Brandywine NTA-100 User Manual

Network time adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Guide
Network Time Adapter
Model NTA-100
P/N 001-0076
Revision F
May 2005
Brandywine Communications
2230 South Fairview Street
Santa Ana, CA 92704
(714) 755 1050
(714) 755 0175
http://www.brandywinecomm.com
1
MANUAL P/N 900000012 REV F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NTA-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Brandywine NTA-100

  • Page 1 User Guide Network Time Adapter Model NTA-100 P/N 001-0076 Revision F May 2005 Brandywine Communications 2230 South Fairview Street Santa Ana, CA 92704 (714) 755 1050 (714) 755 0175 http://www.brandywinecomm.com MANUAL P/N 900000012 REV F...
  • Page 2 Revision History REVISION DATE COMMENTS 03-27-03 Original release of NTA-100 user guide. 09-02-04 Revision of entire user guide. 12-01-04 Revised reference section of the user guide. 12-09-04 Revised time section of the user guide. 03-11-05 Revised reference section of the user guide.
  • Page 3 Safety Warnings WARNING: This unit contains lethal AC voltages. Disconnect the unit from the AC supply before removing the cover. WARNING: The lightning flash with an arrowhead inside of an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure. The “dangerous voltage”...

  • Page 4: Table Of Contents

    Table of Contents Introduction..........................5 Specifications ..........................6 Technical ..........................6 LED Indicators ........................7 Connections........................8 2.3.1 Power ..........................8 2.3.2 Ethernet..........................8 2.3.3 Antenna..........................8 2.3.4 Ethernet and Antenna Connections Example..............8 2.3.5 Output ..........................8 Unpacking and Installation ......................9 Unpacking...........................9 Installation ..........................9 3.2.1 IPSetup.exe........................10 3.2.2 Web Browser........................11 3.2.3 Latest Version of Java Software...................11 3.2.4...

  • Page 5: Introduction

    Introduction The Network Time Adapter (NTA-100) is used as a Network Time Protocol (NTP) client. When the NTA-100 has been fully configured, the NTA-100 receives its time from the NTP Time Server and distributes this time via the serial port to wall displays or other serial devices.

  • Page 6: Specifications

    Specifications Technical • Unit Numbers o Model Number: NTA-100 o Part Number: 001-0076 • Physical Characteristics o Size: 5.25” x 5.38” x 1.12” (W x L x H) o Weight: typically 1 lb o Power: 85-264 VAC 50/60 Hz • Synchronization o Source: NTP Version 3 o Synchronization Accuracy: typically ±20 milliseconds...

  • Page 7: Led Indicators

    LED Indicators The table below describes each LED indicator on the front panel of the NTA-100. COLOR ACTIVITY COMMENT POWER GREEN NTA-100 does not have power. NTA-100 has power. LINK GREEN No link exists between the NTA-100 10/100 Base-T port and network.

  • Page 8: Connections

    Connections 2.3.1 Power Insert the power cord of the NTA-100 into an electrical socket to power up the unit. The Power LED indicator will illuminate green. 2.3.2 Ethernet Connect one end of an Ethernet cable to the NTA-100 Ethernet port. Connect the other end of the Ethernet cable to a hub.

  • Page 9: Unpacking And Installation

    • 1 NTA-100 • 1 user guide • 1 wall mount template sheet Installation The NTA-100 is shipped with a label that indicates the IP address stored in the unit. The default settings are: • IP Address: 192.168.1.1 • Subnet Mask: 255.255.255.0 •...

  • Page 10: Ipsetup.exe

    To transfer the NDK Settings to the selected NTA-100, click the Set button. Wait 15 seconds for the NDK Settings to be loaded into the NTA-100 and for the NTA-100 to restart. Verify that the NTA-100 has the correct NDK Settings and is connected to the network by clicking the Search Again button.

  • Page 11: Web Browser

    3.2.4 Mounting The NTA-100 may be either mounted on a tabletop or wall. To mount the unit on a wall, use the wall mount template sheet provided. Insert two or four #6 screws into the wall on the 5” centers, as shown in the wall mount template sheet.

  • Page 12: Configuration

    Configuration Please note that the unit will automatically reboot when a serious error or lock up occurs. This allows the unit to reset and run instead of locking up. Setup The Setup tab consists of two sections, the System and IP Address. This tab allows you to modify setup information for the Network Time Adapter.

  • Page 13: Ip Address

    Device IP Address, Device Subnet Mask, and Device Gateway. If the DHCP Enable radio button is selected, the NTA-100 will retrieve its configurations from the DHCP server. If the DHCP Disable radio button is selected, the user must manually enter the configurations for the device.

  • Page 14: Time

    Time The Time tab consists of four sections, the Serial Output (TOD), Time Zone Settings, Daylight Saving Time, and Daylight Saving Time (Advanced). This tab allows you to modify the time settings for the Network Time Adapter. To save all modifications made to the Time screen, click the Submit button. To undo all modifications made to the Time screen, click the Reset button.

  • Page 15: Serial Output (Tod)

    4.2.1 Serial Output (TOD) The Serial Output (TOD) consists of one field, the Format, four combo boxes, the Baud, Data Bits, Stop Bits, and Parity, and one check box, the Serial Output. The Format refers to the format of the time outputted from the Network Time Adapter when the serial port is being used.

  • Page 16: Time Zone Settings

    4.2.2 Time Zone Settings The Time Zone Settings consists of two fields, the Time Zone text field and Time Zone combo box. The Time Zone text field allows the user to enter the Standard Time offset from the Universal Time. The Time Zone combo box allows the user to select either hour or minute.

  • Page 17: Daylight Saving Time

    4.2.3 Daylight Saving Time The Daylight Saving Time consists of the “automatically adjust clock for daylight saving changes” check box. If the user clicks the check box, the system will automatically adjust the time of the Network Time Adapter when daylight saving time occurs. If the user does not click on the check box, the system will not automatically adjust the time of the Network Time Adapter when daylight saving time occurs.

  • Page 18: Password

    Submit button. To undo all modifications made to the Password screen, click the Reset button. IMPORTANT INFORMATION: The default user name and password for the system is BRANDYWINE and the user must always enter a user name and password when submitting changes to the system.

  • Page 19: Reference

    Reference The Reference tab consists of three sections, the Reference, Reference Status, and Reference Settings. This tab allows you to modify the reference for the Network Time Adapter. Please note that while the Network Time Adapter is acquiring time from the references the Valid Time LED indicator will be extinguished.

  • Page 20: Reference

    4.4.1 Reference The Reference consists of two fields, the Select reference and Reference Stable. The Select reference allows the user to select one of the three references to acquire time from. The three references used by the system are NTP Time Server, Serial Port Input, and GPS (model NTA- 100GM only).

  • Page 21: Reference Status

    The GPS reference uses a GPS receiver to synchronize the internal clocks. The stratum level for this reference is 1. To use the GPS reference, the GPS option must be installed. The Reference Stable may be either ‘TRUE’ or ‘FALSE’. It is ‘TRUE’ when the Network Time Adapter has acquired the time from a reference.

  • Page 22: Open Satellite Status

    4.4.2.1 Open Satellite Status The system provides a comprehensive view of the GPS receiver. A typical GPS receiver screen is displayed below. The upper section of the screen displays different tracked satellites and their signal strengths. The typical GPS Signal Strength for a satellite that is overhead and has an unobstructed view is between 40 and 50.

  • Page 23: Gps Settings

    4.4.2.2 GPS Settings The figure below is displayed when the user clicks on the GPS Settings link. The GPS Settings screen consists of two sections, the Settings and Version. This screen allows the user to select a position mode, set a position, cold start, set the GPS lock criteria, and view the version number of the GPS receiver.
  • Page 24 4.4.2.2.1 Settings The Settings consist of six fields, the Position Mode, Enable mobile mode, Position, Cold Start, Tracking at least X satellites, and using T-RAIM. A Set Position link is available for the Position setting. A Cold Start link is available for the Cold Start setting. The following two sections describe the two links.
  • Page 25 4.4.2.2.1.1 Position The figure below is displayed when the user clicks on the Set Position link. The Position consists of seven fields, the Latitude, North, South, Longitude, West, East, and Altitude. This link allows the user to set the position of the GPS receiver. Please note that the input format is DD.DDDDDD. The latitude and longitude are in degrees and the altitude is measured in meters.

  • Page 26: Reference Settings

    4.4.3 Reference Settings The Reference Settings consists of six fields, a NTP Query Interval and five NTP Server Address Pool entries. The NTP Query Interval is a number (in seconds) entered by the user. The NTP Query Interval will be invalid for the first 300 seconds because the NTP client will be sampling the time once every second and adjusting the internal clocks in the NTP servers using the internal Proportional Integral algorithm.

  • Page 27: Help

    Help The Help tab provides the user with help while using difficult areas in the system. Help links are located throughout the entire system so the user has access to the Help screen whenever the user encounters a problem. Once the user clicks on the help link the user will be automatically redirected to the Help screen.

  • Page 28: Uploading Firmware

    1. Double click on the AutoUpdate icon and the AutoUpdate V2.0 screen will be displayed. 2. Enter the IP address of the NTA-100 in the IP address field. If the user does not know the IP address, press the Find button and the Find Netburners screen will be displayed. Locate and click on the IP address of the unit and click the OK button.
  • Page 29 3. Enter the path name to the new released file. If the user does not know the path name, press the Browse button and the Open screen will be displayed. Locate and click on the file and click the Open button. The File Name field will be completed for you. 4.

  • Page 30: Defaulting Memory To Factory Default Settings

    FOR SECURITY PURPOSES DETACH THIS PAGE Defaulting Memory to Factory Default Settings The NTA-100 memory may be defaulted to factory default settings using the web browser based interface. To default the NTA-100 memory to factory default settings, follow the steps listed below.

  • Page 31: Drawings

    Drawings FIGURE DESCRIPTION NTA-100 Front Panel NTA-100 Rear Panel NTA-100 Mechanical Outline MANUAL P/N 900000012 REV F...
  • Page 32 Figure 1 NTA-100 Front Panel Figure 2 NTA-100 Rear Panel MANUAL P/N 900000012 REV F...

  • Page 34: Wall Mount Template Sheet

    Wall Mount Template Sheet MANUAL P/N 900000012 REV F...
