Hilka HDPC106 Assembly Instructions

Drawer chest

Assembly INSTRUCTIONS FOR

Model No.

6 Drawer Chest

Overall Size:

Top Tray (x1):

Weight Load per Top Tray:

Small Drawer (x3):

Weight Load per Small Drawer:

Medium Drawer (x1):

Weight Load per Medium Drawer:

Big Drawer (x2):

Weight Load per Big Drawer:

Unit Weight:

Maximum Weight Load (Total):

6 Drawer Chest

HDPC106

686 x 305 x 364 mm

658.5 x 303 x 92 mm

25 kg

172.5 x 267.5 x 46 mm

10 kg

577 x 267.5 x 46 mm

20 kg

577 x 267.5 x 61.5 mm

25 kg

21.70 kg

125 kg
