Summary of Contents for Rubicon netgate XG-1537
- Page 1 Secure Router Manual XG-1537 © Copyright 2022 Rubicon Communications LLC Jun 24, 2022...
-
Page 2: Table Of Contents
OUT OF THE BOX 1 Getting Started 2 Input and Output Ports 3 Connecting to the Console Port 4 Additional Resources 5 Warranty and Support... - Page 3 Secure Router Manual XG-1537 This Quick Start Guide covers the first time connection procedures for the Netgate 1537 1U Secure Router and also provides information needed to stay up and running. © Copyright 2022 Rubicon Communications LLC...
-
Page 4: Getting Started
CHAPTER GETTING STARTED Use the following steps to configure the TNSR Secure Router. 1. To configure the Network Interfaces and gaining access to the Internet, follow the instructions provided in the Zero-to-Ping documentation. Note: Not all steps in the Zero-to-Ping documentation will be necessary for every configuration scenario. 2. -
Page 5: Input And Output Ports
CHAPTER INPUT AND OUTPUT PORTS Contents • Input and Output Ports – Default Configuration Network Ports Other I/O Status LEDs – With CPIC-8955 Accelerator Card with Intel® QuickAssist Technology – With 2 Port Intel 1 Gbps Ethernet Expansion Card – With 2 Port Intel 10 Gbps X710 SFP+ Expansion Card –... - Page 6 OS and not available in TNSR. Though technically optional, the best practice is to have one for accessing and updating the host OS. 2.1.2 Other I/O Port I/O Type 2x USB 3.0 IPMI Reset & Power buttons Status LEDs (see table below) 2.1.3 Status LEDs © Copyright 2022 Rubicon Communications LLC...
- Page 7 Indicates power is being supplied to Illuminated the system power supply units. This LED should normally be illuminated when the system is operating. Indicates no power is being supplied to the system power © Copyright 2022 Rubicon Communications LLC supply. System is powered off.
- Page 8 Note: Default Host OS Interface is eno1. The Host OS Interface is one network interface that is only available to the host OS and not available in TNSR. Though technically optional, the best practice is to have one for accessing and updating the host OS. © Copyright 2022 Rubicon Communications LLC...
- Page 9 GigabitEthernet7/0/1 RJ-45 1 Gbps eno3 TenGigabitEthernet3/0/0 SFP+ 10 Gbps eno4 TenGigabitEthernet3/0/1 SFP+ 10 Gbps Note: Default Host OS Interface is eno1. The Host OS Interface is one network interface that is only available to © Copyright 2022 Rubicon Communications LLC...
- Page 10 Note: Default Host OS Interface is eno1. The Host OS Interface is one network interface that is only available to the host OS and not available in TNSR. Though technically optional, the best practice is to have one for accessing and updating the host OS. © Copyright 2022 Rubicon Communications LLC...
-
Page 11: Connecting To The Console Port
CHAPTER THREE CONNECTING TO THE CONSOLE PORT Connecting to the VGA console is identical to connecting any computer to a monitor. Connect the VGA cable (DB-15) between the Netgate appliance and the monitor. Use a USB or PS/2 keyboard and mouse as applicable to the hardware. -
Page 12: Additional Resources
CHAPTER FOUR ADDITIONAL RESOURCES 4.1 Professional Services Support does not cover more complex tasks such as network design and conversion from other firewalls. These items are offered as professional services and can be purchased and scheduled accordingly. https://www.netgate.com/our-services/professional-services.html 4.2 Netgate Training Netgate training offers training courses for increasing your knowledge of Netgate products and services. -
Page 13: Warranty And Support
CHAPTER FIVE WARRANTY AND SUPPORT • One year manufacturer’s warranty. • Please contact Netgate for warranty information or view the Product Lifecycle page. • All Specifications subject to change without notice. Enterprise Support is included with an active software subscription, for more information view the Netgate Global Support page.
