Summary of Contents for Nothern Industrial tools 150508
- Page 1 5-SHELF RACK OWNER’S MANUAL WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 150508...
- Page 2 Thank you very much for choosing a NORTHERN TOOL + EQUIPMENT CO., INC. Product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.
- Page 3 Figure A Figure B STEP 2 Start by adding a laminate shelf to the level previously built, then continue working by adding the second level using two (2) beams and two (2) braces in the post slots of your desired location. Again place the rivets of the beams and braces into the post slots with the shelf ledge facing up and tap lightly to seat the rivets.
- Page 4 STEP 4 Add a laminate shelf to the level previously built level, then continue by adding the fourth and fifth level to the unit using two (2) beams and two (2) braces per level. Tap lightly to properly seat the rivets and add the final laminate shelves to the unit. Optional anchor hardware is supplied with this unit so the unit can be fastened to a wall if necessary.
- Page 5 Parts List Description Qty. Part Number Part Size Beams RUBE3502 35 1/8" Braces RUBE1702 17 1/8" Post RUPT3602S 36" Laminate Shelves RPB21836LM 17 1/2" × 33 1/2" Wall Anchor. Screw. Washer Post Connector PC101 For replacement parts and technical questions, please call 1-800-222-5381. Northern Tool + Equipment Co., Inc.
