Summary of Contents for Atim Cloud Wireless ACW/SF8-THM-I
- Page 1 Atim Cloud Wireless ® Temperature & Humidity Sensor User's guide Models concerned : ACW/SF8-THM-I ACW/LW8-THM-I ACW/SF8-THM-O ACW/LW8-THM-O...
-
Page 2: Table Of Contents
ABLE OF CONTENTS Version history of this document ............................2 Disclaimer ..................................2 Trademarks and copyrights ............................... 2 Declaration of conformity ..............................3 Environmental recommendations ............................. 4 Environment Radio Technical specifications ..............................5 Product Temperature and humidity sensor Housing....................................6 Identification Assembly and disassembly Installation... -
Page 3: Version History Of This Document
Trademarks and copyrights ATIM radiocommunications®, ACW ATIM Cloud Wireless®, ARM Advanced Radio Modem® are registered trademarks of ATIM Sarl in France. Other trademarks mentioned in this document are the property of their respective owners. -
Page 4: Declaration Of Conformity
Declaration of conformity All ACW (Atim Cloud Wireless®) products comply with the regulatory requirements of the R&TTE Directive 1999/5/EC Article 3 : 1 Safety (Article 3.1a of Directive 1999/5/EC) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic compatibility (Article 3.1b of Directive 1999/5/EC) -
Page 5: Environmental Recommendations
Environmental recommendations a. Environment Observe the storage and operating temperature ranges of the products. Failure to do so may result in operational disruption and even damage to the equipment. This equipment is not designed for an outdoor environment! Follow the precautions and instructions listed below to ensure your safety and that of your environment and to prevent damage to your equipment. -
Page 6: Technical Specifications
Technical specifications a. Product Dimensions 80 x 80 x 35 mm Weight 100g Antenna Built-in (¼ wave) Temperature -20°C to +55°C (operation) -40°C to +70°C (storage) Housing and Mounting ABS - Wall mounted Power supply 1 pack of Lithium batteries 3.6V / 7.2Ah (Storage mode - battery depassivation) Sigfox : 100 bits/s Radio rate LoRaWAN: 300 bits/s to 10 Kbit/s... -
Page 7: Housing
Housing a. Identification The product ID can be seen on the outer label on the back of the product, inside on the electronic board and in the status bar of the configuration software. Product reference : Sigfox or LoRaWAN version Datamatrix : ID sigfox or DevEUI LoRaWAN Product revision number... -
Page 8: Assembly And Disassembly
b. Assembly and disassembly The box is mounted on a flat, vertical wall. Place and fix the back of the box on the wall following the direction indicated by the arrows on 60mm the back. Use Ø 5 mm screws. Bouton poussoir The holes of the cover must be on the right side, in the same direction... -
Page 9: Installation
c. Installation For best results, it is recommended to install the box without environmental obstruction and to place it at a minimum height of 1.5m. The antenna is integrated in the box. The product should be mounted on a vertical support, or fixed to a wall. WARNING Do not install on a metal pole. -
Page 10: Operation
Operation The ACW-THM sensor measures a temperature and a humidity rate at the time "t" and sends these data by radio on the Radio network (Sigfox or LoRaWAN). In this version, only the periodic mode is available as well as the life frame. a. -
Page 11: Frame Format
Frame format Sigfox and LoRaWAN Frame format Type Description octet 0 octet 0 octet 1 octet 2 octet 3 octet 4 octet 5 (dec) (hex) (hex) (hex) (hex) (hex) (hex) Life frame Keep Alive Supply voltage IDLE (mV) Supply voltage TX (mV) Test pattern Test Counting... -
Page 12: Downlink
Downlink The operation of the Downlink is explained in the document ATIM_ACW-DLConfig_UG_EN. The parameters specific to the ACW-THM are the following: a. Frequency of emission of the line frame Parameter code (Octet 1) Parameter value (Octet 2) 0x00 = once a day 0x03 0x01 = once every 4 days 0x02 = once every 8 days... -
Page 13: Example Of Data Visualization On The Acw Platform
Example of data visualization on the ACW platform ATIM_ACW-THM_UG_EN_V1.3... -
Page 14: Technical Support
Troubleshooting Radio data is not received • Check if the power supply is properly connected to the modem • Check if the modem has been registered to the network • Check if network coverage is available • Check if the light is illuminated when transmitting Technical support For any information or technical problem, you can contact our technical support on this page: Technical support | ATIM...
