- Page 1 EF-6L EF-6L-2 Electric Fryer User’s Manual 2015.A...
- Page 2 Dear User & Client, Firstly, thanks for purchasing and using our product. All the information and guidelines of this user’s manual comply with certain applicable regulations, which come out from our long-term accumulated knowledge and experience as well as current project development situations.
- Page 3 Warning ◆ Any self-modification, wrong installation, adjustment or maintenance can lead to property loss or casualty. Please contact the manufacturer for any adjustment or maintenance, and have the work done by a trained & qualified person. ◆ For your safety sake, please keep the machine away from any liquid, gas or other object, which is flammable or explosive.
-
Page 4: Table Of Contents
Table Of Contents 1. Functional Introduction…………………………………....…1 2. Structure Schematic Diagram & Working Principle….....…1 2.1 Structure Schematic Diagram……………………...…………1 2.2 Working Principle……………………………………..………2 2.3 Copyright Protection…………………………………...………2 3. Technical Parameters…………....………………...…3 4. Precautions & Recommendations ……………………..…..4 4.1 Operation Tips………........…..………4 4.2 Storage & Transport……………………………………...……4 4.3 Installation…………………………………………..………5 5. -
Page 5: Functional Introduction
1. Functional Introduction This product is manufactured by our company, which is combined with advantages from home and abroad. It is novel in design, reasonable in structure, easy in operation, durable in using, fast in heating up, saving in energy and convenient in maintenance. The thermostatic control makes the temperature freely adjustable at a certain range according to food requirement. -
Page 6: Working Principle
2-Tank Fryer 英联斯特(广州)餐饮设 材 vesta (Guangzhou) C 料 Equipment Company 投 影 EF-4L6L8L 标记 处数 签 名 日期 更改文件号 双缸电炸 设计 标准化 版本号 重量(g) 比例 2.2 Working Principle 审核 EF-8L-2-00 共 张 第 张 工艺 批准 Heat produced by energization of heating element(s) in the oil is transferred to the oil to rise the temperature. -
Page 7: Technical Parameters
3. Technical Parameters Electric 1-Tank Electric 2-Tank Name Name Fryer (1-Basket) Fryer (2-Basket) Model EF-6L Model EF-6L-2 Voltage（V） Voltage（V） Power（kW） 1.75 Power（kW） 1.75×2 122℉(50℃) ～374 122℉(50℃) ～374 Set Temperature Set Temperature ℉(190℃) ℉(190℃) Tank Tank Tank Size (mm) 240×300×150 Tank Size (mm) 240×300×150... -
Page 8: Precautions & Recommendations
4. Precautions & Recommendations 4.1 Operation Tips Installation and maintenance shall be done by professional technicians. If necessary, contact the technicians. Grounding connection of the device must comply with the local regulations. (Warning: Improper operation, installation or maintenance may cause property damage, injury or death etc.. Read this instruction manual thoroughly before installing, operating or servicing this equipment.) This product is a commercial machine that needs to be operated by trained cook. -
Page 9: Installation
4.3 Installation The supply voltage should comply with the working voltage of the appliance. After installation, check that whether the connection is loose, whether the voltage is normal and whether the safety grounding is reliable. The fixed arrangement of wire should be equipped with an all-pole disconnecting switch with a contact opening of 3mm on its poles. -
Page 10: Function
in tank. Then, pull out the electrical box from the slot at rear of the bottom case. At this moment, the heating elements are separated from the tank body completely with the electrical box, put it on a clean area. Then lift out the tank for a thorough cleaning. For safety and durability sake, users should remove the residues in tank and dirt on heating elements regularly to keep the tank and elements in long-term clean state. -
Page 11: Trouble Shooting
8. Trouble Shooting 8.1 Electrical Diagram 8.2 Common Fault thermostat heating element micro switch indicator TEMP. limiter 2015.A... - Page 12 Symptoms Causes Solutions The plug is not in Power on, but the power place. Plug in again. indicator is not on and the The micro switch is in Regulate limit appliance does not heat contact. distance of the switch. disconnected. Connection of heating Fasten the connecting The heating indicator is...
