- Page 1 Avantrek Fat-tire eBike LCD Display User Manual for Cybertrack 200 Contents sections: 1. Description (Page 1-2) Using The Display (Page 2-5 ) Safety Notes (Page 6) Diagnostic and Reference Guide Lists...
-
Page 2: Specifications
1. Product name and model Intelligent LCD display for e-bike; model: YL80C. 2. Specifications ● 36V/48V power supply ● Rated working current 15mA ● Maximum working current 30mA ● Leakage current at power-off <1uA ● Working current at the supply controller end 50mA ●... - Page 3 Front View Side View 4. Summary of functions and buttons 4.1 Function overview YL80C can provide a lot of functions for Avantrek Bikers. The indicating contents are as follows: ● Battery level indicator ● Motor power indicator ● Assist level adjustment and indication Speed indicator (including real-time speed, maximum speed and average speed) ●...
-
Page 4: General Operation
4.2 The screen is best explained by a diagram... Battery level indicator Fault indicator Speed unit indicator Speed indicator mile/h Trip distance Assist level indicator Maximum speed Average speed Push assistance indicator Numeric indicator Unit indicator 4.3 Button definitions There are five buttons on the operating unit of display YL80C, i.e., the on/off button , plus button , minus button , backlight button... - Page 5 5.2 Display Interface After the display is turned on, the display will show the real-time speed (mile/h) and the trip distance (mile) by default. Press the button , the information displayed will be switched between the trip distance (miles), ODO (mile), maximum speed (mile/h), average speed (mile/h) and riding power.
- Page 6 5.3 Walk Assist Mod Press and hold the button around 3 seconds, your e-bike motor will start to run at a uniform speed of 6km/h (3.73mph) and will continue to do so whilst you press that button. The display will show .
- Page 7 5.7 Error Code Indicator Getting error codes on your Avantrek Bike is not something you want to see. Sometimes an error code could mean a loose wire, or other times a sensor could be damaged. Use the error code chart below to find out what the error on your LCD display means.
Need help?
Do you have a question about the Cybertrack 200 and is the answer not in the manual?
Questions and answers
My ebike turns on and I can use the throttle when it first turns but won't go after that
If the AVANTREK Cybertrack 200 ebike turns on and allows throttle use initially but then stops moving, possible issues could include:
1. Battery level is too low to sustain motor power.
2. Motor power settings may have been accidentally changed.
3. Brake lever switch may be engaged, cutting motor power.
4. Chain or moving parts may not be properly lubricated, affecting performance.
Check battery charge, speed mode, brake switch, and ensure the chain and parts are properly maintained.
This answer is automatically generated
@Mr. Anderson Thanks that's what it was my battery was to low
Are there any fusses in the system
