- Page 1 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE I NSTAL L AT I ON M ANUAL Load cell Feet Label printers bracket screws Outer tower bolts Scoreboard Inner tower bracketbolt bolts info@selletonscales.com (844)-735-5386 www.selletonscales.com...
- Page 2 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE Start unpacking the protective Frame of the Wrapping machines Use the forklift channels to pick the wrapping machine up & remove it from Crate. Set the wrapping machine on the ground info@selletonscales.com (844)-735-5386 www.selletonscales.com...
- Page 3 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE Lift up the tower with 2-3 people or use a forklift & strap Remove the Engine Cover by unscrewing the bolts Remove the Side panel on the tower by removing the screws info@selletonscales.com (844)-735-5386 www.selletonscales.com...
- Page 4 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE Locate the anchoring holes Install the 2 bolts Install the 2 bolts located on to the left side of the machine, on each side of the stretch wrap info@selletonscales.com (844)-735-5386 www.selletonscales.com...
- Page 5 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE Install the Bolt on top of the tower to hold the bracket & the scoreboard Plug in the Power & the 5 prong scoreboard cables Install the Bracket for the printer & plug in the printer &...
- Page 6 SL-K120 INDUSTRIAL PRE-STRETCH WRAPPING MACHINE Install all 4 feet & Screw all the way up Place the stretch wrap film on to the pole system & feed it as shown in the below diagram info@selletonscales.com (844)-735-5386 www.selletonscales.com...
