Summary of Contents for Furniture of America CM7190T
- Page 5 1. Insert the rear left post (#2) into the slots along the ends of the front left post (#1). 2. Insert the bolts (#B) into the holes and secure using the Allen wrench. 2. Align the middle T legs (#10) to the 1.
- Page 6 Align (#4,5,9) to the holes indicated, then insert the bolts shown. Secure using the Allen wrench. Place the slats (#11) onto the slots. 1. Insert the rods (#A) into the wheel covers (#8). Turn right to tighten. 2. Insert the rods (#A) into the wheels (#7), then into the legs.
- Page 11 1. Insert the rear left post (#2) into the slots along the ends of the front left post (#1). 2. Insert the bolts (#B) into the holes and secure using the Allen wrench. 2. Align the middle T legs (#10) to the 1.
- Page 12 1. Align (#4,5,9) to the holes indicated, then insert the bolts shown. Secure using the Allen wrench. 2. Place the slats (#11,12) onto the slots, then insert 3. Align the legs (#13) a bolt (#B) with washer (#K) to the holes, then into each hole from below.
