX SEND
GAIN
L/R
HARDWARE
PLUGIN
DAW
FX RETURN
L/R
COMPUTER
AUDIO INTERFACE
INPUT
GAIN
DAW
