1home Furniture CH-001 Assembly

Pc tower holder

Download this manual

CH-001 PC TOWER HOLDER

Before starting assembly

Carefully open the carton, remove con-

tents and lay out on cardboard or other

protective surface to avoid damage.

Check package contents against the

Supplied Parts List to assure that all

components were received undam-

aged. Do not use damaged or defective

parts.

Install and operate this device with

care. Please read this instruction before

beginning the installation, and carefully

follow all instructions contained herein.

Use proper safety equipment during

installation.

Do not use this product for any purpose

or in any conﬁguration not explicitly

speciﬁed in this instruction. We hereby

disclaims any and all liability for injury

or damage arising from incorrec t

assembly, incorrect mounting, or incor-

rect use of this product.

Supplied Parts List

01 Holder x1set

Webbing accommodate PC tower

height in variety:

a. PC tower width at 80mm maximum

height at 650mm.

b. PC tower width at 700mm maximum

height at 30mm.

02 Stopper x4

03 Screw x8

04 Cable Tie x2

Page 1 CH-001 PC TOWER HOLDER Before starting assembly Carefully open the carton, remove con- tents and lay out on cardboard or other protective surface to avoid damage. Check package contents against the Supplied Parts List to assure that all components were received undam- aged.
Page 2 ASSEMBLY GUIDE 66.7mm 66.7mm 66.7mm Place Holder 01 on top of PC tower as the above diagram. Measure the distance “a” by the tape. Make 8 marks under the desk as the below diagram for the location you want to install this PC tower holder. 66.7mm 66.7mm 66.7mm Use 8pcs Screw 03 to ﬁx the Holder 01 under the desk.
