  • Page 1 ARC-SP188 UHD 1x8 HDMI Splitter User manual V1.0ep...
  • Page 2 Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. I. Introduction This 1 by 8 HDMI UHD Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to eight HDMI outputs.
  • Page 3 Support 3D frame sequential video format up to 1080p@60; Support high resolution VESA mode video format up to QSXGA@60Hz; Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio; Supports smart EDID control; III. Package UHD 1x8 HDMI Splitter ------------------------------------------------------------------ 1PC 12V2.5A DC Power adapter ------------------------------------------------------------- 1PC Operation Manual ------------------------------------------------------------------------- 1PC IV.
  • Page 4 ESD Protection Human Body model: ±8 kV (air-gap discharge) ±4 kV (contact discharge) Power Supply 12V/2.5A DC (US/EU standards, CE/FCC/UL certified) Dimensions 105 mm (W) × 245 mm (D) × 16 mm (H) Weight 630g Chassis Material Metal Operating Temperature 0 °C~40 °C/ 32 °F~104 °F Storage Temperature −20 °C ~ 60 °C/−4 °F ~140 °F...
  • Page 5 V. Operation controls and Functions Front Panel & Rear Panel POWER LED: This blue LED illuminate when the device is connected with power supply. OUT LED: These blue LEDs will light up to indicate which HDMI outputs are connected to an active TV/display/monitor.
  • Page 6 mode, the video output will be set to 1080p@60Hz and the audio output at LPCM 2CH Stereo. Use this mode if there are display problems in TV Mode. EDID TV: When in 'TV' mode, the unit will read the EDID settings of the display device connected to HDMI OUT 1.
  • Page 7 VI. Application Example www.digitalworld.net.nz...
