SPARKFOX Pro-Kam Manual

Keyboard and mouse adapter
Hide thumbs

Advertisement

Quick Links

Download this manual
Pro-Kam
Keyboard and Mouse Adapter
Instructions on how to program/key bind your keyboard can be
found from page 7 below, please follow the instructions carefully.
As we continue to look to improve this product, we will release additional
software and updates as they become available.
See "Product Updates" section on page 13.
DISCLAIMER PLEASE READ:
This product is designed for use with wired and 2.4GHz wireless (USB)
keyboards and mice only. Although widely compatible with many
products, it will not be compatible with all. If your product does not work,
please contact us with the make and model and we will try to find a
solution for you.
Manual Revision: 3.2

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro-Kam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPARKFOX Pro-Kam

  • Page 1 Pro-Kam Keyboard and Mouse Adapter Instructions on how to program/key bind your keyboard can be found from page 7 below, please follow the instructions carefully. As we continue to look to improve this product, we will release additional software and updates as they become available.

  • Page 2: Product Description

    Product Description This innovative product allows you to play games on different consoles (Nintendo Switch™, Xbox One™, Xbox 360™, PlayStation 3 & ® PlayStation 4) with a wired keyboard and wired mouse and will also work ® with a lot of 2.4G wireless keyboard and mice that use a USB dongle for connection.
  • Page 3 LED will turn GREEN. Activate the adapter by pressing the “Space Bar” on the keyboard. PLEASE NOTE: If using a headset, please connect directly to the Pro-Kam Adapter AFTER the keyboard and mouse have successfully been connected. MOUSE...
  • Page 4 LED will turn GOLD. Activate the adapter by pressing the "Home" button on Xbox One/ 360 controller. PLEASE NOTE: If using a headset, please connect directly to the Pro-Kam Adapter AFTER the keyboard and mouse have successfully been connected.
  • Page 5 MOUSE CONSOLE ADAPTER KEYBOARD XBOX ONE CONTROLLER PlayStation 4 Setup: IMPORTANT: This adapter only supports official PlayStation 4 controllers. It does not support other third-party controllers. The controller must be switched OFF before it is connected to the adapter for setup to work correctly.
  • Page 6 LED will turn GOLD. Activate the adapter by pressing the "Home" button on PlayStation 4 controller. PLEASE NOTE: If using a headset, please connect directly to the Pro-Kam Adapter AFTER the keyboard and mouse have successfully been connected. MOUSE CONSOLE...
  • Page 7 PlayStation 3 Setup: IMPORTANT: This adapter only supports official PlayStation 3 controllers. It does not support other third-party controllers. The controller must be switched OFF before it is connected to the adapter for setup to work correctly. A data cable must be used for connection to the controller. The adapter will not support a cable with charging function only.
  • Page 8 Programming / Key-Binding - (PS4, PS3, Xbox One, Xbox 360): Once setup is complete, simultaneously (at the same time) press “F11 + F12” on the keyboard. The LED on the adapter will turn BLUE. Press and hold the button you want to set on the controller, then press the button on the keyboard or mouse you want to program, then release the button on the controller to set it.
  • Page 9 Once setup is complete as shown above, connect the official Nintendo Switch Pro Controller to the console port on the adapter using the official data charge cable supplied with the controller. The LEDs on the adapter will turn GOLD. Simultaneously (at the same time) press “F11 + F12” on the keyboard. The LED on the adapter will turn BLUE.
  • Page 10 Default Mouse Settings / Key Bindings Replace Button Mouse Buttons Nintendo Switch Xbox One / 360 Right Button Left Button Middle Button Mouse Move Right Joystick Right Joystick Right Joystick Right Joystick Mouse Move Right Joystick Right Joystick Right Joystick Right Joystick LEFT LEFT...
  • Page 11 Default Keyboard Settings / Key Bindings Replace Button Keyboard Buttons Nintendo Switch Xbox One / 360 D-pad UP D-pad UP D-pad UP D-pad UP D-pad LEFT D-pad LEFT D-pad LEFT D-pad LEFT D-pad DOWN D-pad DOWN D-pad DOWN D-pad DOWN D-pad RIGHT D-pad RIGHT D-pad RIGHT...
  • Page 12 Default Key Mapping Guide – Nintendo Switch Default Key Mapping Guide – Xbox One / Xbox 360...
  • Page 13 Default Key Mapping Guide – PlayStation 4 Default Key Mapping Guide – PlayStation 3...

  • Page 14: Precaution And Maintenance

    CORPORATION. ALTHOUGH THIS PRODUCT IS COMPATIBLE WITH SONY® OR PLAYSTATION® RELATED PRODUCTS, THIS PRODUCT IS NOT LICENSED, AUTHORIZED OR ENDORSED BY THOSE COMPANIES, OR THEIR RELATED ENTITIES. SPARKFOX LTD. FOXHILLS FARM BUSINESS PARK LONGCROSS ROAD, CHERTSEY, SURREY, KT16 0DN. TM & © 2021 SPARKFOX LTD. ALL RIGHTS RESERVED.
