LA-5174 Solar Wireless Door Announcer

Introduction

The LA-5174 is based on the advanced wireless and solar cell technology that the door

announcer gives alert signal for anyone approaching the area monitored by the solar wireless

PIR. All visitors will be effectively detected. It is easy to set up and simple to use.

Please read this manual carefully before commencing installation.

Wireless Door Announcer x 1

The unit receives signals from the PIR and gives

off alert signal.

Solar Wireless PIR Motion Detector x 1

It detects body heat of a moving object. (more

than one set can be linked to the Wireless Door

Announcer.)

Solar panel x 1

It is used to charge the rechargeable batteries for the Solar

Wireless PIR. When the Wireless PIR is connected to

the Solar Panel, the battery of the Wireless PIR will

last longer

Remarks : Batteries are not included in the kit

Large and small flat bladed screwdrivers

Large and small cross-point screwdrivers

Hammer

Ladder or other safe working platform

Please Note: Tools are not included, consult a professional if you need assistance
