- Page 1 | w e s i m p l i f y c o n s t r u c t i o n Mounting instruction InCapsa...
-
Page 2: Table Of Contents
| w e s i m p l i f y c o n s t r u c t i o n Description Lindab InCapsa is a system that makes it easier to assemble, suspend and cover a ventilation syste Lindab InCapsa consists of few products that can easily be assembled in different combi- nations to fit most rooms. -
Page 3: Components
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Components U-panel, CUP Panel, CP Outer corner, Inner corner, Rail, CSR Gable, CG Console, CC U-console,... -
Page 4: Planning And Measurement
• Metal shears • Lindab supply and exhaust air valves Planning and measuring 1. Carefully plan where you intend to mount the duct system in the room. 2. Ideally starting in a corner and letting the rails and panels meet in the centre of the straight sections. -
Page 5: Making Holes
| w e s i m p l i f y c o n s t r u c t i o n min. For InCapsa to be installed some space from the ceiling is required. Any obstacles should be moved or a solution other than InCapsa should be used. -
Page 6: Rails And Consoles
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Rails and consoles Mounting consoles 1. Mark the wall and the ceiling where the consoles are to be attached. The easiest way to locate the position of the fixing hole is to use a console. - Page 7 l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Mitring rails in corners Where rails meet in a corner, the edges can be mitred, allowing the joints to line up with the corners.
-
Page 8: Support Plates
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Wall rails Start from the corner and let the rail go 15 mm out. -
Page 9: Duct System
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Duct system 1. Bend the console’s folding plates so that you can insert the duct system into the con- soles. - Page 10 l i n d a b | w e s i m p l i f y c o n s t r u c t i o n 6. Attach two inner joints to the end of the final panel . 7.
-
Page 11: Crossing The Ceiling
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Crossing the ceiling 1. Mount two u-concoles using screws loosesly in the ceiling where the duct is supposed to be suspended. -
Page 12: Dimensional Transitions
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Dimensional transitions Perpendicular through wall 1. Panel dimension 2. Duct dimension 3. - Page 13 l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Straight through wall 1. Panel dimension 2. Duct dimension 3. Panel dimension 4.
- Page 14 l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Panel to u-panel 1. Panel dimension 2. Duct dimension 3. Duct dimension in u-panel 4.
-
Page 15: Gable
If the duct system ends in the middle of a wall, you can choose to either let the panels continue to the next wall or to use a gable. Lindab recommends finishing at a wall to achieve a more pleasing appearance. 1. Keep the gable vertically against the ceiling and wall using a spirit level. - Page 16 l i n d a b | w e s i m p l i f y c o n s t r u c t i o n 5. Mount the wall rail in the gable and the console. Attach the second con- sole tightly against the wall and ceiling.
-
Page 17: Electrical Installations
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Electrical installations 180mm If a rail passes over an electrical box cover, leave a gap by the cover that is as long as a access rail. -
Page 18: Vertical Obstacles
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Vertical obstacles If you encounter vertical water pipes, make a hole measuring about 80×30 mm in the panel that bypasses the pipes. -
Page 19: Fire
l i n d a b | w e s i m p l i f y c o n s t r u c t i o n Fire Each country has is its own fire regulations and they must allways be followed.
