Manual
Manual for the scales
GBS-2 Optima
Przedsiębiorstwo Pszczelarskie Tomasz Łysoń
Spółka z o.o. Spółka Komandytowa
34-125 Sułkowice, ul. Racławicka 162, Polska
www.lyson.com.pl, email;
lyson@lyson.com.pl
Siedziba Firmy Klecza Dolna 148, 34-124 Klecza Górna
KOD PIN
Advertisement
Summary of Contents for LYSON GBS-2 Optima
- Page 1 Manual Manual for the scales GBS-2 Optima Przedsiębiorstwo Pszczelarskie Tomasz Łysoń Spółka z o.o. Spółka Komandytowa 34-125 Sułkowice, ul. Racławicka 162, Polska www.lyson.com.pl, email; lyson@lyson.com.pl Siedziba Firmy Klecza Dolna 148, 34-124 Klecza Górna KOD PIN...
- Page 2 Manual for the scales GBS-2 Optima The scales consist of a table with a movable top fixed to a strain gauge and a controller including a display, GSM communication module as well as a battery compartment. 1. Preparing the scales for operation The scales will be ready for operation when all its components have been connected.
- Page 3 2. Start-up and configuration Having prepared the scales for operation in a proper manner, a short configuration must be performed. First, the scales must be switched on by changing the switch on the left side of the controller casing to SWITCH ON) (I) position.
- Page 4 • Setting the clock Having entered the PIN code correctly, the current date and time can be set. For this purpose, the four buttons located under the screen must be used Screen: Blinking letter T means the initial position of the cursor. In the first line: letter T, TIME In the second line: date and time to be set Buttons:...
- Page 5 Subsequently, the user’s telephone number must be provided. Messages on the device status shall be texted to it. Screen: Blinking letter S indicates the initial position of the cursor. The first line: letter S, text message (SMS) number Second line: telephone number in the form +XX XXX XXX XXX , 00XX XXX XXX XXX The underlined beginning of the number is the country code.
- Page 6 SELECT: deleting the messages. MINUS: moving to screen 2: SMS TEST PLUS: moving to screen 2: SMS TEST ENTER: pressing for a longer time resets the weight (TARA). Tare weight value is stored in non- volatile memory. • Screen 2: SMS TEST Screen: the first line: the screen number: 2, SMS TEST the second line: Press ENTER...
- Page 7 shall be sent once the main supply has been activated with the switch located on the scales casing. If a recipient has received such a text message it means that the device functions properly. The device periodically checks the weight status at 6:00 am, 1:00 pm and 8:30 pm and sends an informative text message at 8:30 pm.
- Page 8 device ID number. C: XX-XX-XXXX XX:XX Data and time when the report has been produced W06.00: XX.XX kg Weight measurement taken at 6:00 am W13.00: XX.XX kg Weight measurement taken at 1:00 pm W20.30: XX.XX kg Weight measurement taken at 8:30 pm D: +XX.XX kg Weight difference between the last measurement taken on the current date and the last measurement taken n the...
