Accessories:
1. Micro USB Cable ( for charging )
2. 3.5mm Audio cable ( AUX-in cable )
3. User Manual
Bluetooth Connection:
Turn the speaker on by long press the power on button for 3 seconds. The Blue LED light
flashes quickly, then blue led flash quickly. The speaker now has entered the Bluetooth
pairing mode.
Connect to mobile phones/tablet PCs/computers:
1. Activate your phone's Bluetooth
2. Go to your phone's Bluetooth settings , scan for new Bluetooth devices
3. Upon device found (BT107), click the device name and pair with it
4. If your phone ask for pairing code , please enter "0000" and confirm
5. After successful pairing, your speaker will sound a prompt tone and the LED
lights blue.
Note: Pairing time is varied with different mobile phones. It only need to pair at the first
time and it will auto connect the devices which already paired before( Speaker only can
remember the last 8 paring devices name)
AUX -IN function
The speaker also features 1x AUX audio in port, simply connect the speaker with your
non-bluetooth mobile phone/MP3 player/PC/laptop with the 3.5' jack audio cable. The
green will be on, and then you can play music via wired connection
Low power indication: Speaker will have voice hint to remind you to charge if battery is
low( battery only left 10%). User need to charge the speaker timely.
Charging and computer connection :
Connect the micro USB charging cable to a computer or USB charger, red Led
indication for charging status.
Red LED goes off upon charging finished. (2-3 hours for charging time.)
Specifications:
The meet Bluetooth 4.1 Class II, meet A2DP V1.2, AVRCP V1.4 profiles agreement.
BT107
User Guide
Advertisement
Table of Contents
Related Manuals for Weiking BT107
Summary of Contents for Weiking BT107
- Page 1 2. Go to your phone's Bluetooth settings , scan for new Bluetooth devices 3. Upon device found (BT107), click the device name and pair with it 4. If your phone ask for pairing code , please enter ”0000” and confirm 5.
- Page 2 Transmission distance: up to 10 m (transmission distance may different according to environmental factors and other device's functional range) Maximum output power: 3W Size： 69 *69*58mm signal to noise ratio S / N: ≥ 80dB Frequency Range: 160Hz-20KHz Distortion THD: ≤ 10% speaker unit: outer diameter 50 mm, inner magnet, 4 ohms, 5W Rated voltage: 3.7V DC Battery: built-in lithium battery, 3.7V/1000mA...
- Page 3 Note : 1. Under Bluetooth mode when the 3.5mm audio plug is inserted in, the speaker will switch to line in status automatically; 2. Please switch off the speaker if don’t use to prevent power loss 3. The batteries shall not be exposed to excessive heat such as sunshine, fire or the like. LED status: 1.
- Page 4 Bluetooth device supports AVRCP. Safety Notices: Read the following recommendations before using the bluetooth speaker. a) Keep it dry and don’t take it to damp places to avoid the product’s internal circuit being affected. b) Keep the product away from direct sunlight or hot places. High temperatures will shorten the life of electronic devices, destroy the battery or distort certain plastic parts.
