Summary of Contents for Cannon Tools Neilsen CT2210
- Page 1 100LB SPIKE / SEEDER / SPREADER CT2210 INSTRUCTION MANUAL SAVE THESE INSTRUCTIONS AND PRECAUTIONS. READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE. Cannon Tools Limited Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K.
-
Page 3: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY We CANNON TOOLS LTD 20 Station road, Rowley Regis, West Midlands,B65 0JU.U.K. Declare that the following machine complies with the appropriate basic safety and health requirements of the EC Directive based on its design and type, as brought into circulation by us. -
Page 4: Specifications
1. SPECIFICATIONS Capacity: 100LB Spread Width: 32"/0.8M Rubber Tyre: 10" Coverage: 17500 Sq/ft Spikes: 9 spike wheels, 7" dia. Adjustable flow control lever with stop feature. Works with lawn/garden tractors and ATVs. 2. GENERAL SAFETY INSTRUCTIONS Warning: When using tool, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. - Page 5 in mind the operator or user is responsible for accidents or hazards occurring to other people or their property. INSPECT YOUR MACHINE. Check all bolts, nuts & screws for tightness before each use, especially those securing guards & drive mechanisms. Vibration during use, may cause these to loosen.
- Page 6 Only tow with recommended vehicles (Lawn/Garden Tractors and ATVs). Always secure and lock dump cart to the vehicle hitch before operating. This equipment is not designed to be used with zero-turn mowers. NEVER LEAVE MACHINE RUNNING UNATTENDED. Do not leave the machine unattended until it has come to a complete stop.
-
Page 7: Controls And Features Identification
3. CONTROLS AND FEATURES IDENTIFICATION Read this owner’s manual before operating the equipment. Familiarize yourself with the location and function of the controls and features. Save this manual for future reference. 1) Flows Control Lever – Controls the flow of material. 2) Poly Hopper –... - Page 8 4. ASSEMBLY 1. READ THE INSTRUCTIONS BEFORE ASSEMBLY Any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times, when using power equipment. Read this owner’s manual before attempting to assemble or operate the ...
- Page 9 3. ASSEMBLY STEP 1 1. Insert the Bolt M12X90 on one of the wheels into the hole on Wheel Bracket， make sure the wheel should be at the outside. Then lock it by a Nylon Lock Nut M12. Adjust the position of the Hex Nut M12 to make sure the wheel is not so tight and not so loose，just can swiveling flexible.
- Page 10 STEP 2 Insert a Hex Bolt M8X35 with a Flat Washer Φ8 through the hole on hopper, like the picture b showing. Assemble hitch tube by a nylon lock nut M8. Make sure do not tighten this lock nut at the moment. STEP 3 Insert a Hex Bolt M8X35 with a flat washer Φ8 through the hole on the hopper,like the picture c showing, and assemble the other piece of Hitch tube by...
- Page 11 STEP 4 1. Insert a Hex Bolt M8X45 with a Flat Washer Φ8 through the hole on the hopper, like the picture d showing,then assemble the Wheel Bracket and Operating Handle by a Nylon Lock Nut M8. The Lock Nut should not be tightened at this moment.
- Page 12 STEP 6 1.Put together 2 Hitch Tubes and the Adjustable Handle assembly, and lock them by the Hex Bolts M6 x 65 , Nylon Lock Nuts M6 and 2pcs of big washer Φ6 like the picture f showing. The bolts and nuts should not be tightened at this moment. 2.
- Page 13 STEP 7 1. Assemble 2 hitch brackets on each side of hitch tube assembly by 2Hex Bolt M8 x 45 and 2 Nylon Lock Nut M8, tighten the nylon lock nut M8. 2. Insert the pin through 2 brackets and lock it by a R Pin Φ3x75 STEP 8...
-
Page 14: Operation
5. OPERATION How to use your spiker/spreader? 1.Determine the approximate square footage of the area to be covered and estimate the amount of fertilizer or seed required. 2.Move the spreader to the area where application is to begin. 3.Loosen the plastic wing nut and move it to the desired setting. Retighten the nut. -
Page 15: Maintenance And Storage
6. MAINTENANCE AND STORAGE MAINTENANCE ● Rinse/dry inside and outside of the aerator spreader after each use. ● Regularly grease axle and wheel bearing area or when needed. ● Periodically check all fasteners for tightness. ● Annually clean and lightly lubricate spike assembly and shaft or when needed. ●... -
Page 16: Parts Drawing
7. PARTS DRAWING... - Page 17 PARTS LIST Part# Description Part# Description Hopper & Side Plate Nylon Lock Nut M12 Assembly Axle & Gear Assembly Spring Cotter Pin Ø4x30 Fluted Disc & Fixed Spacer Assy Screw M5x6 Small Sprocket Wheel Spacer Scratch Board Big Sprocket Wheel Spacer Flat Washer Ø12 Bushing Chain Scratch Board Support...
- Page 18 Flat Washer Ø8 Hex Bushing Hex Bolt M8X35 Fluted Disc Spacer 1 (Short) Hex Bolt M8X40...
- Page 20 CANNON TOOLS LTD Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K. Made in China...
