Summary of Contents for ZOpid HS-MS70PT
-
Page 2: Safety And General Information
AFETY AND ENERAL NFORMATION IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION OF THIS PRODUCT. READ THIS INFORMATION BEFORE USING YOUR DEVICE. Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 3: Key Features
Congratulations on your purchase of HS-MS70PT. The system consists of a wireless 7.0” LCD monitor and a wireless color pan/tilt camera. This is an ideal system for baby, elder or patient care, as well as for house monitoring. It is also well suited for small business applications. - Page 4 • Connect camera’s power adapter to the power jack on the backside of the camera’s base. Once powered on, the camera will go through the initial test. Note: The camera can be adjusted by rotating the camera head to the required position using the remote.
- Page 5 Left or Right Press “◄” or ”►” key to rotate the lens left and right Center Press this key to bring lens back to the normal position Auto. & Manual The “Auto” and “Manual” button on the remote control can operate the mode of M700 NOTE: 9V battery included –...
-
Page 6: Multi -Camera Operation
PERATION The Wireless monitoring System is designed to work with up to three wireless cameras. Additional cameras are sold separately. All models of wireless cameras offered by Hi-Tech Trading are compatible with this monitor. Important: When using more than one camera, make sure each camera is assigned to a specific/different channel by moving the DIP switch to the right position. - Page 7 SCAN (requires camera(s) with motion sensor) Pressing the Scan button places the system in Scan mode. The LCD monitor screen turns blank indicating it’s in standby mode. In standby mode system continuously scans the active cameras. If a camera detects motion, the LCD monitor displays picture from that camera and also generate a beep (the beep volume is adjustable from the monitor).
-
Page 8: Volume Adjust
OURCE Press to switch the monitor to work as wired monitor only or wireless. By pressing the Menu button, you can cycle through the Alarm Volume, Brightness, Contrast, Color, Tint, Mirror, Up/Down and Display Mode. OLUME DJUST Adjust Volume setting and parameters as above. ROUBLE HOOTING Symptom... - Page 9 PECIFICATIONS (CA520): AMERA TV System Standard Image Sensor Integrated Lens Resolution Signal/Noise Ratio Frequency Range Weather proof Mini. Illumination Current Consumption Modulation PIR Range & Angle Overall size Transmission Range (M700) ONITOR TV System Standard Frequency Range Screen Size Resolution Power Supply Brightness Contrast Rate...
- Page 10 Limited 1 Year Warranty Coverage: Hi-Tech Trading (USA), Inc. (“HiTT”) warrants this product (“Product”) against defects in materials and workmanship under normal consumer use for 1 year from the date of purchase. HiTT, at its option, will at no charge repair, replace or refund the purchase price of this Product should it not conform to this warranty.
- Page 11 ZOpid and the Stylized Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © 2007 Hi-Tech Trading (USA), Inc. The information contained in this User Manual is believed to be correct at the time of printing.
- Page 12 DRILLING TEMPLATE FOR WALL MOUNTING MONITOR To wall-mount monitor, drill two holes using a 1/4” drill bit and this template. Insert supplied wall anchors into the holes and secure monitor to wall with supplied screws.
