x1 Kaya Fixed Screen
Tools you will need:
0
• Phillips head screw driver
• Metal Saw
• Drill
1
x2
h = (Floor to ceiling height ) - 2" [50mm]
a.
Max Ceiling Height Is 120" [3050mm]
Longer Tubes Available On Request
PAGE 1
Kaya Fixed Screen install guide for all sizes.
h
CONTENTS
Tube Gliders
Aluminum Tube
x2
Adjustable feet
Safety
protection you will need:
• Safety Glasses
b.
Slide tubes down into the Kaya
Panel.
KAYA
FIXED SCREEN
INSTALL INSTRUCTIONS
x4
x4
PET Panel
x1
Advertisement
Table of Contents
Summary of Contents for Func KAYA
- Page 1 KAYA FIXED SCREEN INSTALL INSTRUCTIONS Kaya Fixed Screen install guide for all sizes. CONTENTS Tube Gliders Aluminum Tube Adjustable feet x1 Kaya Fixed Screen PET Panel Tools you will need: Safety protection you will need: • Phillips head screw driver •...
- Page 2 KAYA FIXED SCREEN INSTALL INSTRUCTIONS ZINTRA BAFFLE (V2) BOLT NSTALLATION INSTRUCTIONS www.baresque.com Ensure tubes are Insert Glider at the top and Ensure Gliders are flat and within the PET panel bottom of the tube. straight Insert adjustable feet. Adjust feet to be able to smaller than the floor to ceiling height.
- Page 3 NSTALLATION INSTRUCTIONS www.baresque.com (Top + Bottom) Insert Kaya screen into position. Pre Drill Foot (Top + Bottom) Adjust feet until Kaya panel is tight. BOTTOM Screws are not included- Installer to supply based on-site conditions. Screw and secure feet into All done and ready to be used, position with bolts.
