EFI DPF12015R Instruction Bulletin

Instruction Bulletin
Digital Power Filter
Transient Voltage Surge
Suppressor (TVSS)
INTRODUCTION
PRECAUTIONS
INSTALLATION
© 2002 EFI Electronics Corporation All Rights Reserved
The networking copier has become critical to a business's communication
and documentation requirements. More than just a copier, this business
system serves a companies fax, printing and copying needs. Protecting
this sensitive business system has become an ever increasing challenge.
The new Digital Power Filter (DPF) provides unmatched protection for AC,
Telephone and Network lines. This protection is essential to protecting the
sensitive electronics and preventing interruption of this business
document and communication center.
NOTE: Do not mount on table tops.
• Intended for indoor use only.
• Never install telephone wiring during a lightning storm.
• Effective surge suppression requires correct wiring and proper
grounding from the AC wall outlet.
Failure to follow these precautions can result in minor or moderate
injury.
NOTE: Save these instructions for future reference.
Follow steps 1-4 for models with Tel/Network Protection. (see Table 1)
1. Connect the telephone line (from the wall jack) to the DPF's TEL/FAX
IN jack. (see Figure 1) NOTE: The DPF telephone jacks (RJ-14)
protect both lines of a 4 wire telephone cable.
2. Install a telephone cable from the DPF's TEL/FAX OUT jack to the
jack on the copy machine. If you have two telephone lines, make sure
this is a four wire cable.
3. Connect the network line (from the wall jack) to the DPF's NETWORK
IN jack. NOTE: The DPF jack (TIA-568, RJ45) protects 8 data lines.
To achieve maximum performance, make sure the network system
uses CAT 5 cable.
4. Install a network cable from the DPF's NETWORK OUT jack to the
copier's network IN jack.
8245-0061B 07/02 WC#EF09A
CAUTION
1
