Instruction Manual
Refrigerator
No frost
Model
R-WB640PT1
Thank you very much for purchasing the Hitachi refrigerator.
Before installation and usage, please read the user's guide carefully
for the correct usage.
Maintenance work must only be carried out at works
by well-trained maintenance work.
Content
Preparation for Use
Warning and Caution for Safety..........
Preparations before Use.....................
Installation.......................................................
Beginning........................................................
Food Storage..................................................
Location of Food Storage....................
Operation
How to use the Control panel.............
Name and Function of Display........................
Temperature Control.......................................
Other functions...................................
Freezer Compartment.......................
How to use Ice Maker................................
Swing Partition Suggestion.........................
How to remove part....................................
Maintenance
Care and Maintenance.........................
Cleaning.........................................................
Troubleshooting.................................
Dew or Frost is generated...................
Service Center.................................. 16
For household use only
R600a
Refrigerant
2
4
4
4
4
4
5
5
5
6
8
9
9
10
11
11
13
15
Advertisement
Table of Contents
Related Manuals for Hitachi R-WB640PT1
Summary of Contents for Hitachi R-WB640PT1
-
Page 1: Table Of Contents
Troubleshooting......... Dew or Frost is generated....Service Center........16 For household use only Thank you very much for purchasing the Hitachi refrigerator. Before installation and usage, please read the user’s guide carefully for the correct usage. R600a Maintenance work must only be carried out at works Refrigerant by well-trained maintenance work. -
Page 2: Warning And Caution For Safety
●This may impair electricity insulation and cause electric shock or fire. moisture. (Please consult with a retailer or Hitachi Service Center.) Power Cord and Power Plug ... To avoid fire, electric shock. - Page 3 ● If transporting in a vehicle, do not load the refrigerator on its side. This could damage the compressor. When replacing lamps (LED) is required. ■ When lamps (LED) need to be replaced, please contact Hitachi Service Center. Such as old cloth...
-
Page 4: Preparations Before Use
More than 70 mm this refrigerator when using it in place with high humidity or moisture. Adjustable leg (Please consult with retailers or Hitachi Service Center.) CAUTION 7) Adjusting the adjustable legs to keep the left/right refrigerator door level, ■ Without adjusting the legs, door heigh may not be level, or there may be abnormal When installing, vibration or noises depending on floor conditions.Follow the instructions below. -
Page 5: How To Use The Control Panel
How to use the Control Panel Name and Function of the Control Panel Control Panel Setting Refrigerator Temperature button Setting Freezer Setting Selectable Zone Temperature button Compartment button Setting Quick Mode “Energy Saving” Button Refrigeratorbutton Setting Quick Mode “Ice Maker” Buttom Freezer button ●... -
Page 6: Other Functions
Other Functions ■ Door Alarm and ECO Alarm Function If the door is left open for more than 1 minute, the alarm system will inform the user by the sound and digital display. After 1 minute PeepPeepPeep All LED on display- ●... - Page 7 Other Functions ■ Quick Mode Refrigerator When you want to freeze food or make ice quickly, use this function. Quick Cooling : Quick Cooling Press “Quick Mode Refrigerator” Button Put food on the quick cooling “Quick Cooling” corner is located on the upper part of the refrigerator compartment.
-
Page 8: Refrigerator/Selectable Zone/Freezer Compartment
Other Functions Energy Saving ■ Recommend to use this function in case of low storage volume, or a long vacation when the doors are not opened for long time. ● No door open. Press “Energy Saving” button ● No control panel operation. again for stop Energy Saving operation, lamp light is off. -
Page 9: How To Use Ice Maker
Refrigerator/Selectable Zone/Freezer Compartment How to use Ice Maker 1. Remove the water tank. 2. Slide the Lid and fill the water. Tank-full line ● Hold the handle and pull the water tank towards yourself. ● Fill the water not over the full line. 3. -
Page 10: How To Remove Part
Refrigerator/Selectable Zone/Freezer Compartment How to remove part Vegetable/Dry-Vegetable/Fresh select Drawer Ice Bank ■ To remove Ice Bank, pull Upper Freezer Drawer all the way out, To remove Vegetable Drawer ,Dry-Vegetable Drawer and Fresh select ■ then lift Ice Bank upward. Drawer pull it all the way out, then lift it upward. -
Page 11: Care And Maintenance
Care and Maintenance Cleaning WARNING Make sure to unplug the power plug when maintaining the refrigerator. When dirt is found Wipe off it immediately. It is recommended to clean the hidden places once a year. Power plug Door gaskets ■ This area is prone to smudges, ■... - Page 12 Care and Maintenance Ice maker WARNING WARNING Do not touch the mechanical parts of the automatic ice maker. (Touching these parts might result in injury.) Water tank In order to prevent grime and hard water stains In order to prevent grime and hard water stains from building up, from building up, make sure to clean the Water Tank make sure to clean the Water Filter once per week.
-
Page 13: Troubleshooting
Troubleshooting Before you call for service, please check the following items: Problem Things to check Instructions Page ●Check the fuse box for blown fuse ● Is the refrigerator plugged in properly? The refrigerator does not get cold or tripped circuit breaker. at all. - Page 14 Troubleshooting This is not a malfunction of the refrigerator: Problem Things to check Instructions Page ● You may feel that the operation sound is loud because the compressor operates in high-speed under the following conditions: the refrigerator does not cool fully on the occasion such as using it for the first time, Annoying sound is generated opening/closing the door frequently, the surrounding...
-
Page 15: Dew Or Frost Is Generated
Dew or Frost is generated General operation Please check here Possible causes and / or Recommended solutions Check that the wrapping paper of the food is not getting The door of the freezer caught in order not to make gap between door and compartment was not left door gasket when you close the door. -
Page 16: Service Center
● R600a refrigerant is flammable. But the refrigerant is sealed up by the refrigerant circuit, and never leaks by usual use. In case of the refrigerant circuit being damaged by any chance, please avoid using fire or electric product, open the window and ventilate. Afterwards, please contact Hitachi Service Center.
